Hoshizaki KM-2000SRE3 Final Parts List

Hoshizaki KM-2000SRE3 Final Parts List

Stackable crescent cuber
Hide thumbs Also See for KM-2000SRE3:

Advertisement

Quick Links

Download this manual See also: Service Manual
STACKABLE CRESCENT CUBER
HOSHIZAKI
MODEL
KM-2000SWE3
KM-2000SRE3
(FINAL) PARTS LIST
NO.
ISSUED:
JUNE 7, 1994
REVISED:
AUG. 7, 2000
71090

Advertisement

loading

Related Manuals for Hoshizaki KM-2000SRE3

Summary of Contents for Hoshizaki KM-2000SRE3

  • Page 1 STACKABLE CRESCENT CUBER KM-2000SWE3 KM-2000SRE3 (FINAL) PARTS LIST HOSHIZAKI MODEL 71090 ISSUED: JUNE 7, 1994 REVISED: AUG. 7, 2000...

  • Page 4: Ice Cuber Assembly

    KM-2000SWE3 A. ICE CUBER ASSEMBLY...
  • Page 5 KM-2000SWE3 A. ICE CUBER ASSEMBLY E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 6 KM-2000SWE3 MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY LABEL LOCATION TRANSFORMER BOX ASSEMBLY EVAPORATOR CASE CONTROL BOX COVER SQUARE WASHER SCREW - GROUNDING BUSHING JUNCTION BOX COVER BULB HOLDER SPACER BULB HOLDER (C) BUSHING SPACER BULB HOLDER (D) FRONT PANEL - BRACKET SPACER TOP INSULATION...
  • Page 7 MODEL INDEX DESCRIPTION FRONT PANEL BULB HOLDER (E) BULB HOLDER (F) BULB HOLDER (G) TITLE KM-2000SWE3 A. ICE CUBER ASSEMBLY MATERIAL PART OR MODEL NUMBER NUMBER D-0 E-1 F-1 F-2 G-0 G-1 H-0 325848G01 439725-01 328743-01 439726-01 REQUIRED NUMBER...
  • Page 8 KM-2000SRE3 A. ICE CUBER ASSEMBLY D-0, E-0...
  • Page 9 KM-2000SRE3 A. ICE CUBER ASSEMBLY E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 10 KM-2000SRE3 MODEL INDEX DESCRIPTION REFRIGERATION CIRCUIT WATER CIRCUIT CONTROL BOX ASSEMBLY LABEL LOCATION TRANSFORMER BOX ASSEMBLY EVAPORATOR CASE CONTROL BOX COVER SQUARE WASHER SCREW - GROUNDING BUSHING JUNCTION BOX COVER BULB HOLDER SPACER BULB HOLDER (C) BUSHING SPACER BULB HOLDER (D)
  • Page 11 MODEL INDEX DESCRIPTION FRONT PANEL BULB HOLDER (E) BULB HOLDER (F) BULB HOLDER (G) BUSHING KM-2000SRE3 A. ICE CUBER ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER D-0 E-0 E-1 F-1 F-2 G-0 G-1 H-0 325848G01 439725-01 328743-01 439726-01 SR-30-1 420472-03...

  • Page 12: Refrigeration Circuit

    KM-2000SWE3 B. REFRIGERATION CIRCUIT (1/2) D-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 13 KM-2000SWE3 B. REFRIGERATION CIRCUIT (2/2)
  • Page 14 KM-2000SWE3 B. REFRIGERATION CIRCUIT (2/2) E-1, F-1, F-2, G-0...
  • Page 15 KM-2000SWE3 B. REFRIGERATION CIRCUIT (2/2) G-1, H-0...
  • Page 16 KM-2000SWE3 MODEL INDEX DESCRIPTION EVAPORATOR REAR FRAME SIDE FRAME (A) SIDE FRAME (B) FRONT FRAME REAR PANEL BRACE COMPRESSOR GROMMET SPACER BOLT CONDENSER - WATER-COOLED DRIER DRIER BRACKET EXPANSION VALVE FRAME SEAL HOT GAS VALVE BRACKET VALVE BRACKET VALVE BODY COIL - VALVE BOLT PRESSURE SWITCH...
  • Page 17 KM-2000SWE3 MODEL INDEX DESCRIPTION WATER REGULATOR BRACKET WATER REGULATOR ASSEMBLY STRAINER CHECK VALVE COPPER TUBE (A) - HIGH SIDE COPPER TUBE (B) - HIGH SIDE COPPER TUBE (C) - HIGH SIDE COPPER TUBE (F) - HIGH SIDE HEADER - S COPPER TUBE (A) - EXP.
  • Page 18 KM-2000SWE3 MODEL INDEX DESCRIPTION COPPER TUBE (A) COPPER TUBE (B) COPPER TUBE (C) HOLDER / EXP. VALVE - 3/8 CLAMP INSULATION TUBE CABLE TIE EXP. VALVE COVER (A) EXP. VALVE COVER (B) THERMISTOR HOLDER - THERMISTOR INSULATION - THERMISTOR PE FOAM RUBBER INSULATION (A) RUBBER INSULATION (B) INSULATION HOLDER...
  • Page 19 KM-2000SRE3 B. REFRIGERATION CIRCUIT (1/2) D-0, E-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 20 KM-2000SRE3 B. REFRIGERATION CIRCUIT (1/2) D-0, E-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 21 KM-2000SRE3 MODEL INDEX DESCRIPTION EVAPORATOR REAR FRAME SIDE FRAME (A) SIDE FRAME (B) FRONT FRAME REAR PANEL BRACE COMPRESSOR GROMMET SPACER BOLT CRANKCASE HEATER DRIER DRIER BRACKET EXPANSION VALVE FRAME SEAL HOT GAS VALVE BRACKET LINE VALVE BRACKET VALVE BODY...
  • Page 22 KM-2000SRE3 MODEL INDEX DESCRIPTION STRAINER CHECK VALVE COPPER TUBE (A) - HIGH SIDE VALVE BODY COIL - VALVE BOLT HEADER - S COPPER TUBE (A) - EXP. VALVE COPPER TUBE (B) - EXP. VALVE COPPER TUBE (C) - EXP. VALVE...
  • Page 23 KM-2000SRE3 MODEL INDEX DESCRIPTION HOLDER / EXP. VALVE - 3/8 CLAMP INSULATION TUBE CABLE TIE EXP. VALVE COVER (A) EXP. VALVE COVER (B) THERMISTOR HOLDER - THERMISTOR INSULATION - THERMISTOR PE FOAM RUBBER INSULATION (A) RUBBER INSULATION (B) INSULATION HOLDER...

  • Page 24: Water Circuit

    KM-2000SWE3, SRE3 C. WATER CIRCUIT D-0, E-0...
  • Page 25 KM-2000SWE3, SRE3 C. WATER CIRCUIT E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 26 KM-2000SWE3, SRE3 MODEL INDEX DESCRIPTION PUMP MOTOR ASSEMBLY CORNER INSULATION (A) CORNER INSULATION (B) WATER SUPPLY PIPE RUBBER GASKET WATER VALVE BRACKET WATER VALVE DISTRIBUTOR HOSE (A) JOINT PIPE DISTRIBUTOR HOSE (B) HOSE CLAMP HOSE CLAMP SPRAY TUBE SPRAY GUIDE (A) SEPARATOR (A) SEPARATOR (B) CUBE GUIDE...
  • Page 27 MODEL INDEX DESCRIPTION JOINT - OVERFLOW BUSHING VALVE HOLDER MICRO SWITCH TAPPING SCREW FLOAT SWITCH BRACKET CONNECTOR - FLOAT SWITCH FLOAT SWITCH JOINT HOSE CLAMP HANDLE "O" RING "O" RING DRAIN HOSE DRAIN "O" RING BYPASS HOSE DISTRIBUTOR (C) JOINT HOSE DISTRIBUTOR (B) FLANGE BALL VALVE...
  • Page 28 KM-2000SWE3, SRE3 MODEL INDEX DESCRIPTION VINYL HOSE SILICONE HOSE VINYL HOSE SILICONE HOSE INSULATION HOSE INSULATION HOSE INSULATION HOSE C. WATER CIRCUIT TITLE MATERIAL PART OR MODEL NUMBER D-0 E-0 (SRE3 ONLY) L=190 7716-0913 7730 I 3812 L=190 L=430 7716-0913 7730 I 3896 L=430 L=120...

  • Page 29: Control Box Assembly

    KM-2000SWE3 D. CONTROL BOX ASSEMBLY D-0, E-1, F-1...
  • Page 30 KM-2000SWE3 D. CONTROL BOX ASSEMBLY F-2, G-0, G-1, H-0...
  • Page 31 KM-2000SWE3 MODEL INDEX DESCRIPTION CONTROL BOX MAGNETIC CONTACTOR CAPACITOR TRANSFORMER BUSHING CONTROLLER BOARD BOARD SUPPORT CONTROL LABEL THERMOSTAT TOGGLE SWITCH 3P PLUG HOUSING 3P RECEPTACLE HOUSING BUSHING BUSHING BUSHING 2P PLUG HOUSING 2P RECEPTACLE HOUSING D. CONTROL BOX ASSEMBLY TITLE MATERIAL PART OR MODEL...
  • Page 32 KM-2000SRE3 D. CONTROL BOX ASSEMBLY D-0, E-0, E-1, F-1...
  • Page 33 KM-2000SRE3 D. CONTROL BOX ASSEMBLY F-2, G-0, G-1, H-0...
  • Page 34 KM-2000SRE3 MODEL INDEX DESCRIPTION MAGNETIC CONTACTOR CAPACITOR TRANSFORMER CONTROLLER BOARD BOARD SUPPORT CONTROL LABEL THERMOSTAT TOGGLE SWITCH 3P PLUG HOUSING 2P PLUG HOUSING 2P PLUG HOUSING 3P RECEPTACLE HOUSING 2P RECEPTACLE HOUSING 2P RECEPTACLE HOUSING BUSHING BUSHING BUSHING CONTROL BOX...

  • Page 35: Label Location

    KM-2000SWE3 E. LABEL LOCATION D-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 36 MODEL INDEX DESCRIPTION EMBLEM (L) - HOSHIZAKI EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN (R) MAINTENANCE LABEL WARNING LABEL - DANGER PVC FILM LABEL - R22 NAMEPLATE WIRING LABEL MANUAL LABEL MANUAL LABEL - BIN CONTROL INSTRUCTION LABEL TAG - WARNING:...
  • Page 37 KM-2000SRE3 E. LABEL LOCATION...
  • Page 38 KM-2000SRE3 E. LABEL LOCATION D-0, E-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 39 MODEL INDEX DESCRIPTION EMBLEM (L) - HOSHIZAKI EMBLEM MODEL NUMBER LABEL LABEL - PENGUIN (R) MAINTENANCE LABEL WARNING LABEL - DANGER PVC FILM LABEL - R22 NAMEPLATE WIRING LABEL MANUAL LABEL MANUAL LABEL - BIN CONTROL INSTRUCTION LABEL TAG - WARNING:...

  • Page 40: Transformer Box Assembly

    KM-2000SWE3, SRE3 F. TRANSFORMER BOX ASSEMBLY D-0, E-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 41 KM-2000SWE3, SRE3 MODEL INDEX DESCRIPTION TRANSFORMER BOX TRANSFORMER BOX COVER TRANSFORMER SLIDE SWITCH BUSHING MANUAL LABEL - TAP SWITCH F. TRANSFORMER BOX ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER D-0 E-0 (SRE3 ONLY) 333074-01 438467-01 BE24543001 4A0374-01 SE1022-SD- 439305-01 PM-F-R-HK-A SR-30-1 420472-03 PVC FILM...
  • Page 42 KM-2000SWE3, SRE3 G. EVAPORATOR D-0, E-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 43 MODEL INDEX DESCRIPTION EVAPORATOR EVAP. BRACKET (A) EVAP. BRACKET (B) END PLATE (A) END PLATE (B) HOOK EVAP. BRACKET COPPER TUBE (A) - EVAP COPPER TUBE (B) - EVAP COPPER TUBE (C) - EVAP EVAP. BRACKET (C) KM-2000SWE3, SRE3 TITLE G.

  • Page 44: Pump Motor Assembly

    KM-2000SWE3, SRE3 H. PUMP MOTOR ASSEMBLY D-0, E-0, E-1, F-1, F-2, G-0, G-1, H-0...
  • Page 45 KM-2000SWE3, SRE3 MODEL INDEX DESCRIPTION PUMP MOTOR PUMP FLANGE PUMP MOTOR BRACKET MECHANICAL SEAL PACKING IMPELLER PUMP HOUSING H. PUMP MOTOR ASSEMBLY TITLE MATERIAL PART OR MODEL NUMBER D-0 E-0 (SRE3 ONLY) 2U0106-01 M91A60SP201 215662-01 323904-01 428545-01 H5-PN, 8MM EPDM 428547-01 436584-01 414102-01...
  • Page 46 KM-2000SWE3, SRE3 J. ACCESSORIES D-0, E-0, E-1, F-1...
  • Page 47 KM-2000SWE3, SRE3 J. ACCESSORIES F-2, G-0, G-1, H-0...
  • Page 48 KM-2000SWE3, SWE3, SRE, SRE3 MODEL INDEX DESCRIPTION INSTRUCTION MANUAL UNIVERSAL BRACE THUMBSCREW THERMOSTAT EXTENSION BRACKET TITLE MATERIAL PART OR MODEL NUMBER D-0 E-0 (SRE3 ONLY) PAPER 91U1RE10A PAPER 91U1RE10B 4A0363-01 ABS, SS 415949G01 3A0408-01 J. ACCESSORIES REQUIRED NUMBER E-1 F-1 F-2 G-0 G-1 H-0...

This manual is also suitable for:

Km-2000swe3
