Note: If an extension cable is used it must be
earthed and connected through the plug to the earth
cable of your supply network in accordance with pre-
scribed safety regulations.
If in doubt contact a qualified electrician or the near-
est Bosch Service Centre.
WARNING! Inadequate extension cables can be
dangerous. Extension cable, plug and socket
must be of watertight construction and intended
for outdoor use.
Cable connections should be kept dry and off
ground.
It is recommended for increased electrical safety to
use a Residual Current Device (RCD) with a tripping
current of not more than 30 mA. Always check your
RCD every time you use it.
For products not sold in GB: WARNING: For safety,
it is essential that the mains plug attached to the
product is fitted to the power supply cable. The cou-
plings of connection leads must be protected against
splashes and the coupling sockets on the leads must
be made of rubber or coated with rubber. Fixing
means for the connection leads must be used.
If the supply cord is damaged, it must be replaced by
a Bosch Service Centre.
Products sold in GB only: Your product is fitted with
an approved 13 A (BS 1363/A) electric plug and is
protected by a 13 A fuse (ASTA Approved to
BS 1362).
If the fitted plug is not suitable for your socket out-
lets, it should be cut off and an appropriate plug fitted
in its place.
The severed plug must be disposed of to avoid a
possible shock hazard and should never be inserted
into a 13 A socket elsewhere.
Assembly
Water connection
Screw inlet connector 8 onto machine water inlet
A
connection 12.
/ Attach water supply hose (not supplied) to
A B
the mains water supply and machine.
Connecting high pressure water
supply hose/nozzle
Securely screw high pressure hose 5 onto ma-
C
chine at connection 13.
Inserting the vario-jet/fan power lance 4 into the
D
power gun 3. Depress and turn the vario-jet/fan
power lance 90° clockwise to lock in place.
F016L70 350 • 05.10
Adjustments and using
different nozzles
Vario-jet-fan power lance (red colour coded)
Twist the front ring to adjust from a pencil to a fan
E
jet and vice versa.
Roto power lance (red colour coded)
Turn the vario-jet/fan power lance 4 90° anti-
I
clockwise. Extract the vario-jet/fan power lance.
Insert the roto-power lance 7 into the power
J
gun 3. Depress and turn the roto-power lance 90°
clockwise to lock in place.
Detergent nozzle and bottle
AQUATAK 110
Turn the power lance 90° anti-clockwise. Extract
I
the power lance.
Insert the detergent-nozzle 6 into the power
F
gun 3. Depress and turn the detergent-nozzle 90°
clockwise to lock in place.
AQUATAK 110 PLUS/115 PLUS
To apply the detergent twist the rear ring as
G
shown from high pressure mode to low pressure
mode.
To adjust the spray pattern twist the front ring.
Starting and Stopping
Starting
Connect the product to the mains supply ensuring
that the mains switch is in the (
Open water tap.
Press the safety lock 1 to release the trigger 2.
K
Fully press the trigger 2 until there is a constant flow of
water to clear the air from the machine and water supply
hose. Release trigger 2. Press the trigger safety lock.
Press button ( ) on main switch 10.
Point the power gun 3 downwards. Press the trigger
safety lock to release the trigger 2. Fully press the
trigger 2.
Stopping
Release trigger 2. Press the trigger safety lock. The
power gun is now locked and can not be operated
accidentally.
Press button ( ) on the main switch 10.
Close water tap. Unplug the machine from the elec-
tric supply.
Press the trigger safety lock 1 to release the trig-
ger 2. Fully press the trigger 2 until there is no more
water pressure in the machine. Release trigger 2.
Press the trigger safety lock 1.
Disconnect water supply hose from machine and
water supply.
) position.
