pressure on the 'front' of the material i.e., that portion
of the stuff that has passed over the block, but use a
push stick or a pusher shoe to clear the end of the
stuff over the block.
Thicknessing
When thicknessing, remove the fence. Lower the
thicknessing table slightly. Unlock and swing both
tables 'up and out of the way' , taking care not to foul
the overhand guard/arm assembly, which will
probably swing free. Turn the dust extraction hood
up and over the block.
Connect the dust extraction. Ensure the hose will not
Model
Product Code
Rating
Power
Feed Speed
Cutterblock Speed
Cutterblock Diameter
Max Thicknesser Capacity
Max Planing Width
Max Depth of Cut
Max Depth of Cut Thicknesser
Max Depth of Cut Planer
Knives
Length of Table
Min Extraction Airflow Required
Dust Extraction Outlet
Overall L x W x H
Weight

Specific Precautions Using Planer Thicknessers

AW106PT2
501202
Trade
1,500W
8m/min
4,000rpm
80mm
180mm
250mm
2.5mm
3.0mm
1.5mm
HSS(Resharpenable) x 3
260 x 1,090mm
1,000m³/hr
100mm
1,090 x 750 x 1,000mm
150kg
foul any stuff being passed through the machine.
Check the height of the thicknessing table.
Engage the autofeed mechanism.
Periodically, clean any excess build up of resin from
the thicknessing table, and apply any proprietary
brand of lubricating agent.
NOTE, Consideration should be given to the type of
finish you will be applying to the surface when you
select your cleaning/lubrication agent.
AW128PT
501203
Trade
2.2kW
8m/min
4,000rpm
95mm
220mm
310mm
5mm
2.5mm
1.5mm
HSS(Resharpenable) x 4
310 x 1520mm
1,500m³/hr
125mm
1,520 x 600 x 1,070mm
325kg

Specifications

AW168PT
501204
Trade
3.0kW
8m/min
4,000rpm
95mm
220mm
410mm
5mm in surfacing mode
2.5mm
1.5mm
HSS(Resharpenable) x 4
1,600mm
1,500m³/hr
125mm
1,700 x 600 x 1,000mm
343kg
05
