Shaft Hedge Clipper Attachment
Operator's Manual
MODEL
MODELS USED ON:
Users of this equipment risk injury to themselves and others if the unit is used im-
properly and/or safety precautions are not followed. ECHO provides an operator's
manual and a safety manual. Both must be read and understood for proper and
safe operation. Failure to do so could result in serious injury.
X7702091902
99944200485
SRM-2100SB
SRM-2400SB
SRM-210SB/211SB/225SB
SRM-260SB/261SB
PAS-2100
PAS-2400
PAS-2601
PAS-210/211
PAS-225/225VP/225VPB
PAS-230/231
PAS-260/261
PAS-265/266
WARNING
X770001132
11/11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Echo 99944200485
Summary of Contents for Echo 99944200485
- Page 1 Users of this equipment risk injury to themselves and others if the unit is used im- properly and/or safety precautions are not followed. ECHO provides an operator’s manual and a safety manual. Both must be read and understood for proper and safe operation.
-
Page 2: Table Of Contents
Welcome to the ECHO family. This ECHO product was designed and manufactured to provide long life and on-the-job- dependability. Read and understand this manual and the SAFETY MANUAL. You will find both easy to use and full of helpful operations tips and SAFETY messages. -
Page 3: Safety
afeTy WARNING Refer to your Pro Attachment Series or Split Boom Operator's Manual for correct engine fueling, starting and stop- ping instructions. manual safeTy symbols and ImporTanT InformaTIon Throughout this manual and on the product itself, you will find safety alerts and helpful, informational messages pre- ceded by symbols or key words. -
Page 4: Personal Condition And Safety Equipment
Gloves also reduce the transmis- sion of machine vibration to your hands. Hearing Protection ECHO recommends wearing hearing protection whenever unit is used. Vibration and Cold It is believed that a condition called Raynaud’s Phenomenon, which affects the fingers of certain individuals, may be brought about by exposure to vibration and cold. - Page 5 Repetitive Stress Injuries It is believed that overusing the muscles and tendons of the fingers, hands, arms and shoulders may cause soreness, swelling, numbness, weakness, and extreme pain in those areas. Certain repetitive hand activities may put you at a high risk for developing a Repetitive Stress Injury (RSI).
-
Page 6: Equipment
WARNING Use this attachment with ECHO approved models only. Serious injury may result from the use of this attachment combined with a non approved ECHO product. Before operation a complete check of the unit must be performed; • Check unit for loose/missing nuts, bolts and screws. Tighten and/or replace as needed. -
Page 7: Description
Locate this safety decal on your attachment. Make sure the decal is legible and that you understand and follow the instructions on it. If it cannot be read, a new one can be ordered from your ECHO dealer. See PARTS ORDERING instructions for specific information. -
Page 8: Contents
The ECHO product you have purchased has been factory pre-assembled for your convenience. After opening the carton, check for damage. Immediately notify your retailer or ECHO Dealer of damaged or missing parts. Use the contents list to check for missing parts. -
Page 9: Loop Handle Removal
NOTE Lower bearing housing and head assembly must be in line with the engine. 6. Select desired blade position by aligning one of the holes (F) in lower shaft with locator pin position. 7. Rotate locator pin (A) 1/4 turn clockwise to engage lower shaft hole. -
Page 10: Operation
1. Hold trimmer firmly and squeeze throttle trigger to accelerate engine. 2. Tilt trimmer so cutting teeth are angled slightly toward the hedge or shrub and proceed to cut. WARNING Never remove hands from unit when blades are moving. -
Page 11: Skill Levels
ECHO Service Dealer for maintenance. To help you decide whether you want to DO-IT-YOURSELF or have the ECHO Dealer do it, each maintenance task has been graded. If the task is not listed see your ECHO dealer for repairs. - Page 12 Gear Housing Assembly Level 1 Parts required: POWER BLENDX Lithium Based Grease Clean dirt from grease fitting (A). 2. Carefully pump grease in fitting. DO NOT force grease. Too much pressure will force grease past seals and cause damage. Apply 1-2 pumps of grease every 15-25 hours of operation. Drive Shaft Assembly Level 1.
-
Page 13: Sharpening Blades
If a power grinder is used DO NOT allow blade to over heat. 5. Lubricate blades (see “Lubrication instructions”). IMPORTANT Blades should only be removed and reinstalled by an Authorized ECHO Servicing Dealer, otherwise premature wear or internal damage may occur. haft edge... -
Page 14: Blade Adjustment
blade adjusTmenT Level 2. Move stop switch to STOP position. Disconnect spark plug wire. WARNING Hedge clipper blades are very sharp. Touching them may lead to severe personal injury. Use long hex wrenches and sockets with extensions when tightening blade screws and blade locknuts to keep hands at a safe distance from sharp blades. -
Page 15: Storage
Torage IMPORTANT Always install blade cover when transporting or storing unit. Clean and lubricate cutting blades and gear case. Sharpen cutting blades as required. Apply a light coating of clean 20W engine oil along entire length of blades and on blade bolts. Install blade cover onto hedge clipper cutting blades. -
Page 16: Servicing Information
ECHO Inc., 400 Oakwood Road, Lake Zurich, IL 60047 (800-673-1558). Always check the ECHO Web Site for updated information. Safety Videos are available from your Echo dealer. A $5.00 shipping charge will be required for each video. eCho, InCorporaTed...
