PRODUCT
Product Model:
Description:
Dimensions (h x w x d): 108 mm x 618 mm x 688 mm / 4.3 in x 24.3 in x 27.1 in
Material:
Supplied Accessories: 2x Connecting Pin
Accessories:
COUNTRY OF ORIGIN FOR THE PRODUCT AND COMPONENTS
United States of America
TECHNICAL SPECIFICATIONS
The JFL210 and JFL118 loudspeakers are to be suspended below the FB121 Fly Bar or JFL118
loudspeaker. When used in accordance with the JFL Series Owner's Manuals the Working Load Limits
(WLL) and Design Factor are:
Nominal Weight of JFL210
Nominal Weight of JFL118
Nominal Weight of FB121
WLL (for Fly Bar mixed array)
WLL (for Fly Bar JFL210 only array)
WLL (for Fly Bar JFL118 only array)
Ultimate Strength Design Factor
STANDARDS CONFORMITY
The FB121 Fly Bar is designed and intended to suspend JFL210 and JFL118 loudspeakers in accordance
with the JFL Series Owner's Manual and FB121 Installation Instructions. Up to six (6) JFL210/JFL118
loudspeakers may be vertically suspended in a column below the FB121 Fly Bar. JFL210 loudspeakers
must be flown below JFL118 loudspeakers in a mixed array. JFL118 must be pinned to FB121 in all three
locations and JFL210 must be pinned in both locations. The total weight of any combination must not exceed
the WLL of the integral rigging components or that of the FB121 Fly Bar. For combinations of JFL210 and
JFL118, use the following formulas to determine maximum quantities of each. This keeps the total weight of
the JFL210/JFL118 combination within the above-specified WLL.
Maximum total quantities for suspended configurations using a combination of JFL210 and JFL118
loudspeakers are:
Maximum Total Combination
Maximum quantity JFL210 = 6 - quantity JFL118
Maximum quantity JFL118 = 6 - quantity JFL210
Quantity JFL210 + quantity JFL118 ≤ 6
The ultimate strength for the FB121 Fly Bar was determined utilizing calibrated and certified destructive pull-
tests.
Eastern Acoustic Works
One Main Street
Whitinsville, Ma 01588
CE DECLARATION OF CONFORMITY
FB121
Fly Bar
A500 steel tubing, A36 steel bar stock, 4140 steel bar stock
Spare Connecting Pin
M10 Eye Bolt
JFL210 Loudspeaker
JFL118 Loudspeaker
Page 1 of 2 October 2008
p/n 0031170
p/n 0032275
p/n 0031196-01
p/n 0031196-01
p/n 0029818
p/n
0029139-90
p/n 0031237-90
p/n 0030529-90
p/n 0032250-90
27 kg / 52 lb
44 kg / 97 lb
13 kg / 29 lb
277 kg / 611 lb
155 kg / 341 lb
277 kg / 611 lb
>10:1
Tel: 800 992 5013
e-mail:
info@eaw.com
www.eaw.com
