Installation and Assembly:
Universal Flat Wall Mount for 37" - 47" Flat Panel Screens
Model:
MT150 THIN
Features:
•
Universal design for 37" to 47" flat panel screens
•
Low-profile design keeps the screen close up against the wall
•
Easy to install with hooking brackets
•
Screen fasteners included for quick installation
Visit the Westinghouse Web Site at www.westinghousedigital.com
Max Load Capacity: 150 lb (68 kg)
For customer care call 1-866-287-5555.
ISSUED: 02-08-06 SHEET #: 202-9092-1
Advertisement
Table of Contents
Related Manuals for Westinghouse MT150 THIN
Summary of Contents for Westinghouse MT150 THIN
- Page 1 Low-profile design keeps the screen close up against the wall • Easy to install with hooking brackets • Screen fasteners included for quick installation Max Load Capacity: 150 lb (68 kg) Visit the Westinghouse Web Site at www.westinghousedigital.com For customer care call 1-866-287-5555. ISSUED: 02-08-06 SHEET #: 202-9092-1...
-
Page 2: Table Of Contents
Note: Read entire instruction sheet before you start installation and assembly. WARNING • Do not begin to install your Westinghouse product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please call customer care at 1-866-287-5555. -
Page 3: Parts List
Before you begin, make sure all parts shown are included with your product. Parts List Description Part # AA wall plate 200-4797 BB adapter bracket 200-0759 CC #14 x 2.5" wood screw 5S1-015-C03 DD Alligator® anchor 590-0097 EE 4 mm allen wrench 560-1145 Adapter Bracket Fasteners M6 x 12 mm (4) -
Page 4: Installation To Single Wood Stud Wall
Installation to Single Wood Stud Wall WARNING • Installer must verify that the supporting surface will safely support the combined weight of all attached equipment and hardware. Use a stud finder to locate the edges of the stud. Use of an edge-to-edge stud finder is highly recommended. Based on its edges, draw a vertical line down the stud’s center. -
Page 5: Installation To Double Wood Stud Wall
Installation to Double Wood Stud Wall WARNING • Installer must verify that the supporting surface will safely support the combined weight of all attached equipment and hardware. Wall plate (AA) can be mounted to two studs that are 16" apart. Use a stud finder to locate the edges of the studs. Use of an edge-to-edge stud finder is highly recommended. -
Page 6: Installation To Solid Concrete Or Cinder Block
WARNING • When installing Westinghouse wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual con- crete thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid part of the block, generally 1"... -
Page 7: Installing Adapter Brackets
Installing Adapter Brackets Refer to Screen Compatibility Chart to determine the proper fasteners to use. To prevent scratching the screen, set a cloth on a flat, level surface that will support the weight of the screen. Place screen face side down. If screen has knobs on the back, remove them to allow the adapter brackets to be attached. Place adapter brackets (BB) on back of screen, align to holes, and center on back of screen as shown in figure 2.1. -
Page 8: Installing Flat Panel Screen To Wall Plate
Mounting and Removing Flat Panel Screen Hook adapter brackets (BB) onto wall plate (AA). Then slowly swing screen in as shown. Turn screws clockwise using 4 mm allen wrench (EE) at least six times to prevent screen from being removed as shown in detail 1. Screen can be adjusted horizontally if desired. - Page 9 REPAIR OR REPLACEMENT – For a period of five (5) years from the original date of purchase, Westinghouse Digital Electronics will repair any defect in material or workmanship in the Product, or, at its option, replace a defective Product.
