Echo 99944200545 Operator's Manual

Trimmer attachment
Hide thumbs Also See for 99944200545:
Table of Contents

Advertisement

Quick Links

Download this manual
Trimmer Attachment
Operator's Manual
MODEL
FOR MODELS:
Users of this equipment risk injury to themselves and others if the unit is used im-
properly and/or safety precautions are not followed. ECHO provides an operator's
manual. It must be read and understood for proper and safe operation. Failure to
do so could result in serious injury.
X7702093803
99944200545
SRM-2100SB
SRM-2400SB
SRM-210SB/211SB/225SB
SRM-260SB/261SB
PAS-2100
PAS-2400
PAS-2601
PAS-210/211
PAS-225/225VP/225VPB
PAS-230/231
PAS-260/261
PAS-265/266
PAS-280
WARNING
X770001333
04/13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 99944200545 and is the answer not in the manual?

Questions and answers

Related Manuals for Echo 99944200545

Summary of Contents for Echo 99944200545

  • Page 1 Users of this equipment risk injury to themselves and others if the unit is used im- properly and/or safety precautions are not followed. ECHO provides an operator’s manual. It must be read and understood for proper and safe operation. Failure to do so could result in serious injury.

  • Page 2: Table Of Contents

    Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual and the SAFETY MANUAL. You will find both easy to use and full of helpful operations tips and SAFETY messages.

  • Page 3: Safety

    rimmer TTAchmenT perATOr AnuAl afeTy WARNING Refer to your Pro Attachment Series or Split Boom Operator's Manual for correct engine fueling, starting and stop- ping instructions. manual safeTy symbols and ImporTanT InformaTIon Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages pre- ceded by symbols or key words.

  • Page 4: Personal Condition And Safety Equipment

    Keep long hair away from engine and air intake. Retain hair with cap or net. Hearing Protection Hot Humid Weather ECHO recommends wearing hearing protection whenever unit is used. Heavy protective clothing can increase operator fatigue which may lead to heat stroke. Schedule heavy work for early morning or late afternoon hours when temperatures are cooler.
  • Page 5 rimmer TTAchmenT perATOr AnuAl Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).

  • Page 6: Equipment

    WARNING Use this attachment with ECHO approved models only. Serious injury may result from the use of this attachment combined with a non approved ECHO product. • Check unit for loose/missing nuts, bolts, and screws. Tighten and/or replace as needed.

  • Page 7: Description

    Locate this safety decal on your unit. Make sure the decal is legible and that you understand and follow the instructions on it. If the decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instruc- tions for specific information.

  • Page 8: Contents

    The ECHO product you purchased has been factory pre-assembled for your convenience. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts.

  • Page 9: Plastic Shield Installation

    rimmer TTAchmenT perATOr AnuAl 5. Rotate locator pin (A) 1/4 turn clockwise to engage lower shaft hole. Insure locator pin is fully engaged by twisting lower drive shaft. Locator pin should snap flush in coupler. Full engagement will prevent further shaft rotation. 6.

  • Page 10: To Advance Trimmer Line

    To advanCe TrImmer lIne See Maintenance Section for nylon line replacement. NOTE To advance trimmer line, tap trimmer head against the ground while the head is turning at normal operating speed. remove nylon lIne head 1. Align locking hole in upper plate with notch in edge of gear housing and insert head locking tool (C).

  • Page 11: Maintenance

    ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOUR- SELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed see your ECHO dealer for repairs.

  • Page 12: Nylon Line Replacement

    Drive Shaft (Lower) IMPORTANT Lower and upper drive shaft must be lubricated with high tem- perature automotive grease every 25 hours of operation, otherwise drive shaft assembly overheating and failure can result. 1. Loosen two (2) screws (B) and remove center locating screw (C). Pull gear box and shield from drive shaft housing.
  • Page 13 rimmer TTAchmenT perATOr AnuAl 3. Hold the spool, opening toward you. Place index finger between the two strands and wind line, tightly and evenly, in direction of arrow (E). 4. Place ends of line (C) into notches (F) in spool, leaving 6 in. pro- truding.

  • Page 14: Storage

    Torage Storage Hook Installation 1. Insert small end of hook into locating hole on attachment shaft. 2. Slide plastic cap onto end of attachment shaft. peCIfICaTIons MODEL ---------------------------------------------------- PAS hi Torque Trimmer Attachment Shaft Length ------------------------------------------------ 864 mm (34.02 in.) Attachment Width ----------------------------------------- 176 mm (6.93 in.) Attachment Height ----------------------------------------- 245 mm (9.65 in.) Weight (dry) w/line head --------------------------------- 1.57 kg (3.43 lb.)

  • Page 15: Warranty Statement

    The owner shall demonstrate reasonable care and use, and follow preventative maintenance, storage, fuel and oil usage as prescribed in the operator’s manual. Should a product difficulty occur, you must, at your expense, deliver or ship your ECHO unit to an authorized ECHO servicing dealer for warranty repairs (within the applicable warranty period), and arrange for pick-up or return of your unit after the repairs have been made.
  • Page 16 89 octane or higher. Gasohol which contains a maximum 10% ethanol (grain alcohol) or 15% MTBE (methyl/tertiary/butyl/ether) is also approved. The prescribed mixing ratio of gasoline to oil is listed on the ECHO oil label and covered in your operator’s manual.
  • Page 17 rimmer TTAchmenT perATOr AnuAl noTes...
  • Page 18 noTes...
  • Page 19 rimmer TTAchmenT perATOr AnuAl noTes...

  • Page 20: Servicing Information

    ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047 (800-673-1558). Always check the ECHO Web Site for updated information. Safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video. ECHO, INCORPORATED...
