Introducing the FireWire ExpressCard

The FireWire ExpressCard easily adds FireWire connectivity
to ExpressCard equipped computers.

Features and Benefits

Provides two FireWire (6-pin) ports & supports up
to 63 devices
Works with DV camcorders, FireWire hard disks,
digital cameras, scanners, CD-RW/DVD drives,
video game sytems, & other audio/video devices
Compliant with 1394a-2000, 1394-1995 standards
ExpressCard/34 form factor works with either
34mm or 54mm ExpressCard slot
Supports serial bus data transfer rates of 100, 200,
400 Mbps
Hot-swapping allows you to connect/detach devices
without first turning your system off

System Requirements

ExpressCard-enabled PC or Mac
an available ExpressCard slot
Windows
2008 (32-/64-bit) / Vista (32-/64-bit)
Mac Os X v10.4 or later
04-0539A
FireWire ExpressCard
Quick Installation Guide
2000 / XP (32-/64-bit) / Server 2003 &
®
notebook with
®
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FireWire ExpressCard and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SIIG FireWire ExpressCard

  • Page 1 FireWire ExpressCard Quick Installation Guide Introducing the FireWire ExpressCard The FireWire ExpressCard easily adds FireWire connectivity to ExpressCard equipped computers. Features and Benefits • Provides two FireWire (6-pin) ports & supports up to 63 devices • Works with DV camcorders, FireWire hard disks, digital cameras, scanners, CD-RW/DVD drives, video game sytems, &...
  • Page 2 Layout Power adapter jack FireWire ports (6-pin) Figure 1: FireWire ExpressCard Note: 1394 devices that have their own power supply do not require the optional power adapter to be connected in order to work. However, non-powered 1394 devices may need this power adapter to work.
  • Page 3: Hardware Installation

    Since the design of systems may vary, refer to your system reference manual for further information, if needed. Insert the FireWire ExpressCard into the ExpressCard slot of your system. Make sure it is inserted all the way in for a solid connection.
  • Page 4 Mac OS X Mac OS will automatically detect and install the correct driver for the FireWire ExpressCard. No additional driver installation is needed. To Verify Mac OS Installation Open System Profiler. Under Hardware, click PCI Cards, an IEEE 1394 Open HCI ExpressCard should be displayed.
  • Page 5 Blank Page...
  • Page 6 Blank Page...
  • Page 7 Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA. If the product is determined to be defective, an RMA number will be issued. Step 2: After obtaining an RMA number, ship the product.
  • Page 8 Fremont, CA 94538-3152, USA Ph: 510-657-8688 FireWire ExpressCard is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. Mac and Mac OS are registered trademarks of Apple, Inc. Other names used in this publication are for identification only and may be trademarks of their respective companies.
