Installation and Assembly:
Universal Tilt Wall Mount for 37" - 47" Screens
Model: MT150 TILT
Features:
• Universal design for 37" - 47" flat panel screens
• One-touch tilt for effortless positioning and adjustment of the screen
• Ultra-slim design holds the screen flat against the wall
• IncreLok™ locking tilt positions for specific tilt settings in 5° increments
• Comes in black
Visit the Westinghouse Web Site at www.westinghousedigital.com
This product is UL Listed. It must be
installed by a qualified professional
R
installer.
Max Load Capacity: 150 lb (68kg)
For customer care call 1-866-287-5555.
ISSUED: 02-08-06 SHEET #: 202-9093-1
Advertisement
Table of Contents
Related Manuals for Westinghouse MT150 TILT
Summary of Contents for Westinghouse MT150 TILT
- Page 1 • Ultra-slim design holds the screen flat against the wall • IncreLok™ locking tilt positions for specific tilt settings in 5° increments Max Load Capacity: 150 lb (68kg) • Comes in black Visit the Westinghouse Web Site at www.westinghousedigital.com For customer care call 1-866-287-5555. ISSUED: 02-08-06 SHEET #: 202-9093-1...
- Page 2 Note: Read entire instruction sheet before you start installation and assembly. WARNING • Do not begin to install your Westinghouse product until you have read and understood the instructions and warnings contained in this Installation Sheet. If you have any questions regarding any of the instructions or warnings, please call customer care at 1-866-287-5555.
-
Page 3: Parts List
Before you begin, make sure all parts shown are included with your product. Parts may appear slightly different than illustrated. Parts List Description Qty. Part # AA wall plate 200-4797 BB Left tilt bracket 200-0905 CC Right tilt bracket 200-0906 DD #14 x 2.5"... -
Page 4: Installation To Double Wood Stud Wall
Installation to Double Wood Stud Wall WARNING • Installer must verify that the supporting surface will safely support the combined load of the equipment and all attached hardware and components. • Tighten wood screws so that wall plate is firmly attached, but do not overtighten. Overtightening can damage the screws, greatly reducing their holding power. -
Page 5: Installation To Solid Concrete Or Cinder Block
WARNING • When installing Westinghouse wall mounts on cinder block, verify that you have a minimum of 1-3/8" of actual con- crete thickness in the hole to be used for the concrete anchors. Do not drill into mortar joints! Be sure to mount in a solid part of the block, generally 1"... -
Page 6: Installing Tilt Brackets
Installing Tilt Brackets Refer to Screen Compatibility Chart to determine the proper fasteners to use. To prevent scratching the screen, set a cloth on a flat, level surface that will support the weight of the screen. Place screen face side down. If screen has knobs on the back, remove them to allow the adapter brackets to be attached. Place tilt brackets (BB and CC) on back of screen. - Page 7 Mounting and Removing Flat Panel Screen Hook tilt brackets (BB and CC) onto wall plate (AA). Then slowly swing screen in as shown. Turn safety/ security screws, using phillips screw driver or security BB and CC allen wrench (FF), clockwise at least six times to prevent screen from being removed as shown in detail 1.
- Page 8 REPAIR OR REPLACEMENT – For a period of five (5) years from the original date of purchase, Westinghouse Digital Electronics will repair any defect in material or workmanship in the Product, or, at its option, replace a defective Product.
