01 Safety
Child safety
01
Press the booster cushion backwards to
lock.
Stage 2
Start from the lower stage. Press the but-
ton.
36
Lift the booster cushion up at the front edge
and press it back against the backrest to lock.
WARNING
Repair or replacement should only be per-
formed by an authorised Volvo workshop.
Do not make any modifications or additions
to the booster cushion. If an integrated
booster cushion has been subjected to a
major load, such as in conjunction with a
collision, the entire booster cushion must be
replaced. Even if the booster cushion
appears to be undamaged, it may not afford
the same level of protection. The booster
cushion must also be replaced if it is heavily
worn.
NOTE
It is not possible to adjust the booster cush-
ion from stage 2 to stage 1. It must first be
reset by being fully folded into the seat
cushion. Refer to the heading below, Low-
ering the two-stage booster cushion.

Lowering the two-stage booster cushion

Lowering can take place from both the upper
and lower stage to fully lowered position in the
cushion. However, it is not possible to adjust
the booster cushion from the upper stage to
the lower stage.
Pull the handle forwards to release the
cushion.
