Setup Manual
COLOR CAMERA
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS .......................... 2
2. GENERAL DESCRIPTION ........................ 3
3. HANDLING PRECAUTIONS ..................... 3
4. NOMENCLATURE ..................................... 4
5. INSTALLATION ......................................... 5
6. CONNECTIONS ......................................... 6
7. ADJUSTMENT ........................................... 6
Thank you for purchasing TOA's Color Camera. Please carefully follow the instructions in this manual to
ensure long, trouble-free use of your equipment.
INSTALLATION MANUAL
C-CC364 NT
8. ABOUT THE MODE SWITCH .................... 8
9. ABOUT THE DAY/ NIGHT
INPUT TERMINAL ...................... 10
10. ABOUT THE ALARM INPUT
TERMINAL .................................. 10
11. TROUBLESHOOTING .............................. 11
12. SPECIFICATIONS .................................... 12
Advertisement
Table of Contents
Related Manuals for Toa C-CC364 NT
Summary of Contents for Toa C-CC364 NT
-
Page 1: Table Of Contents
TERMINAL ........10 6. CONNECTIONS ......... 6 11. TROUBLESHOOTING ......11 7. ADJUSTMENT ........... 6 12. SPECIFICATIONS ........12 Thank you for purchasing TOA's Color Camera. Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment. -
Page 2: Safety Precautions
• Should the following irregularity be found during use, immediately switch off the power, disconnect the power supply plug from the AC outlet and contact your nearest TOA dealer. Make no further attempt to operate the unit in this condition as this may cause fire or electric shock. -
Page 3: General Description
Modifications Any modifications made to this device that are not approved by TOA Corporation may void the authority granted to the user by the FCC to operate this equipment. -
Page 4: Nomenclature
4. NOMENCLATURE [ Top panel ] [ Side panel ] [ Front panel ] [ Rear panel ] VIDEO OUT DAY/NIGHT V-PHASE ALARM MENU OFF ON F.ADJ 1/60 1/100 CLEAR (1 ) Power input terminal ( 24 VAC, 12 VDC ) (7 ) Video output terminal ( BNC ) ( 2 ) Power indication lamp ( 8 ) Phase control ( V-PHASE ) -
Page 5: Installation
5. INSTALLATION [Ceiling Mounting Example] [Wall Mounting Example] Camera mounting Ceiling surface bracket (optional) Lock lever Camera mounting bracket (optional) Pedestal Camera mount Camera mount Pedestal Camera mounting Lock lever bracket (optional) nstall the unit only in a location that can structurally support the weight of the WARNING unit and the mounting bracket. -
Page 6: Connections
4. Run the coaxial cable. 5. Determine the camera direction and fix it. Set the camera's direction, then fix the camera by rotating the lock lever on the Camera Mounting Bracket. 6. CONNECTIONS Connect the unit's video output terminal to the monitor’s Video IN. Video output terminal Monitor VIDEO OUT... - Page 7 6. Adjust the angle of view with the zoom ring and focus on with the focal ring to get the best possible picture reproduction. • When focusing The object that was brought into focus in bright locations could be out of focus in dark conditions. In such cases, focus the lens after turning the Focus adjustment switch of mode switch to "ON"...
-
Page 8: About The Mode Switch
8. ABOUT THE MODE SWITCH Set each switch to the position that provides the best picture reproduction. [ C-CC364 ] VIDEO OUT DAY/NIGHT Focus adjustment switch F.ADJ V-PHASE ALARM Flickering-reduction switch 1/60 1/100 MENU Synchronization switch OFF ON Synchronization position switch F.ADJ 1/60 1/100... - Page 9 • Synchronization switch One of the following methods can be selected: internal locking (switch position: "INT"), line locking ("LL" position), and vertical external synchronization. Connecting the camera to the equipment with vertical external synchronization automatically switches the camera mode to vertical external synchronization. INT: When synchronization is not required such as using only one camera, set the switch to this position.
-
Page 10: About The Day/ Night Input Terminal
9. ABOUT THE DAY/ NIGHT INPUT TERMINAL Shorting (making) the Day/ Night input terminal forcibly switches the display to B&W mode, which increases the camera’s sensitivity. It is also possible to switch between color and B&W modes on the Camera menu screen. -
Page 11: Troubleshooting
11. TROUBLESHOOTING Possible cause Symptom Remedy No picture is displayed Monitor TV's power is not switched Switch on the main power. on the monitor TV. Cables are not correctly connected. Connect the cables correctly. BNC plug is not correctly soldered. Solder the plug correctly. -
Page 12: Specifications
SPECIFICATIONS [C-CC364] Power Source 24 V AC, 50/ 60 Hz or 12 V DC Power Consumption 1/ 3 type IT-CCD Image Sensor 768 ( H ) x 494 ( V ) ( 380,000 Pixels ) No. of Effective Pixels Scanning System 2:1 interlace Scanning Frequency ( H/ V ) 15,734 kHz / 59.94 Hz...
