SIIG DP FireWire 800 PCI-32T Quick Installation Manual

Hide thumbs Also See for DP FireWire 800 PCI-32T:
Table of Contents

Advertisement

Quick Links

Download this manual
Introducing the DP FireWire 800 PCI-32T
The DP FireWire 800 PCI-32T provides 2 independent hot-
pluggable FireWire 800 (1394b) ports and 1 FireWire 400
(1394a) port with data transfer rates up to 800Mbps.
Features and Benefits
•
Provides 2 FireWire 800 (9-pin) and 1 FireWire 400
(6-pin) ports for multiple device connections
•
Supports IEEE 1394b and backwards compatible
with 1394a-2000 and 1394-1995 standards
•
Supports serial bus data transfer rates of 100, 200,
400 and 800 Mbps
•
Built-in 4-pin power connector provides extra power
when connected to the system power supply
(recommended)
•
Hot-swapping allows you to connect/detach
devices without turning your system off
•
Includes one spare low profile bracket for systems
with low profile chassis
•
Works with DV camcorders, CD-RW/DVD-ROM
drives, scanners, FireWire hard disks, digital
cameras, video game systems and other
audio/video devices
04-0459D
DP FireWire 800 PCI-32T
Quick Installation Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DP FireWire 800 PCI-32T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG DP FireWire 800 PCI-32T

Summary of Contents for SIIG DP FireWire 800 PCI-32T

  • Page 1 DP FireWire 800 PCI-32T Quick Installation Guide Introducing the DP FireWire 800 PCI-32T The DP FireWire 800 PCI-32T provides 2 independent hot- pluggable FireWire 800 (1394b) ports and 1 FireWire 400 (1394a) port with data transfer rates up to 800Mbps.

  • Page 2: System Requirements

    • Windows 7 (32-/64-bit) / Vista (32-/64-bit) / XP ® (32-/64-bit) / Server 2003 & 2008 (32-/64-bit) / 2000 Package Contents • DP FireWire 800 PCI-32T • Spare low profile bracket • Driver CD • Quick installation guide Board Layout...

  • Page 3: Hardware Installation

    Connect an available 4-pin power connector from the system power supply to the 4-pin power connector on the DP FireWire 800 PCI-32T (see Figure 1 on page 2). This connection is recommended for reliable power output. Secure the card and replace the cover.

  • Page 4: Driver Installation

    FireWire 800 PCI-32T drivers. Windows 7 (32-/64-bit) Windows 7 automatically installs it's built-in FireWire 400 driver for the DP FireWire 800 PCI-32T. To get the full speed out of this controller, install the FireWire 800 driver using the directions below.
  • Page 5 Windows 2000 Windows 2000 automatically installs it's built-in 1394a driver for the DP FireWire 800 PCI-32T. To get the full speed out of this controller, install the Firewire 800 driver using the directions below. Insert the driver CD. Click Start, Run. Type D:\setup32.exe, click OK.

  • Page 6: Connecting Devices

    To Verify Windows Installation Check Device Manger to verify installation. For Windows 7 / XP / Server 2003 / 2000: Right click Computer or My Computer, click Manage, click Device Manager. For Windows Vista: Right click Computer, click Manage, click Continue, click Device Manager. For Windows Server 2008: Right click Computer, click Manage,...
  • Page 7 Windows XP At the Found New Hardware Wizard. For XP w/SP2 or later: Select No, not this time, then click Next. For XP w/SP1 or earlier: Go directly to step #2. Select Install the Software Automatically, click Next. Click Continue Anyway. (Skip if not prompted) Click Finish to complete the installation.
  • Page 8 ubSwitch Utility In order to use a DV camcorder with this controller, Microsoft's FireWire 400 driver must be installed in the system. We have supplied an easy to use utility that allows switching between Microsoft's driver and the FireWire 800 driver.
  • Page 9 Blank Page...
  • Page 10 Blank Page...

  • Page 11: Technical Support And Warranty

    • Clearly write your RMA number on the top of the returned package. SIIG will refuse to accept any shipping package, and will not be responsible for a product returned without an RMA number posted on the outside of the shipping carton.
  • Page 12 Fremont, CA 94538-3152, USA Phone: 510-657-8688 DP FireWire 800 PCI-32T is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft, Windows and Windows Vista are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other contries.
