Active Xenon headlamps*

Hold the button in the centre console
depressed for at least 5 seconds. The car must
be stationary when the headlamp pattern is
HEADLIGHTS SET
adjusted. The message
FOR RH TRAFFIC or HEADLIGHTS SET
FOR LH TRAFFIC is shown in the display.

Halogen headlamps

The headlamp pattern for halogen headlamps
is readjusted by masking the headlamp lens.
The headlamp pattern may not be as good.

Masking the headlamps

1. Copy the A and B templates for left-hand
drive cars or the C and D templates for
right-hand drive cars with a scale of 1:1,
see page 85:
•
A = LHD Right (left-hand drive, right
lens)
•
B = LHD Left (left-hand drive, left lens)
•
C = RHD Right (right-hand drive, right
lens)
•
D = RHD Left (right-hand drive, left lens)
2. Transfer the template to a self-adhesive
waterproof material and cut it out.
3. Position the self-adhesive templates at the
right distance from the edge of the head-
lamp lens using the illustration, see
page 84, and the dimensions in the fol-
lowing list:
•
Templates A and D: horizontal line
approx. 104 mm, vertical line approx.
20 mm
•
Templates B and C: horizontal line
approx. 167 mm, vertical line approx.
14 mm
03 Your driving environment
*
Option/accessory, for more information, see Introduction.
