Hoshizaki KM-201BAH Instruction Manual

Hoshizaki KM-201BAH Instruction Manual

Self-contained crescent cuber
Hide thumbs Also See for KM-201BAH:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Instruction Manual
SELF-CONTAINED CRESCENT CUBER
INSTRUCTION MANUAL
KM-201BAH
KM-260BAH
KM-201BWH
KM-260BWH
L1F015102 (100109)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM-201BAH and is the answer not in the manual?

Questions and answers

Related Manuals for Hoshizaki KM-201BAH

Summary of Contents for Hoshizaki KM-201BAH

  • Page 1 SELF-CONTAINED CRESCENT CUBER KM-201BAH KM-260BAH KM-201BWH KM-260BWH INSTRUCTION MANUAL L1F015102 (100109)
  • Page 2 Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, write, or send an e-mail message to the Hoshizaki Technical Support Department for assistance. HOSHIZAKI AMERICA, INC.

  • Page 3: Table Of Contents

    CONTENTS PAGE I. Specifications -------------------------------------------------------------------------------------------1 A. Nameplate Rating ----------------------------------------------------------------------------------1 B. Dimensions/Connections -------------------------------------------------------------------------2 1. KM-201BAH --------------------------------------------------------------------------------------2 2. KM-260BAH --------------------------------------------------------------------------------------3 3. KM-201BWH -------------------------------------------------------------------------------------4 4. KM-260BWH -------------------------------------------------------------------------------------5 II. Installation and Operating Instructions -----------------------------------------------------------6 A. Checks Before Installation -----------------------------------------------------------------------6 B.

  • Page 4: Specifications

    I. Specifications A. Nameplate Rating Model Amperes Refrigerant Energy Star KM-201BAH 6.1 AMPS R404A 12.0 oz. Applicable KM-260BAH 7.6 AMPS R404A 12.7 oz. Applicable KM-201BWH 5.4 AMPS R404A 10.9 oz. Not applicable KM-260BWH 7.1 AMPS R404A 13.8 oz. Not applicable See the Nameplate for electrical and refrigeration specifications.

  • Page 5: Dimensions/Connections

    B. Dimensions/Connections 1. KM-201BAH Unit: mm [inches]...

  • Page 6: Km-260Bah

    2. KM-260BAH Unit: mm [inches]...

  • Page 7: Km-201Bwh

    3. KM-201BWH Unit: mm [inches]...

  • Page 8: Km-260Bwh

    4. KM-260BWH Unit: mm [inches]...

  • Page 9: Installation And Operating Instructions

    II. Installation and Operating Instructions A. Checks Before Installation * Visually inspect the exterior of the shipping container, and any severe damage noted should be reported to the carrier. IMPORTANT 1. Remove shipping carton, tape(s) and packing. If packing material is left in the icemaker, it will not work properly.

  • Page 10: Location

    Separator (inside) * KM-201BAH, KM-260BAH only Door Air Inlet* (Air Filter) Air Filter* Louver How to remove Louver Magnet Catch Fig. 1 C. Location WARNING This icemaker is not intended for outdoor use. Normal operating ambient temperature should be within +45°F to +100°F (+7°C to +38°C); Normal operating water temperature should be within +45°F to +90°F (+7°C to +32°...

  • Page 11: Electrical Connection

    D. Electrical Connection WARNING THIS APPLIANCE MUST BE GROUNDED. This icemaker requires a ground that meets the national and local electrical code requirements. To prevent possible severe electrical shock injury to individuals or extensive damage to equipment, install a proper ground wire to this icemaker.

  • Page 12: Water Supply And Drain Connections

    from 6” (15.2 cm) to 7” (17.8 cm). Screw the legs tightly into the tapped holes in the base (see Fig. 3). Handle the icemaker carefully not to damage the exterior. Tapped Hole (Leg Mounting) Base Adjustable Leg Max. 0.2” (5mm) [0.3°] Fig.
  • Page 13 floor drain. * This icemaker should be installed in accordance with applicable national, state and local regulations. * A plumbing permit and services of a licensed plumber may be required in some areas. KM-201BAH Drain Outlet KM-260BAH 3/4” FPT Water Supply Inlet 1/2”...
  • Page 14 KM-201BWH KM-260BWH Drain Outlet Condenser Water 3/4” FPT Inlet 1/2” FPT Water Supply Inlet Condenser Water 1/2” FPT Outlet 1/2” FPT Shut-off Valve Shut-off Valve 1/4” fall per foot Drain Valve To approved floor drain Drain Valve Two-inch (5 cm) air gap Separate piping to approved drain.

  • Page 15: Final Checklist

    G. Final Checklist 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within +45°F to +100°F (+7° C to +38°C) and the water temperature within +45°F to +90°F (+7°C to +32°C) all year around? 3) Is there at least 2”...

  • Page 16: Startup

    H. Startup CAUTION 1. All parts are factory-adjusted. Improper adjustments may result in failure. 2. If the unit is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the Compressor. 3. To prevent damage to the Water Pump, do not leave the Control Switch in the “SERVICE”...

  • Page 17: Cleaning And Maintenance Instructions

    1. Cleaning Procedure 1) Dilute 5 fl. oz. (148 ml) of recommended cleaner Hoshizaki “Scale Away” or “LIME-A- WAY” (Economics Laboratory, Inc.) with 1 gallon (3.8 lit.) of water. 2) Remove the Louver. Open the Door and remove all ice from the Evaporator and the Storage Bin.
  • Page 18 7) After 30 minutes, move the Control Switch to the “OFF” position. 8) Same as step 4. 9) Move the Control Switch to the “ICE” position to fill the Water Tank with water. 10) After 3 minutes, move the Control Switch to the “SERVICE” position and the Service Switch to the “WASH”...

  • Page 19: Sanitizing Procedure - Following Cleaning Procedure

    15) Pull the Cube Guides (quantity varies depending on model) upward to remove them from the Water Tank. They are snapped in place. See Fig. 8. 16) Same as step 1. Cube Guide Water Tank * The Bin Control Switch is accessible by removing the Water Tank.

  • Page 20: Maintenance

    2) Soak the removed parts from step 17 above in a clean container containing the sanitizing solution. After allowing the parts to soak for 10 minutes, wash them with the solution. Also wash the bin liner, Bracket (L) (R) with the solution. 3) Discard the sanitizing solution and rinse the parts thoroughly with water.

  • Page 21: Air Filter

    * The Storage Bin is for ice use only. Do not store anything else in the bin. * Keep the scoop clean. Clean it by using a neutral cleaner and rinse thoroughly. * Clean the bin liner by using a neutral cleaner. Rinse thoroughly after cleaning. 3.
  • Page 22 5) Allow the line to drain by gravity. 6) Attach compressed air or carbon dioxide supply to the potable water supply line Drain Valve. 7) Move the Control Switch to the “ICE” position. 8) Quickly blow the potable water supply line out using compressed air or carbon dioxide. 2.
