FireWire 800 2-Port
ExpressCard/34
Quick Installation Guide
Introducing the FireWire 800 ExpressCard
The FireWire 800 2-Port ExpressCard/34 adds FireWire 800
(1394b) interface to your ExpressCard equipped notebook
computer.
Features and Benefits
•
Provides 2 FireWire 800 (9-pin) ports for multiple
device connections
•
Supports data transfer rates up to 800Mb/s
•
Supports hot-swap, hot-plug and Plug-n-Play
connection of peripheral devices
•
Works with FireWire devices including DV
camcorders, CD-RW/DVD-ROM drives, portable
hard disks, digital cameras and other audio/video
devices
System Requirements
•
ExpressCard-enabled notebook PC with an available
ExpressCard slot
•
Windows 2000/XP/Server 2003/Vista
Package Contents
•
FireWire 800 2-Port ExpressCard/34
•
Driver CD
•
Quick Installation Guide
04-0448A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireWire 800 2-Port ExpressCard/34 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SIIG FireWire 800 2-Port ExpressCard/34

Summary of Contents for SIIG FireWire 800 2-Port ExpressCard/34

  • Page 1 FireWire 800 2-Port ExpressCard/34 Quick Installation Guide Introducing the FireWire 800 ExpressCard The FireWire 800 2-Port ExpressCard/34 adds FireWire 800 (1394b) interface to your ExpressCard equipped notebook computer. Features and Benefits • Provides 2 FireWire 800 (9-pin) ports for multiple device connections •...

  • Page 2: Hardware Installation

    However, non-powered FireWire devices require this optional power adapter to work. The power adapter can be purchased at SIIG's Online Store, part # NN-ADA011. Hardware Installation General instructions for installing the card are provided below.

  • Page 3: Driver Installation

    FireWire 800 drivers. Windows 2000 Windows 2000 automatically installs it's built-in 1394a driver for the FireWire 800 2-Port ExpressCard/34. To get the full speed out of this controller, install the FireWire 800 driver using the directions below. Insert the driver CD. Click Start, Run. Type D:\setup.exe, click OK.
  • Page 4 At the Welcome screen, click Next. At the License Agreement screen, click Yes. Type in your customer information, then click Next. At the Destination Location screen, click Next. Select Complete, then click Next. At the Program Folder screen, click Next. At the Hardware Installation screen, click Continue Anyway three times, then click Finish.
  • Page 5 Windows Vista Windows Vista automatically installs it's built-in FireWire 400 driver for the FireWire 800 2-Port ExpressCard/34. To get the full speed out of this controller, install the FireWire 800 driver using the directions below. Insert the driver CD. Click Start, Run. Type D:\setup.exe, click OK.

  • Page 6: Removing The Expresscard

    Removing the ExpressCard Stop the ExpressCard before removing it from the ExpressCard slot. The utility is located by the system clock. For Windows 2000: Click the Unplug or Eject Hardware icon. Click Remove PCI standard PCI-to-PCI bridge. For Windows XP/Server 2003/Vista: Click the Safely Remove Hardware icon.
  • Page 7 Select Install the Software Automatically, click Next. Click Continue Anyway. (Skip if not prompted) Click Finish to complete the installation. Server 2003 At the Found New Hardware Wizard, For 2003 w/SP1 or later Select No, not this time, then click Next. For 2003 no service pack installed Go directly to step #2.
  • Page 8 We have supplied an easy to use utility that allows switching between Microsoft's driver and the FireWire 800 driver. Before using this utility, unplug all devices from the FireWire 800 2-Port ExpressCard/34. Click Start, Programs, Unibrain ubcore, Tools then ubSwitch.
  • Page 9 Blank Page...
  • Page 10 Blank Page...

  • Page 11: Technical Support And Warranty

    This product comes with a lifetime manufacturer warranty. Please see SIIG website for more warranty details. If you should happen to have any problems with this product, follow the procedures below. A) If it is within the store's return policy period, please return the product to the store where you purchased from.
  • Page 12 Fremont, CA 94538-3152 FireWire 800 2-Port ExpressCard/34 is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Other names used in this publication are for identification only and may be trademarks of their respective companies.
