Power Management Block Diagram; Gs64 - Wavecom Gx64 Application Note

Table 1: Type / Variant Configuration
Feature
CHG_IN
VREF as input
VREF as output
ALARM
PON_H
ON/OFF
2.2

Power Management Block Diagram

This section describes the individual implementations in the three different designs;
GS64, GR64001, and GR64002.
Detailed information on the PSC-implementation can be found in 3.2 below
2.2.1

GS64

The GS64 implementation uses all PSC-options listed in Table 1. If a signal is not
used it should be left floating.
The "PM ON/OFF Sequence Logic" block diagram can be found in Figure 5.
Gx64 APPLICATION NOTE
Power Management
Page: 8/30
Type
VCC PSI
PSI/PSC
VUSB PSI
PSI
VRTC PSI
PSC
PSC
PSC
