Draytek VigorTalk ATA-24 User Manual page 9

LED
ROR
VoIP (1-24)
Factory Reset:
Used to restore the default settings. Turn on the adapter (VACT LED is blinking). Press the
hole and hold for more than 5 seconds. When you see the VACT LED begins to blink rapidly
than usual, release the button. Then the adapter will restart with the factory default
configuration.
Interface
CONSOLE
MGN
WAN (WAN1 ~ WAN2)
MIRROR
VigorTalk ATA24 Series User's Guide
Status
On
1000
Off
FDX On
Off
On
Blinking
Explanation
It means that a normal 1000 Mbps connection is
through its corresponding port.
It means that a normal 100 Mbps connection is
through its corresponding port.
It means a full duplex connection on corresponding
port.
It means a half duplex connection on corresponding
port.
The phone is off hook (the handset of phone is
hanging).
A phone call is incoming or on-line.
Description
Provided for technician use.
Connecter for local management.
Connecter for remote networked devices.
Connecter for security monitor.
3
