Operator's Manual
Trimmer Attachment
Operator's Manual
MODEL
FOR MODELS:
Read rules for safe operation and instructions carefully. ECHO provides an
Operator's Manual and a Safety Manual for Pro Attachment Series power source
or Split Boom Trimmer. Those manuals and this manual must be read and under-
stood for proper and safe operation, otherwise serious personal injury may result.
X7702093800
99944200545
SRM-2400SB
SRM-260SB/261SB
PAS-230/231
PAS-260/261
PAS-2601
PAS-265
WARNING
X770001330
02/09
Advertisement
Table of Contents
Related Manuals for Echo 99944200545
Summary of Contents for Echo 99944200545
- Page 1 FOR MODELS: WARNING Read rules for safe operation and instructions carefully. ECHO provides an Operator's Manual and a Safety Manual for Pro Attachment Series power source or Split Boom Trimmer. Those manuals and this manual must be read and under- stood for proper and safe operation, otherwise serious personal injury may result.
-
Page 2: Table Of Contents
NTRODUCTION Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual and the SAFETY MANUAL you found in the same package. You will find both easy to use and full of helpful operating tips and SAFETY messages. -
Page 3: Safety
AFETY MANUAL SAFETY SYMBOLS AND IMPORTANT INFORMATION Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages preceded by symbols or key words. The following is an explanation of those symbols and key words and what they mean to you. -
Page 4: Personal Condition And Safety Equipment
Gloves also reduce the transmission of machine vibration to your hands. Hearing Protection ECHO recommends wearing hearing protection when- ever unit is used. Extended Operation/Extreme Conditions It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may be brought about by exposure to vibration and cold. -
Page 5: Repetitive Stress Injuries
Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms, and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI). -
Page 6: Equipment
EQUIPMENT WARNING Use this attachment with ECHO approved models only. Serious injury may result from the use of this attachment combined with a non approved ECHO product. • Check unit for loose/missing nuts, bolts, and screws. Tighten and/or replace as needed. -
Page 7: Description
Make sure the decal is legible and that you understand and follow the instructions on it. If the decal cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information. -
Page 8: Contents
The ECHO product you purchased has been factory pre-assembled for your convenience. Due to packaging restrictions, shield installation and other assembly may be necessary. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. -
Page 9: Plastic Shield Installation
5. Rotate locator pin (A) 1/4 turn clockwise to engage lower shaft hole. Insure locator pin is fully engaged by twisting lower drive shaft. Locator pin should snap flush in coupler. Full engagement will prevent further shaft rotation. 6. Secure lower shaft assembly to coupler by tightening clamping knob (D). -
Page 10: Remove Nylon Line Head
REMOVE NYLON LINE HEAD 1. Align locking hole in upper plate with notch in edge of gear housing and insert head locking tool (C). 2. Remove line head by turning it clockwise until head is completely off of shaft. 3. Remove locking tool. PERATION WARNING Moving parts can amputate fingers or cause severe injuries. -
Page 11: Maintenance
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOUR- SELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed see your ECHO dealer for repairs. -
Page 12: Drive Shaft (Lower)
NYLON LINE REPLACEMENT Level 1. Parts Required: ECHO 0.095" Nylon Trimmer Line 6 m (20 ft.) long. 1. Shut engine off. Lay unit on the ground with head assembly up. 2. Hold drum (A) and firmly turn spool (B) CW (clockwise) until it disengages from the inner drive. - Page 13 3. Use one piece of new nylon line (C) 6 m (20 ft.) long and thread through the molded loop (D) on the spool. Pull line tight and adjust so one end is 15 cm (6 in.) longer than the other. 4.
-
Page 14: Storage
TORAGE Storage Hook Installation 1. Insert small end of hook into locating hole on attachment shaft. 2. Slide plastic cap onto end of attachment shaft. PECIFICATIONS MODEL ---------------------------------------------------- PAS Hi Torque Trimmer Attachment Shaft Length ------------------------------------------------ 864 mm (34.02 in.) Attachment Width ----------------------------------------- 176 mm (6.93 in.) Attachment Height ---------------------------------------- 245 mm (9.65 in.) Weight (dry) w/line head --------------------------------- 1.57 kg (3.43 lb.) - Page 15 RIMMER TTACHMENT PERATOR ANUAL NOTES...
-
Page 16: Servicing Information
• Purchasing from your Echo Dealer. • Manuals are available by sending a written request stating the model number and serial number of your Echo unit, part number of the manual, your name and address, and mail to the address below.
