  • Page 1 Instruction Handbook DC 2118 Digital Multifunctional System...
  • Page 2 Introduction Thank you for your purchase of DC 2118. This Operation Guide is intended to help you operate the machine correctly, perform routine maintenance and take a simple troubleshooting action as necessary, so that you can always use the machine in good condition. Please read this Operation Guide before you start using the machine, and keep it close to the machine for easy reference.

  • Page 3: Table Of Contents

    CONTENTS Names of Parts ....................1-1 Main Body ..........................1-1 Preparations ....................2-1 Loading Paper ..........................2-1 Loading Paper into the Cassette ..................2-2 Cassette Size Detection .....................2-4 Setting Paper in the Multi Purpose Tray ................2-4 Loading postcards or envelopes in the MP tray ...............2-7 MP Tray Size and Media Type ....................2-8 Selecting a Size from Regular Sizes ..................2-8 Selecting a Size from Other Regular Sizes ................2-8...
  • Page 4 Optional Equipment ..................5-1 Document Processor ....................... 5-1 Paper Feeder ........................... 5-2 Duplex Unit ..........................5-2 Key Counter ..........................5-3 Printer Kit / Printer Server ....................... 5-3 Additional Memory ........................5-3 Maintenance ....................6-1 Cleaning the Machine ......................6-1 Replacing the Toner Container and the Waste Toner Box ............6-5 Troubleshooting .....................
  • Page 5 Notice The information in this guide is subject to change without notification. Additional pages may be inserted in future editions. The user is asked to excuse any technical inaccuracies or typographical errors in the present edition. No responsibility is assumed if accidents occur while the user is following the instructions in this guide.
  • Page 6 Energy Saving Contol Function The device comes equipped with a Low Power Mode where energy consumption is reduced after a certain amount of time elapses since the device was last used, as well as a Sleep Mode where printer and fax functions remain in a waiting state but power consumption is still reduced to a minimum when there is no activity with the device within a set amount of time.
  • Page 7 Please read this Operation Guide before using this machine. Keep it close to the machine for easy reference. The sections of this guide and parts of the machine marked with symbols are safety warnings meant to protect the user, other individuals and surrounding objects, and ensure correct and safe usage of the machine.
  • Page 8 symbol indicates that the related section includes information on actions which must be performed. Specifics of the required action are indicated inside the symbol..[Alert of required action] ..[Remove the power plug from the outlet] ..[Always connect the machine to an outlet with a ground connection] Please contact your service representative to order a replacement if the safety warnings in this Operation Guide are illegible or if the guide itself is missing.

  • Page 9: Caution Labels

    IMPORTANT! PLEASE READ FIRST. CAUTION LABELS Caution labels have been attached to the machine at the following locations for safety purposes. Be sufficiently careful to avoid fire or electric shock when removing a paper jam or when replacing toner. Label 2 Label 3 High temperature inside.

  • Page 10: Installation Precautions

    INSTALLATION PRECAUTIONS Environment Caution Avoid placing the machine on or in locations which are unstable or not level. Such locations may cause the machine to fall down or fall over. This type of situation presents a danger of personal injury or damage to the machine. Avoid locations with humidity or dust and dirt.

  • Page 11: Precautions For Use

    If the floor is delicate, when this product is moved after installation, the floor material may be damaged. During copying, some ozone is released, but the amount does not cause any ill effect to one's health. If, however, the machine is used over a long period of time in a poorly ventilated room or when making an extremely large number of copies, the smell may become unpleasant.

  • Page 12: Other Precautions

    Do not damage, break or attempt to repair the power cord. Do not place heavy objects on the cord, pull it, bend it unnecessarily or cause any other type of damage. These types of situations present a danger of fire or electrical shock. Never attempt to repair or disassemble the machine or its parts as there is a danger of fire, electrical shock or damage to the laser.

  • Page 13: Handling Of Plastic Bags

    Do not touch electrical parts, such as connec tors or printed circuit boards. They could be damaged by static electricity. Do not attempt to perform any operations not explained in this handbook. Caution: Use of controls or adjustments or per formance of procedur es other than those Do not look directly at the light from the scanning lamp as it may cause your eyes to feel tired or...

  • Page 14: Safety Of Laser Beam

    SAFETY OF LASER BEAM 1. Safety of laser beam This machine has been certified by the manufacturer to Class 1 level under the radiation performance standards established by the U.S.DHHS (Department of Health and Human Services) in 1968. This indicates that the product is safe to use during normal operation and maintenance.

  • Page 15: Radio Tag Technology

    Safety Instructions Regarding the Disconnection of Power Caution: The power plug is the main isolation device! Other switches on the equipment are only functional switches and are not suitable for isolating the equipment from the power source. Attention: Le débranchement de la fiche secteur est le seul moyen de mettre l’appareil hors tension. Les interrupteurs sur l’appareil ne sont que des interrupteurs de fonctionnement: ils ne mettent pas l’appareil hors tension.
  • Page 16 DECLARATION OF CONFORMITY 89/336/EEC, 73/23/EEC and 93/68/EEC We declare under our sole responsibility that the product to which this declaration relates is in conformity with the following specifications. Limits and methods of measurement for immunity characteristics of information technology equipment EN55024 Limits and methods of measurement for radio interference characteristics of information technology equipment...
  • Page 17 Guide to this Operation Guide This operation guide has the following chapters. The content of these chapters is summarized below to be used as a reference. 1 Names of Parts This chapter contains explanations on the names and functions of the parts of the machine and its operation panel.

  • Page 18: Conventions In This Guide

    Conventions in This Guide The following conventions are used depending on the nature of the description. Convention Description Example [Bold] Indicates the operation panel Press [OK]. keys or a computer screen. Italic Indicates a message displayed Ready to copy is displayed. on the touch panel.

  • Page 19: Originals And Paper Sizes

    Originals and Paper Sizes This section explains the notation used in this guide when referring to sizes of originals or paper sizes. As with A4, B5 and Letter, which may be used either in the horizontal or vertical direction, horizontal direction is indicated by an additional letter R in order to indicate the orientation of the original/paper.

  • Page 20: Names Of Parts

    Names of Parts Main Body Original cover — Open/close this cover when setting the original on the platen. Output tray — Finished copies or printouts are stored on this tray. The output tray has a storage capacity of 250 sheets of standard paper (80 g/m²). Operation panel —...
  • Page 21 Names of Parts 11 Platen — Set an original here for copying. Be sure to lay the original face-down and align the edge of the original flush up against the left rear corner of the platen. 12 Original size indicator plates — Be sure to set an original along these plates when setting it on the platen.
  • Page 22 Names of Parts 19 Main power switch — Turn this switch on ( | ) before using this machine. 20 Main power switch cover — Open to operate the main power switch. 21 Handles for transport — Hold the four recessed portions at the right and left when transporting this machine.

  • Page 23: Operation Panel

    Names of Parts Operation Panel US model 13 16 Start Key (Indicator) Stop/Clear Key Reset Key Energy Saver Key Numeric keys Interrupt Key Logout Key OK Key /Auto%100% Key Paper Supply Indicator Paper Selection Key Paper Supply Level Indicator Paper Misfeed Indicator MP Indicator No.
  • Page 24 Names of Parts European model 13 16 Attention Indicator Error Indicator Add Toner Indicator Maintenance Indicator Image Quality Selection Key Printer Key (Indicator) Press this to switch the message display between copier mode and printer mode, when the optional printer kit is installed. 2-sided Key Mixed Original Size Key Combine Key...

  • Page 25: Message Display

    Names of Parts Message Display The message display on the operation panel shows: • Status information, the messages listed below which are displayed during normal operation. • Error codes, when the printer requires the operator’s attention, refer to chapter „Troubleshooting“. Status Information Message Meaning...

  • Page 26: Automatic Cassette Switching Function

    Names of Parts Automatic Cassette Switching Function If multiple cassettes contain the same size paper and the paper in one cassette runs out during copying, the automatic cassette switching function will switch paper feed from the empty cassette to the other cassette that still contains paper.
  • Page 27 Names of Parts...

  • Page 28: Preparations

    Preparations Loading Paper Paper can be loaded into either the cassette or the multi-purpose tray. Note for Adding Paper After taking new paper out of its packaging, be sure to fan through the paper a few times to separate the sheets before loading that paper into the cassette or the multi-purpose tray.

  • Page 29: Loading Paper Into The Cassette

    Preparations Loading Paper into the Cassette Standard paper, recycled paper, and colored paper can be loaded into the cassette. Up to 300 sheets of standard paper (80 g/m²) or 100 sheets of thick paper (90 to 105 g/m²) can be set. Paper sizes that can be loaded are: A3, B4, A4, A4R, B5, B5R, A5R, Folio, 11 ×...
  • Page 30 Preparations Grasp the paper length adjusting tab and adjust the length guide to the paper size. Important! • Make sure that the length guide is flush against the paper. If there is space between the guide and the paper, set the length guide again. •...

  • Page 31: Cassette Size Detection

    Preparations Affix the label supplied so that the paper size set in the cassette can be identified from the front of the cassette. Gently push in the cassette. Important! When the machine will not be used for a long period of time, remove the paper from the cassette, put it in a storage bag, and seal the bag in order to protect the paper from moisture.
  • Page 32 Preparations Open the multi-purpose tray. Note Pull out the multipurpose tray extension to match the paper size. Adjust the sliders to the width of the paper to be set. Set the paper along the sliders and put it in until it stops.
  • Page 33 Preparations Important! • Always straighten out postcards and other types of thick paper that are curled before using them. The paper may not be fed depending on the paper quality. • When loading paper into the multi-purpose tray, set it with the side which faced the top of its packaging facing down.

  • Page 34: Loading Postcards Or Envelopes In The Mp Tray

    Preparations Loading postcards or envelopes in the MP tray When loading a postcard or envelope, open the paper stopper shown in the figure. For landscape envelopes, close the flap. Insert the envelope all the way along the width guides, keeping the printing side face-down and the edge with the flap facing towards you.

  • Page 35: Mp Tray Size And Media Type

    Preparations MP Tray Size and Media Type Adjust the paper in the MP Tray, register the paper size using the Operation Panel and specify the media type. Selecting a Size from Regular Sizes Press the Paper Selection key for 3 seconds. The System Menu will be displayed.

  • Page 36: Specifying Custom Paper Size

    Preparations Specifying Custom Paper Size Select the Customized Size. (Refer to Selecting a Size from Regular Sizes on page 2-7.), and press the OK key. Press to enter the Length Size. 3.88 to 11.63(")/98 to Non-std size L 297(mm): The range in which setting is possible, and press the 297mm OK key.

  • Page 37: Loading Originals

    Preparations Loading Originals Follow the steps below to load originals for copying or sending. Placing Originals on the Platen You may place books or magazines on the platen in addition to ordinary sheet originals. In addiiton, When copying from an original which cannot be set in the document processor, open the document processor and set the original directly on the platen.

  • Page 38: Loading Originals In The Document Processor

    Preparations Loading Originals in the Document Processor The optional document processor automatically scans each sheet of multiple originals. Both sides of two-sided originals are scanned. Originals Supported by the Document Processor The document processor supports the following types of originals. •...

  • Page 39: How To Load Originals

    Preparations How to Load Originals Before loading originals, be sure that there are no originals left on the original eject table. Originals left on the original eject table may cause the new originals to jam. Adjust the original width guides to fit the originals. Note Before setting originals, make sure that there are no originals remaining on the original eject table.

  • Page 40: Turning Power On

    Preparations Turning Power On To turn machine power on: Open the main power switch cover located on the right side of the machine and turn the main power switch on ( | ). The machine starts to warm up. Once warm-up is completed, the Start indicator lights up green. 2-13...

  • Page 41: User Interface Language

    Preparations User Interface language You can select the language that is used in the message display. Display the System Menu. Press the key or the key to select 02.Language. Press the OK key. Press the key or the key to select the language. Press the OK key. 2-14...

  • Page 42: Basic Operation

    Basic Operation This chapter explains the following operations. • Basic Copying Procedure • Zoom Copying • Duplex Copying • Collated Copying • Combined Copying • Interrupt Copying • Low Power Mode • Auto Sleep Basic Copying Procedure Turn the main power switch on ( | ). At the end of warm-up, the Start indicator lights up green.
  • Page 43 Basic Operation Image quality mode Description Text + Photo Select to copy originals that contain a mixture of both text and photographs. Text Select to copy originals that contain large amounts of text, such as documents, etc. Photo Select to copy originals that contain photographs. Adjust the copy density either manually (manual density mode) or automatically (auto density mode) with automatic detection of the contrast of the original.

  • Page 44: Zoom Copying

    Basic Operation Zoom Copying Copied images can be reduced or enlarged by zooming. The following modes are available for zoom copying. Mode Description Auto zoom ratio selection Original images are reduced or enlarged according to the selected mode paper size. Zoom mode The zoom ratio can be changed from 25 % to 400 % in 1 % increments.

  • Page 45: Manual Zoom

    Basic Operation Manual Zoom The zoom ratio can be manually set between 25 % and 25 % 400 % in 1 % increments. 400 % Set the original. Press the key or the key. The zoom ratio will be displayed in the No. of Copies display. Press the OK key to confirm the zoom ratio.

  • Page 46: Duplex Copying

    Basic Operation Duplex Copying Duplex (two-sided) copies can be made from a variety of originals including double-page spread or two-sided originals. Original Copy Note The optional duplex unit must be installed. The following modes are available for duplex copying: Mode Description One-sided originals are copied onto the front and back sides of the 1-sided->2-sided...
  • Page 47 Basic Operation Mode Description Front and back sides of originals are copied in the same way onto 2 sided->2 sided (2-sided copying from 2-sided both sides of copy paper. originals) Original Copy Note The paper sizes that can be used are A3 to A5R, Folio, 11 × 17" (Ledger), 8 ×...

  • Page 48: 2-Sided Copy Reverse Side Rotation Setting

    Basic Operation 2-Sided Copy Reverse Side Rotation Setting Follow the procedure below to change the rotation setting for the reverse side when making 2-Sided copies. Press the 2-sided key for 3 seconds. 42.Duplex 2nd Rotation On The System Menu for the reverse side setting of 2-Sided Copies will be displayed. Press to select Rotation On in the case where the reverse side is to be rotated or Rotation Off when it isn't to be rotated, and then press the OK key.

  • Page 49: Split Copying

    Basic Operation Split Copying Copy books, magazines, etc. with two facing pages of an open-faced original onto separate sheets of paper. Two-sided to One-sided Copies each side of a two-sided original onto two individual sheets. The optional document processor is required. Original Copy Book to One-sided...

  • Page 50: Collated Copying

    Basic Operation Collated Copying A number of collated copy sets can be produced. Original Copy Note If the optional document processor is installed, you can select whether or not to turn on the sort mode at a default setting. Set the original. Press the Collate key.

  • Page 51: Combined Copying

    Basic Operation Combined Copying Two or four originals are reduced and copied onto a single sheet. Also, borderlines of each original can be marked with solid or dotted lines. Press the Combine key to light up the indicator. Original Copy Note Both the original size and the copy paper size must be standard size.

  • Page 52: In-1

    Basic Operation 2-in-1 The orientations of the originals and the finished copy are shown below. Using the platen: Original Copy Original Copy Using the document processor: Original Copy Original Copy 3-11...

  • Page 53: 4-In-1 (Horizontal)

    Basic Operation 4-in-1 (horizontal) The orientations of the originals and the finished copy are shown below. Using the platen: Original Copy Original Copy Using the document processor: Original Copy Original Copy 3-12...

  • Page 54: 4-In-1 (Vertical)

    Basic Operation 4-in-1 (vertical) The orientations of the originals and the finished copy are shown below. Using the platen: Original Copy Original Copy Using the document processor: Original Copy Original Copy 3-13...

  • Page 55: Interrupt Copying

    Basic Operation Interrupt Copying The interrupt mode temporarily stops the output of copy jobs and allows the output of an urgent copy. After the urgent interrupt job is finished, the interrupted job will be automatically resumed. During a copy job press the Interrupt key. The Interrupt indicator will blink Remove the originals of the ongoing copy job.

  • Page 56: Low Power Mode

    Basic Operation Low Power Mode Pressing the Energy Saver key puts the machine into a resting state (low power mode) even when the main power switch is on. During low power mode, the No. of Copies/Zoom display shows '---'. Press the any key to resume copying operations. The recovery time before copies can be made is 10 seconds.

  • Page 57: Auto Sleep

    Basic Operation Auto Sleep This machine is equipped with the auto sleep function that automatically puts this machine into the sleep mode if no operation has been performed on the machine for a preset period of time. The factory default setting time is one minute. Press the Energy Saver key again to resume copying operations.

  • Page 58: Job Accounting

    Job Accounting Overview of Job Accounting Job Accounting allows you to manage the number of copies for each department through the setting of the Department ID Code separately for each department. This copier has the following features available through the Department ID Code. •...

  • Page 59: Job Accounting Operation Procedures

    Job Accounting Job Accounting Operation Procedures Follow the procedures listed below to operate Job Accounting. Press the Exposure Adjustment keys on both sides for 3 seconds while pressing the Logout key. Job Accounting: will be displayed. Press to select each of the mode displays. NOTE: Refer to each of the following setting procedures and make the settings.

  • Page 60: Deleting Department Id Codes

    Job Accounting Deleting Department ID Codes Deleting a registered Department ID Code. Display Job Accounting. (Refer to Job Accounting Operation Procedures on page -2.) Press to select display 03.Delete code, Job Accounting: and then press the OK key. 03.Delete code Enter the Department ID Code to be deleted using the numeric keys.

  • Page 61: How To Set Job Accounting

    Job Accounting How to set Job Accounting Set Job Accounting to enable or disable it. Display Job Accounting. (Refer to Job Accounting Operation Procedures on page -2.) Press to select display Job Accounting: 01.JobAccounting, and then press the OK key. 01.JobAccounting Press to select On when Job Accounting is to be used and Off when it will...

  • Page 62: Optional Equipment

    Optional Equipment The following options are available for this machine. • Document Processor • Paper Feeder • Duplex Unit • Key Counter • Printer Kit / Printer Server • Additional Memory Document Processor This equipment automatically feeds and scans multiple-sheet originals one by one. Two-sided originals are automatically turned over so that both sides can be scanned.

  • Page 63: Paper Feeder

    Optional Equipment Paper Feeder In addition to the cassette(s) provided with the main body, a paper feeder (with cassettes that can hold 300 sheets each) can be used. • The number of sheets that can be accommodated: 300 sheets (standard paper, 64 to 105 g/m²). •...

  • Page 64: Key Counter

    Optional Equipment Key Counter The key counter is used to confirm the amount of usage of the copier functions. It is useful in managing copier usage for each department, section, etc. as well as in the company overall. Setting the Key Counter Set the key counter securely in the key counter slot.
  • Page 65 Optional Equipment Optional Equipment Overview of Optional Equipment The following optional equipment is available for the machine. Document Processor Additional Memory Duplex Unit Printer Kit Paper Feeder Print server (not in all countries) Key Counter...

  • Page 66: Maintenance

    Maintenance Cleaning the Machine Caution For safety purposes, always remove the power plug from the outlet when performing cleaning operations. Cleaning the Original Cover Open the original cover and wipe the back side of the cover with a soft cloth dampened with alcohol or mild neutral detergent.

  • Page 67: Cleaning The Slit Glasses

    Maintenance Cleaning the Slit Glasses If copies appear soiled, such as black lines appearing on the copy image while using the optional document processor, the slit glasses A and B are dirty. Wipe the slit glasses with a dry soft cloth. Important! Never use water, thinner, organic solvents or alcohol.

  • Page 68: Cleaning The Transfer Roller

    Maintenance Move the brush from the left side to the right side along the separation needle as shown in the illustration to remove any dirt or dust. Close the left cover. Cleaning the Transfer Roller Open the front cover. Remove the cleaning brush. Pull the left cover handle up to open the cover.
  • Page 69 Maintenance While turning the left transfer roller gear to turn the roller as shown in the illustration, move the brush from the left side to the right side along the roller to remove any dirt or dust. Close the left cover.

  • Page 70: Replacing The Toner Container And The Waste Toner Box

    Maintenance Replacing the Toner Container and the Waste Toner Box When message Add toner is displayed on the message display the machine stops. Replace the toner container together with the waste toner box. Notes Add toner only when Add Toner is displayed on the message display. Whenever the toner container is changed, be sure to carry out the procedure described from step 7 on page 6-7 through step 11 on page 6-7.
  • Page 71 Maintenance Use the cap attached to the center of the old waste toner box to cover the opening. Turn the toner container release lever A to the left to pull out the toner container. Caution Do not attempt to incinerate the toner container or the waste toner box. Dangerous sparks may cause burns.
  • Page 72 Maintenance While holding the charger cleaner rod, gently pull it out as far as it will go and push it in again. Repeat this operation two or three times. Note Do not use excessive force to pull the rod or attempt to pull it out completely. While pushing the electrical charge section to the right, pull it out approximately 5 cm (2 inches).
  • Page 73 Maintenance Hold the new toner container vertically and tap the upper part five times or more. Turn the toner container upside down and tap the upper part five times or more. Shake the toner container up and down five times or more.
  • Page 74 Maintenance Close the front cover. After use, always dispose of the toner container and the waste toner box in accordance with Federal, State and Local rules and regulations.
  • Page 75 Maintenance 6-10...

  • Page 76: Troubleshooting

    Troubleshooting If Trouble Occurs If trouble occurs with this machine, carry out the items indicated below. If the trouble persists, contact your service representative. Symptom Items to check Corrective procedure Reference page Nothing is displayed on the Is the power plug connected to an AC Connect the plug to an AC outlet.
  • Page 77 Troubleshooting Symptom Items to check Corrective procedure Reference page Set the image quality mode to Photo. A moire pattern (the Is the original a printed photograph? phenomenon where the dots do not appear to be lined up properly but seem to be grouped together in patterns) appears on the copies.
  • Page 78 Troubleshooting Symptom Items to check Corrective procedure Reference page Copies are blurred. Is this machine used at high humidity? Perform drum refresh. The copies are curled. Is the copy paper wet? Replace the copy paper with dry, new paper. Is Middle 2 set at the Paper type Set Middle 1 at the Paper type (Paper (Paper Weight) setting? (Normally, Weight) setting.

  • Page 79: Responding To Error Messages

    Troubleshooting Responding to Error Messages If the touch panel displays any of these messages, follow the corresponding procedure. Alphanumeric Display Corrective Procedure There is no paper in the cassette. Load paper into the Add paper cassette as displayed in place of #. in cassette #.
  • Page 80 Troubleshooting Display Corrective Procedure Check the key counter and make sure it is set properly. Insert key counter. No Letter/A4 size paper was available in either the No matching cassette or the Paper Feeder (MP tray) at the time when the report was attempted to be output.
  • Page 81 Troubleshooting Display Corrective Procedure Originals were set in the optional Document Processor Reseat originals when copying on 2-sides (front and back sides), when on DP. copying from the platen in 2-Sided copy, 2 in 1, 4 in 1 or when collating copies. Remove the originals from the Document Processor, replace the originals on the Original Table after exiting the front and back copying, 2-Sided copy, 2 in 1, 4 in 1 or Collate Mode and resume...

  • Page 82: Clearing Paper Jams

    Troubleshooting Clearing Paper Jams Stop copying operations when a paper misfeed occurs. When a paper misfeed occurs, the indicator for the location of the paper misfeed will light up on the Operation Panel and either “J” plus a 2-digit number will be displayed as notification of the location of the paper misfeed.

  • Page 83: Notes

    Troubleshooting Notes Warning High voltage is present in the charger section. Take sufficient care when working in this area, as there is a danger of electrical shock. Caution The fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting burned.
  • Page 84 Troubleshooting Notes • Check to see if paper is out of position in the cassette. If the paper is out of position, set the paper properly. • If JAM21 is displayed, remove the jammed paper referring to J20 to J50, J52 to J57, J60, J61: Paper Jam in the Left Cover on page 7-10.
  • Page 85 Troubleshooting Remove any jammed paper without tearing it. Note If the paper does happen to tear, remove any loose scraps from inside the machine. Push the cassette back in firmly. J10: Paper Jam in the Multi-Purpose Tray Perform the following procedure to remove the jammed paper. Remove all of the paper remaining in the multi-purpose tray.
  • Page 86 Troubleshooting Pull the left cover handle up to open the left cover. Caution The fixing unit is extremely hot. Take sufficient care when working in this area, as there is a danger of getting burned. Remove any jammed paper without tearing it. Note If the paper does happen to tear, remove any loose scraps from inside the machine.
  • Page 87 Troubleshooting If jammed paper is seen through the paper output slot, pull it out to remove it. Note If the paper does happen to tear, remove any loose scraps from inside the machine. Pull the left cover handle up to open the left cover. Remove any jammed paper without tearing it.
  • Page 88 Troubleshooting Open the left cover. Remove any jammed original without tearing it. Note If the original does happen to tear, remove any loose scraps from inside the document processor. Failure to do so may cause another paper jam later. Raise the paper feed unit A. Remove any jammed originals without tearing them.
  • Page 89 Troubleshooting 7-14...

  • Page 90: Appendix

    Appendix Specifications Note Specifications are subject to change without notice to reflect improvements in performance. Main Body Copying system Indirect electrostatic system Original types Sheets, books, and 3-dimensional objects (maximum original size: accommodated A3/11 × 17") Copy sizes Cassette A3, B4, A4, A4R, B5, B5R, A5R, Folio, 11 × 17" (Ledger), 8 ×...

  • Page 91: Copier Functions

    Appendix Copier Functions Copying speed Platen (1:1) 18-ppm model A3/11 × 17" (Ledger): 8 sheets/minute B4/8 × 14" (Legal): 8 sheets/minute A4/11 × 8 ": 18 sheets/minute A4R/8 × 11" (Letter): 13 sheets/minute B5: 16 sheets/minute First copy time 5.7 seconds or less (1:1, A4/11 × 8 ") Resolution Scanning: 600 ×...

  • Page 92: Duplex Unit (Optional)

    Appendix Duplex Unit (optional) System Internal type Paper sizes A3, B4, A4, A4R, B5, B5R, A5R, Folio, 11 × 17" (Ledger), 8 × 14" (Legal), 11 × 8 ", 8 × 11" (Letter), 5 × 8 " (Statement), × 13" (Oficio II), 8K, 16K, 16KR Acceptable paper Weight: 64 to 80 g/m²...

  • Page 93: System Menu Items

    Appendix System Menu The copier will enter the System Menu after warm up has been completed or when the Reset key has been pressed. The settings automatically set for the copier in the System Menu are called the Default Settings. These settings can be freely changed to match the usage of the copier.
  • Page 94 Appendix System Menu Items Description Available settings 10.Text Density Adjusts the central exposure value for the copier’s 1(lightest) to manual exposure (Text). 7(darkest) (*4) 11.ReduceStreaks It is possible to make black streaking less noticeable Off* when it appears when using the optional Document Weak Processor.
  • Page 95 Appendix System Menu Items Description Available settings 19.Cassette1Size Automatically detects the paper size in the cassettes Auto Detect mm (1 to 4). (*Metric 20.Cassette2Size When it is to be detected in inches, set this to specifications) AutoDetect inch; when the paper size is to be detected AutoDetect inch 21.Cassette3Size in centimeters, (A⋅B columns) set this to Auto Detect...
  • Page 96 Appendix System Menu Items Description Available settings 24.Custom Size 1 Sets the size to be set to the Custom size (1 to 2). [Inch specifications] This makes it possible to set the sizes that do not A3 R 25.Custom Size 2 appear on the operation panel.
  • Page 97 Appendix System Menu Items Description Available settings 30.CustmMedType1 Sets the paper weights and 2-sided copying to the Paper weights Custom paper. 2-sided copying will be displayed only Extra Heavy 31.CustmMedType2 when the optional Duplex Unit is installed. Heavy 3 Heavy 2 32.CustmMedType3 Heavy 1 Normal 3...
  • Page 98 Appendix System Menu Items Description Available settings 49.Silent mode Shortens the amount of time the internal motor 0, 5, 10, 15, 30 continues to run after the copy is produced. Use this (seconds) (*10) setting in cases when the motor noise is bothersome. 50.Auto Clear Sets the copier so that automatic clearing is executed On: Enabled*...

  • Page 99: System Menu

    Appendix System Menu Operation Procedures Follow the procedures listed below to operate in the System Menu. Press Exposure Adjustment keys on both sides for 3 seconds. System Menu will be displayed. Press to select System Menu Items. System Menu: 00.Setting done NOTE: Each of the System Menu Items can be selected by pressing the numeric keys.
  • Page 100 Index Index Numerics 2 in 1 ............................3-11 4 in 1 (horizontal arrangement) ..................... 3-12 4 in 1 (vertical arrangement) ....................3-13 Additional memory ........................5-3 Auto Clear function ........................1-6 Auto low power function ......................3-15 Auto Sleep ..........................3-16 Auto sleep function .........................
  • Page 101 Index Front cover ..........................1-2 Grounding the machine ......................ii-ix How to set job accounting ......................4-4 If trouble occurs .........................7-1 Image quality mode ........................3-1 Interrupt Copying ........................3-14 Job accounting ...........................4-1 Operation procedures ......................4-2 Key counter ..........................5-3 Language setting ........................2-14 Left cover ............................1-2 Loading paper ..........................2-1 Loading paper into the cassette...
  • Page 102 Index Paper jam ........................... 7-7 Jam location indicators ..................... 7-7 Precaution ........................... 7-7 Paper jam in the document processor .................7-12 Paper jam in the left cover ..................... 7-10 Paper jam in the multi-bypass tray ..................7-10 Paper jam in the paper output slot ..................

  • Page 103: Index

    Index Index-4...
  • Page 104 MEMO...
  • Page 105 MEMO...
  • Page 106 MEMO...
  • Page 107 For best print results and machine performance, we recommend that you use only original TA Triumph-Adler supplies for your TA Triumph-Adler products.
  • Page 108 UTAX GmbH, Ohechaussee 235, 22848 Norderstedt, Germany...
