Avermedia AVerTV Studio 509 Specification

"AVerTV Studio 509" is the cutting-edge TV tuner cards with RDS for
Desktop computer users and the can be the gateway to taking
complete control of your TV viewing experiences.
The RDS（Radio Data System）is the spotlight of Analog TV market
and you can regard it as the Teletext for FM radio.
The best feature of RDS is to provide additional information about the
programs being transmitted such as station name, Automatic Tuning,
Regional Links, enhanced other networks, program type, radio text,
commercial, time and date, etc.
It also support manual settings for Video window, color adjustment
and TV system. Instead of scanning all channels, you can choose to manually scan a channel or some
channels only. With the AVerTV Studio 509 you can have more fun and enjoyment while you work on your PC.

FEATURES

Record TV/video into MPEG-1/2/4*
RDS（Radio Data System）
Support 9 Bits Video Analog to Digital Converter
Brand-New Application Software With More
Functions and More Aesthetic
Modify QuickTV icon when pressing the remote
control button
Manual setting for each channel
Wake-Up Recording from stand By (S3)
/Hibernate (S4) Power-saving Mode
Hot-key Re-Definition
Remote Control Button Re-Definition
Multi-font selection for OSD information
Watch TV on Your PC
16-Channel Preview
-
- Channel Scan/All Frequency Scan
Parental Channel Lock-Out
-
Create Your Favorite Channel Group
Exclusive Customized Channel Remapping
Fully Functional Infrared Remote Control
Album Feature for Still Image Capture
Save Image to BMP, JPG, TIF, PCX Format
-
- Save Image to Any Size (up to 1600 x 1200)
Personal Video Recorder (PVR)
- Playback Your Recorded Programs While
Continuing to Record in Real Time
（TimeShift）
TV Viewing/ Recording Scheduler
-
Listen to FM Radio Program
- FM Radio TimeShift
Direct Sound
** (Only for Analog TV) To encode MPEG-4 format, we
suggest that users should download DivX codec from
www.divx.com or XviD codec from www.xvid.org. The
codecs are not developed by AverMedia. Therefore,
AverMedia could not guarantee the function of MPEG-4
recording.
A V e r T V
A V e r T V
The RDS High Quality TV Tuner Card！
S t u d i o 5 0 9
S t u d i o 5 0 9

SPECIFICATIONS

Supports up to 4 Inputs:
TV Input: 75 Ohm Coaxial TV Antenna
Video Input: S-Video & Composite（RCA）Video
Audio Input: Stereo Audio Input
Audio Output: Direct to Sound Card
Dimensions: 5.31" x 4.92" x 0.83"
Weight: 186g

SYSTEM REQUIREMENTS

Pentium III 800, 128MB RAM or better
PCI 2.1 Compatible Slot
Sound Card (Full Duplex for TimeShift™) and Record
For Internet Video Phone Applications
Camcorder or Desktop Camera
-
- Microphone
28.8Kbps or Faster Modem
-
Windows® 98SE/2000/ME/XP
VGA Card supporting DirectX 9.0

PACKAGE INCLUDED

AVerTV Studio 509 Tuner Card
Quick Installation Guide
Installation CD
Audio Loopback Cable
Remote Control（Batteries Included）
FM Radio Antenna
(Features subject to change without notice.)
Global Page: www.avermedia.com
©2006 AVerMedia all rights reserved.
The specifications may be changed without notice.
All other trademarks belong to their respective companies.
