Toa CC-3011B Instruction Manual

MANUAL SWITCHER
Thank you for purchasing TOA's Manual Switcher.
Please carefully follow the instructions in this manual in order to ensure long, trouble-free use of your equipment.

SAFETY PRECAUTIONS

•
Before installation or use, be sure to carefully read all the instructions in this section in order to ensure long, trouble-free
operation.
•
Be sure to follow all the precautionary instructions in this section, which contain important warnings regarding safety.
•
After reading, keep this manual handy for future reference.
Safety Symbol and Message Conventions
Safety symbols and messages described below are used in this manual to prevent bodily injury and property damage
which could result from mishandling. Before operating your product, read this manual first so you are thoroughly aware of
the potential safety hazards as well as understand the safety symbols and messages.
WARNING
•
Avoid installing or mounting the unit in unstable locations, such as on a rickety table or a slanted surface. Doing so may
result in the unit falling down and causing personal injury and/or property damage.
CAUTION
•
Do not place heavy objects on the unit as this may cause it to fall or break which may result in personal injury and/or
property damage. In addition, the object itself may fall off and cause injury and/or damage.

GENERAL DESCRIPTION

The CC-3011B and CC-3021B are switchers that select and output one (1) camera video signal out of 6 (CC-3011B) or 12
(CC-3021B) inputs.

HANDLING PRECAUTIONS

•
When the case or panel is dirty, wipe with a soft cloth damped slightly in a neutral cleanser.
Never use such volatile liquids as thinner and benzine because they damage the unit's finish.
• Use the unit in locations where ambient temperature is between - 10 to 50°C and moisture below 90%.
Do not install the unit in locations where dust accumlates or unit may be splashed by water.

NOMENCLATURE

Video input 1
selector switch
Pressing a video input selector switch outputs the camera signal connected to that switch.
Indicates a potentially hazardous situation which could result in death or serious
personal injury if ignored or mishandled.
Indicates a potentially hazardous situation which could result in moderate or minor
personal injury, and/or property damage if ignored or mishandled.
Video input 12
selector switch
INSTRUCTION MANUAL
Video output
Video input connector
connector
CC-3011B
CC-3021B
