Summary of Contents for AOpen AX45

  • Page 1: W H A T S I N T H I S M A N U A L

    AX45 / AX45-V DOC. NO.: AX45-OL-E0110A...
  • Page 2: Table Of Contents

    ’ ’ AX45 / AX45-V............................. 1 What’s in this manual ................................2 You Must Notice ..................................8 Before You Start ..................................9 Overview ....................................10 Feature Highlight..................................11 Quick Installation Procedure..............................14 Motherboard Map..................................15 Block Diagram..................................16 Hardware Installation ........................... 17 About “Optional” and “Upgrade Optional”…..........................18 JP14 Clear CMOS Data ................................19...
  • Page 3 AC Power Auto Recovery ................................30 IDE and Floppy Connector ..............................31 IrDA Connector..................................33 Thermal Sensor Connector ..............................34 AGP (Accelerated Graphic Port) Expansion Slot ........................35 WOM (Zero Voltage Wake on Modem) Connector........................36 WOM by External BOX Modem ...............................37 WOM by Internal Modem Card ..............................38 WOL (Wake on LAN)................................39 Support 10/100 Mbps LAN onboard (Optional) ........................41 CNR (Communication and Network Riser) Expansion Slot ......................42...
  • Page 4 Over-current Protection ................................52 Hardware Monitoring ................................53 Resettable Fuse ..................................54 2200µF Low ESR Capacitor ..............................55 Layout (Frequency Isolation Wall) ............................56 Pure Aluminum Heatsink .................................57 Driver and Utility ........................... 58 Auto-run Menu from Bonus CD Disc............................59 Installing LAN Driver (Optional) ...............................60 Installing Onboard Sound Driver..............................61 Installing Hardware Monitoring Utility............................62 ACPI Suspend to Hard Drive ..............................63 ACPI Suspend to RAM (STR)..............................67...
  • Page 5 VGA Card & Hard Disk ................................77 Glossary ..............................78 AC97.......................................78 ACPI (Advanced Configuration & Power Interface)........................78 AGP (Accelerated Graphic Port)..............................78 AMR (Audio/Modem Riser)..............................79 AOpen Bonus Pack CD................................79 APM (Advanced Power Management).............................79 ATA (AT Attachment) ................................79 ATA/66 ....................................79 ATA/100 ....................................80 BIOS (Basic Input/Output System) ............................80 Bus Master IDE (DMA mode) ..............................80...
  • Page 6 EDO (Extended Data Output) Memory ............................82 EEPROM (Electronic Erasable Programmable ROM)......................82 EPROM (Erasable Programmable ROM) ..........................82 EV6 Bus ....................................83 FCC DoC (Declaration of Conformity) .............................83 FC-PGA (Flip Chip-Pin Grid Array) ............................83 Flash ROM....................................83 FSB (Front Side Bus) Clock ..............................84 C Bus....................................84 IEEE 1394....................................84 Parity Bit....................................84 PBSRAM (Pipelined Burst SRAM)............................85...
  • Page 7 RDRAM (Rambus DRAM) ...............................86 RIMM (Rambus Inline Memory Module) ..........................87 SDRAM (Synchronous DRAM)..............................87 Shadow E PROM..................................87 SIMM (Single In Line Memory Module)............................87 SMBus (System Management Bus)............................88 SPD (Serial Presence Detect) ..............................88 Ultra DMA ....................................88 USB (Universal Serial Bus) ..............................89 VCM (Virtual Channel Memory)...............................89 ZIP file.....................................89 Troubleshooting ............................
  • Page 8: You Must Notice

    All of the specifications and information contained in this manual are subject to change without notice. AOpen reserves the right to revise this publication and to make reasonable changes. AOpen assumes no responsibility for any errors or inaccuracies that may appear in this manual, including the products and software described in it.
  • Page 9: Before You Start

    This Online Manual will introduce to the user how this product is installed. All useful information will be described in later chapters. Please keep this manual carefully for future upgrades or system configuration changes. This Online Manual is saved in format, we recommend using Adobe Acrobat Reader 4.0 for online viewing, it is included in Bonus CD disc...
  • Page 10: Overview

    ® Thank you for choosing AOpen AX45 / AX45-V motherboard. The AX45 / AX45-V is Intel Socket 478 motherboard (M/B) based on the ATX form factor featuring the SIS 645 / SIS 961 chipset. As high performance chipset built in the M/B, the AX45 / AX45-V motherboard can ®...
  • Page 11: Feature Highlight

    1056MB/s. AX45 / AX45-V motherboard includes one AGP expansion slot for a bus mastering AGP graphic card. For AD and SBA signaling, AX45 / AX45-V motherboard can support 4X mode. Of six PCI slots provided, all of them are master PCI...
  • Page 12 Memory With SIS 645 / 961 chipset, the AX45 / AX45-V can support Double-Data-Rate (DDR) SDRAM. The DDR SDRAM interface allows zero wait state bursting between the SDRAM and the data buffers at 66/100/133MHz. The six banks of DDR SDRAM can be composed of an arbitrary mixture of 1M/2M4M/8M/16M/32M/64Mx1GB DDR SDRAM and maximum up to 3 GB.
  • Page 13 Dr. LED (Upgrade Optional) Dr. LED has 8 LEDs on this AX45 / AX45-V M/B to easily show what kind of problems you may encounter. Power Management/Plug and Play Supports the power management function that confirms to the power-saving standards of the U.S. Environmental Protection Agency (EPA) Energy Star program.
  • Page 14: Quick Installation Procedure

    This page gives you a quick procedure on how to install your system. Follow each step accordingly. Installing CPU and Fan Installing System Memory (DIMM Connecting Front Panel Cable Connecting IDE and Floppy Cable Connecting ATX Power Cable Connecting Back Panel Cable Power-on and Load BIOS Setup Default Setting CPU Frequency Reboot...
  • Page 15: Motherboard Map

    Motherboard Map Case Open Connector 2Mbit Programmable Flash ROM MODEM-CN PC99 Colored Back Panel Realtek ALC201A CD-IN Front Audio Connector Resettable Fuse 4-pin 12V. ATX Power Connector Thermal Sensor Connector 32-bit PCI Expansion Slot x5 CNR Expansion Slot Realtek RTL8100BL (Optional) 2200μF Low ESR Capacitors WOM (Wake on Modem) Connector...
  • Page 16: Block Diagram

    DDR266/DDR333 DDR SDRAM Up to 1.5GB 32-bit PCI Slot x6 DIMM Socket x3 Socket 478 400MHz System Intel Pentium 4 CPU(Willamette /Northwood) PCI Bus SIS 645 Primary 33/66100 Channel IDE Drive x4 Secondary AGP 4X Slot Channel RealTek ALC201A SIS 961 AC97 CODEC Realtek...
  • Page 17: Hardware Installation

    This chapter describes jumpers, connectors and hardware devices of this motherboard. Note: Electrostatic discharge (ESD) can damage your processor, disk drives, expansion boards, and other components. Always observe the following precautions before you install a system component. Do not remove a component from its protective packaging until you are ready to install it. Wear a wrist ground strap and attach it to a metal part of the system unit before handling a component.
  • Page 18: About "Optional" And "Upgrade Optional

    When you read this online manual and start to assemble your computer system, you may find some of functions are called “Optional”, and some are called “Upgrade Optional”. Though all AOpen motherboards include many amazing and powerful features, in some situations, these powerful features are not used to every user.
  • Page 19: Jp14 Clear Cmos Data

    You can clear CMOS to restore system default setting. To clear the CMOS, follow the procedure below. Turn off the system and unplug the AC power. Remove ATX power cable from connector PWR2. Locate JP14 and short pins 2-3 for a few seconds. Return JP14 to its normal setting by shorting pin 1 &...
  • Page 20: Cpu Installation

    ® This motherboard supports Intel Pentium 4 Socket 478 series CPU (Willamette / Northwood). Be careful of CPU orientation when you plug it into CPU socket. 2. Locate Pin 1 in the socket and look for a black dot or cut edge on the CPU 1.
  • Page 21 3. Press down the CPU socket lever and finish CPU installation. CPU cut edge Note: If you do not match the CPU socket Pin 1 and CPU cut edge well, it may damage the CPU. Note: This socket supports Micro-FC-PGA2 package CPU, which is the latest CPU package developed by Intel.
  • Page 22 This motherboard comes with a retention module attached on the CPU socket when shipped, we strongly recommend you to install AOpen special designed CPU Fan as shown below on the retention module for better heat dissipation. Please install the CPU Fan correctly as the following pictures shown.
  • Page 23: Cpu Jumper-Less Design

    CPU VID signal and SMbus clock generator provide CPU voltage auto-detection and allows the user to set the CPU frequency through the BIOS setup, therefore no jumpers or switches are used. The disadvantages of the Pentium based jumper-less designs are eliminated. There will be no worry of wrong CPU voltage detection.
  • Page 24 This motherboard supports CPU VID function. The CPU core voltage will be automatically detected. BIOS Setup > Frequency/Voltage Control > CPU Clock Setting This motherboard is CPU jumper-less design, you can set CPU frequency through the BIOS setup, and no jumpers or switches are needed. The default setting is "table select mode".
  • Page 25 CPU Core System Ratio Frequency Clock Pentium 4 1.3G 1300MHz 100MHz 400MHz Pentium 4 1.4G 1400MHz 100MHz 400MHz Warning: SIS 645 / 961 chipset supports Pentium 4 1.5G 1500MHz 100MHz 400MHz maximum 400MHz (100MHz*4) system bus Pentium 4 1.6G 1600MHz 100MHz 400MHz and 66MHz AGP clock;...
  • Page 26: Cpu And System Fan Connector (With H/W Monitoring)

    Plug in the CPU fan cable to the 3-pin CPU FAN connector. If you have chassis fan, you can also plug it on System FAN (FAN2) or AUX FAN (FAN3) connector. FAN2 Connector +12V SENSOR CPU Fan Connector Note: Some CPU fans do not have sensor pin, so that cannot support FAN3 Connector hardware monitoring function.
  • Page 27: Dimm Sockets

    This motherboard has three 184-pin DIMM sockets that allow you to install DDR 266 or DDR 333 memory up to 3 GB. Please be noted that for DDR266 memory, you may install them on all of the sockets; but for DDR333 memory, you may install only them on two sockets. DIMM1 DIMM2 DIMM3...
  • Page 28 Please follow the procedure as shown below to finish memory installation. Make sure the DIMM module’s pin face down and match the socket’s size as depicted below. 40 pins 52 pins Insert the module straight down to the DIMM slot with both hands and press down firmly until the DIMM module is securely in place. Note: The tabs of the DIMM slot will close-up to hold the DIMM in place when the DIMM touches the...
  • Page 29: Front Panel Connector

    Attach the power LED, Keylock, speaker, power and reset switch connectors to the corresponding pins. If you enable “Suspend Mode” item in BIOS Setup, the ACPI & Power LED will keep flashing while the system is in suspend mode. Locate the power switch cable from your ATX housing. It is 2-pin female connector from the housing front panel.
  • Page 30: Atx Power Connector

    This motherboard comes with a 20-pin ATX power connector and an extra 4-pin connector as shown below. Make sure you plug in the right direction. We strongly recommend you to insert the 4-pin connector before connecting the 20-pin connector. Ground Pin1 Ground PS-ON...
  • Page 31: Ide And Floppy Connector

    Connect 34-pin floppy cable and 40-pin IDE cable to floppy connector FDC and IDE connector. The blue connector is IDE1 for clear identification. Be careful of the pin1 orientation. Wrong orientation may cause system damage. Pin 1 Primary Primary Master Slave (2nd) (1st) IDE 1 (Primary)
  • Page 32 IDE1 is also known as the primary channel and IDE2 as the secondary channel. Each channel supports two IDE devices that make a total of four devices. In order to work together, the two devices on each channel must be set differently to Master and Slave mode. Either one can be the hard disk or the CDROM.
  • Page 33: Irda Connector

    The IrDA connector can be configured to support wireless infrared module, with this module and application software such as Laplink or Windows 95 Direct Cable Connection, the user can transfer files to or from laptops, notebooks, PDA devices and printers. This connector supports HPSIR (115.2Kbps, 2 meters) and ASK-IR (56Kbps).
  • Page 34: Thermal Sensor Connector

    With the increasing performance of system, the components nowadays always generate enormous heat in your system, such as CPU, VGA card, HDD, and so on. This motherboard provides thermal sensor for users to detect the temperature of any components. You may just connect a sensor on this connector to sense any possible overheating components.
  • Page 35: Agp (Accelerated Graphic Port) Expansion Slot

    The AX45 / AX45-V provides an 4x slot. The AGP 4x is a bus interface targeted for high-performance 3D graphic. AGP supports only memory read/write operation and single-master single-slave one-to-one only. AGP uses both rising and falling edge of the 66MHz clock, for...
  • Page 36: Wom (Zero Voltage Wake On Modem) Connector

    Pin 1 WOM Connector +5VSB...
  • Page 37: Wom By External Box Modem

    Serial Port (Modem Side) Pin 1 Serial Port (Motherboard Side)
  • Page 39: Wol (Wake On Lan)

    To use Wake On LAN function, you must have a network card with chipset that supports this feature, and connect a cable from LAN card to motherboard WOL connector. The system identification information (probably IP address) is stored on network card and because there is a lot of traffic on the Ethernet, you need to install network management software, such as ADM, for the checking of how to wake up the system.
  • Page 40 WOL Connector (Ethernet Card Side) WOL Connector (Motherboard Side)
  • Page 41: Support 10/100 Mbps Lan Onboard (Optional)

    The South Bridge SIS961 includes a fast Ethernet controller on chip. On the strength of Realtek 8100BL LAN controller on board, which is a highly-integrated Platform LAN Connect device, it provides 10/100M bps Ethernet for office and home use, the Ethernet RJ45 connector is located on top of USB connectors.
  • Page 42: Cnr (Communication And Network Riser) Expansion Slot

    is a riser card specification to replace the AMR (Audio/Modem Riser) that supports V.90 analog modem, multi-channel audio, and phone-line based networking. Owing to CPU computing power getting stronger, the digital processing job can be implemented in main chipset and share CPU power. The analogy conversion (CODEC) circuit requires a different and separate circuit design, which is put on CNR card.
  • Page 43: Pc99 Color Coded Back Panel

    The onboard I/O devices are PS/2 Keyboard, PS/2 Mouse, RJ-45 LAN Connector (Optional), COM1 and COM2, Printer, USB, AC97 sound and game ports. The view angle of drawing shown here is from the back panel of the housing. RJ-45 LAN SPP/EPP/ECP Connector MIDI/Game Port...
  • Page 44: Support 3 Usb Ports

    This motherboard provides six connectors to connect USB devices, such as mouse, keyboard, modem, printer, etc. There are two connectors on the PC99 back panel. You can use proper cable to connect other USB connectors to the back panel or front panel of chassis. Pin 1 USB_FP_OC0 USB_ FP_P0+...
  • Page 45: Chassis Intrusion Connector

    The “CASE OPEN” header provides chassis intrusion-monitoring function. To make this function works, you have to enable it in the system BIOS, connect this header to a sensor somewhere on the chassis. So, whenever the sensor is triggered by lights or the opening of the chassis, the system will send out beep sound to inform you.
  • Page 46: Cd Audio Connector

    This connector is used to connect CD Audio cable from CDROM or DVD drive to onboard sound. CD-IN...
  • Page 47: Modem Audio Connector

    This connector is used to connect Mono In/MIC Out cable from internal modem card to onboard sound circuit. The pin 1-2 is Mono In, and the pin 3-4 is MIC Out. Please note that there is no standard for this kind of connector yet, only some internal modem cards implement this connector.
  • Page 48: Front Audio Connector

    If the housing has been designed with an audio port on the front panel, you’ll be able to connect onboard audio to front panel through this connector. By the way, please remove 5-6 and 9-10 jumper caps from the Front Audio Connector before connecting the cable. Please do not remove these 5-6 and 9-10 yellow jumper caps if there’s no audio port on the front panel.
  • Page 49: Dr. Led Connector (Upgrade Optional)

    In conjunction with Dr. LED (Upgrade Optional), which can easily shows what kind of problems may occur on your system during assembly. It can clearly indicate whether there is a component issue or an installed issue by the 8 LEDs on the front panel of Dr. LED. This can helps you to have a self-diagnostic to your system status quickly.
  • Page 50 Dr. LED is a CD disc storage box with 8 LEDs on its front panel, the size of Dr. LED is exactly the same as 5.25 in floppy drive, so that it can be mount into normal 5.25 in drive bay of any housing. Floppy Boot O.K.
  • Page 51: Battery-Less And Long Life Design

    This Motherboard implements Flash ROM and a special circuit that allows you to save your current CPU and CMOS Setup configurations without the need of a battery. The RTC (real time clock) can also keep running as long as the power cord is plugged. If you lose your CMOS data by accident, you can just reload the CMOS configurations from Flash ROM and the system will recover as usual.
  • Page 52: Over-Current Protection

    Note: Although we have implemented protection circuit try to prevent any human operating mistake, there is still certain risk that CPU, memory, HDD, add-on cards installed on this motherboard may be damaged because of component failure, human operating error or unknown nature reason. AOpen cannot guaranty the protection circuit will always work perfectly.
  • Page 53: Hardware Monitoring

    CPU temperature. If any of these systems’ status goes wrong, there will be an alarm through the chassis external speaker or buzzer of motherboard (if existed) to warn the user. Fan Speed AOpen H/W Detection Monitoring...
  • Page 54: Resettable Fuse

    Traditional motherboard has fuse for Keyboard and port to prevent over-current or shortage. These fuses are soldered onboard that when it is broken (function as protecting the motherboard), user still cannot replace it and the motherboard is still malfunctioning. With expensive Resettable Fuse, the motherboard can be resumed back to normal function after the fuse had done its protection job. Resettable Fuse...
  • Page 55: 2200Μf Low Esr Capacitor

    CPU power. The idea of where to put these capacitors is another know-how that requires experience and detail calculation. Not only that, AX45 / AX45-V implements 2200μF capacitors, which is much larger than normal capacitor (1000 & 1500μf) and it provides...
  • Page 56: Layout (Frequency Isolation Wall)

    CPU working in stable condition. The layout of this motherboard implements AOpen’s unique design called “ Frequency Isolation Wall”. Separating each critical portion of motherboard into regions where each region...
  • Page 57: Pure Aluminum Heatsink

    Cool down CPU and Chipset is important for system reliability. Aluminum heat sink provides better heat consumption especially when you are trying to over clocking the CPU.
  • Page 58: Driver And Utility

    There are motherboard drivers and utilities included in AOpen Bonus CD disc. You don’t need to install all of them in order to boot your system. But after you finish the hardware installation, you have to install your operation system first (such as Windows 98) before you can install any drivers or utilities.
  • Page 59: Auto-Run Menu From Bonus Cd Disc

    You can use the auto-run menu of Bonus CD disc. Choose the utility and driver and select model name.
  • Page 60: Installing Lan Driver (Optional)

    8100BL You can install LAN Driver under Windows95/98, Windows NT and Windows 2000 for Real PCI Fast Ethernet adapter by following steps. Installing driver procedure on Microsoft Windows 95 : ----------------------------------------------------- 1. Select "Driver from disk provided by hardware manufacturer" when being asked which driver you would like to install. 2.
  • Page 61: Installing Onboard Sound Driver

    This motherboard comes with a RealTek ALC201 AC97 CODEC. You can find the audio driver from the Bonus Pack CD disc auto-run menu.
  • Page 62: Installing Hardware Monitoring Utility

    You can install Hardware Monitoring Utility to monitor CPU temperature, fans and system voltage. The hardware monitoring function is automatically implemented by the BIOS and utility software. No hardware installation is needed.
  • Page 63: Acpi Suspend To Hard Drive

    ACPI Suspend to Hard Drive is basically controlled by Windows operation system. It saves your current work (system status, memory and screen image) into hard disk, and then the system can be totally power off. Next time, when power is on, you can resume your original work directly from hard disk within few seconds without go through the Windows booting process and run your application again.
  • Page 64: System Requirement

    System Requirement AOZVHDD.EXE 1.30b or later. Delete config.sys and autoexec.bat. Fresh installation of Windows 98 on a new system 1. Execute "Setup.exe /p j" to install Windows 98 2. After Windows 98's installation is complete, go to the Control Panel > Power Management. a.
  • Page 65 Changing from APM to ACPI (Windows 98 only) 1. Run "Regedit.exe" a. Go through the following path HKEY_LOCAL_MACHINE SOFTWARE MICROSOFT WINDOWS CURRENT VERSION DETECT b. Select "ADD Binary" and name it as "ACPIOPTION". c. Right click and select Modify, add "01" after "0000" to make it "0000 01". d.
  • Page 66 4. Run "Add New Hardware" again and it will find "Advanced Power Management Resource". 5. Click "OK". Tip: Currently we found only ATI 3D Rage Pro AGP card would support ACPI suspend to disk. Please refer to AOpen web site for latest update...
  • Page 67: Acpi Suspend To Ram (Str)

    This motherboard supports ACPI Suspend to RAM function. With this function, you can resume your original work directly from DRAM without going through the Windows 98 booting process and run your application again. Suspend to DRAM saves your current work in the system memory, it is faster than Suspend to Hard Drive but requires power supplied to DRAM, while Suspend to Hard Drive requires no power.
  • Page 68 To implement ACPI Suspend to DRAM, please follow the procedures as below: System Requirement An ACPI OS is required. Currently, Windows 98 is the only choice. Please refer to ACPI Suspend to Hard Drive of how to setup Windows 98 ACPI mode. Procedures Changed the following BIOS settings.
  • Page 69: Award Bios

    Most BIOS setting of AX45 / AX45-V had optimized by AOpen’s R&D engineering team. But, the default setting of BIOS still can’t fine-tune the chipset controlling entire system. Hence, the rest of this chapter is intended to guide you through the process of configuring your system using setup.
  • Page 70: About Bios Function Description

    … AOpen always dedicates to give users a more friendly computer system. Now, we include all function descriptions of BIOS setup program into the BIOS Flash ROM. When you select one function of BIOS setup program, the function description will appeared at right side of screen.
  • Page 71: How To Use Award™ Bios Setup Program

    The following table provides details about how to use keyboard in the Award™ BIOS setup program. By the way, all products of AOpen also provides a special function in the BIOS setup, you can press <F3> key selecting preferred menu language to display.
  • Page 72 Load fail-save setting value from CMOS. Load turbo setting value from CMOS. Save changed setting and exit setup program. Note: AOpen always dedicates to give users a more friendly computer system. Now, we include all function descriptions of BIOS setup program into the BIOS Flash ROM.
  • Page 73: How To Enter Bios Setup

    After you finish the setting of jumpers and connect correct cables. Power on and enter the BIOS Setup, press <Del> during POST (Power-On Self Test). Choose "Load Setup Defaults" for recommended optimal performance. Warning: Please avoid of using "Load Turbo Defaults", unless you are sure your system components (CPU, DRAM, HDD, etc.) are good enough for turbo setting.
  • Page 74: Bios Upgrade

    Caution: AOpen Easy Flash BIOS programs are designed to be compatible with the Award BIOS. At the date of this note, AOpen Easy Flash BIOS programs are not available for AMI BIOS. AMI BIOS appears mostly only on old 486 boards and some early Pentium boards.
  • Page 75 Below are the steps for easy flashing procedures: (applies for Award BIOS ONLY) 1. Download new BIOS upgrade file from AOpen's web site. For example, AX45102.ZIP. 2. Run shareware PKUNZIP (http://www.pkware.com/) which supports miscellaneous operation systems to extract the binary BIOS file and the flash utility.
  • Page 76: Overclocking

    As a leading manufacturer in motherboard industry, AOpen always listens to what customers want and develop products to fit different user's requirements. Reliability, compatibility, leading technology and friendly features are our basic goals when designing motherboards. Other than above mentioned design criteria, there are power users who are always seeking to push the limitation of the system performance by overclocking which we call them "Overclocker".
  • Page 77: Vga Card & Hard Disk

    VGA and HDD is key components for overclocking, for your reference, the following list are what have been successful overclocked in our lab. Please note that AOpen can not guaranty they can be successful overclocked again. Please check the Available Vendor List (AVL) by link to our official website.
  • Page 78: Glossary

    AGP uses both rising and falling edge of the 66MHz clock, for 2X AGP, the data transfer rate is 66MHz x 4byte x 2 = 528MB/s. AGP is now moving to 4X mode, 66MHz x 4byte x 4 = 1056MB/s. AOpen is the first company to support 4X AGP...
  • Page 79: Amr (Audio/Modem Riser)

    Unlike ACPI, BIOS controls most APM power management functions. AOpen Suspend to Hard Drive is a good example of APM power management. ATA is the specification of diskette interface. In 80’s, many software and hardware manufacturers instituted the ATA specification together.
  • Page 80: Ata/100

    ATA/100 is a new IDE specification under developing. ATA/100 uses both rising edge and falling edge as ATA/66 but clock cycle time is reduced to 40ns. The data transfer rate is (1/40ns) x 2 bytes x 2 = 100MB/s. To use ATA/100, you need special 80-wire IDE cable, the same as ATA/66.
  • Page 81: Codec (Coding And Decoding)

    Normally, CODEC means a circuit that can do digital to analog conversion and also the analog to digital conversion. It is part of AC97 sound/modem solution. DDR SDRAM utilizes the existing DRAM infrastructure and technology while doubling the nominal bandwidth available to systems in an easy to design and simple to adopt way.
  • Page 82: Ecc (Error Checking And Correction)

    The ECC mode needs 8 ECC bits for 64-bit data. Each time memory is accessed; ECC bits are updated and checked by a special algorithm. The ECC algorithm has the ability to detect double-bit error and automatically correct single-bit error while parity mode can only detect single-bit error.
  • Page 83: Ev6 Bus

    Flash ROM can be re-programmed by electronic signals. It is easier for BIOS to upgrade by a flash utility, but it is also easier to be infected by virus. Because of increase of new functions, BIOS size is increased from 64KB to 256KB (2M bit). AOpen AX5T is the first board to implement 256KB (2Mbit) Flash ROM.
  • Page 84: Fsb (Front Side Bus) Clock

    FSB Clock means CPU external bus clock. CPU internal clock = CPU FSB Clock x CPU Clock Ratio See SMBus. IEEE 1394 is a low-cost digital interface originated by Apple Computer as a desktop LAN and developed by the IEEE 1394 working group. The IEEE 1394 can transport data at 100, 200 or 400 Mbps.
  • Page 85: Pbsram (Pipelined Burst Sram)

    For Socket 7 CPU, one burst data read requires four QWord (Quad-word, 4x16 = 64 bits). PBSRAM only needs one address decoding time and automatically sends the remaining QWords to CPU according to a predefined sequence. Normally, it is 3-1-1-1, total 6 clocks, which is faster than asynchronous SRAM.
  • Page 86: Pdf Format

    A file format for electronic document, PDF format is independent from platform, you can read PDF file under Windows, Unix, Linux, Mac … with different PDF reader. You can also read PDF file by web browser such as IE and Netscape, note that you need to install PDF plug-in first (Included in Acrobat Reader).
  • Page 87: Rimm (Rambus Inline Memory Module)

    SDRAM comes in 64-bit 168-pin DIMM and operates at 3.3V. AOpen is the first company to support dual-SDRAM DIMMs onboard (AP5V), from Q1 1996 A memory space in Flash-ROM to simulate E PROM operation, AOpen motherboard uses Shadow E...
  • Page 88: Smbus (System Management Bus)

    SMBus is also called I2C bus. It is a two-wire bus developed for component communication (especially for semiconductor IC). For example, set clock of clock generator for jumper-less motherboard. The data transfer rate of SMBus is only 100Kbit/s, it allows one host to communicate with CPU and many masters and slaves to send/receive message.
  • Page 89: Usb (Universal Serial Bus)

    USB is a 4-pin serial peripheral bus that is capable of cascading low/medium speed peripherals (less than 10Mbit/s) such as keyboard, mouse, joystick, scanner, printer and modem. With USB, the traditional complex cables from back panel of your PC can be eliminated. NEC’s Virtual Channel Memory (VCM) is a new DRAM core architecture that dramatically improves the memory system’s ability to service multimedia requirements.
  • Page 90: Troubleshooting

    If you encounter any trouble to boot you system, follow the procedures accordingly to resolve the problem. Start Turn off the power and unplug the AC power cable, then remove all of the add-on cards and cables, including VGA, IDE, FDD, COM1, COM2 and printer. Make sure if all jumper settings are correct.
  • Page 91 Continue Install the VGA card. Then connect your monitor and keyboard. Turn on the power and check if the power supply and CPU fan work properly. The problem is probably caused by power supply or motherboard failure. Next Please contact your reseller or local distributor for repairing.
  • Page 92 Continue Perhaps your VGA card Check if there is display? or monitor is defective. Press <Ctrl> and <Alt> key at the same time, hold them and then press <Del> to reboot the system. It is very possible that your Check if the system keyboard is defective.
  • Page 93 Continue During system rebooting, press <Del> to enter BIOS setup. Choose “Load Setup Default”. Turn off the system and re-connect IDE cable. The problem should be Check if the system can caused by the IDE cable reboot successfully? or HDD itself.
  • Page 94: Technical Support

    Dear Customer, Thanks for choosing AOpen products. To provide the best and fastest service to our customer is our first priority. However, we receive numerous emails and phone-calls worldwide everyday, it is very hard for us to serve everyone on time. We recommend you follow the procedures below and seek help before contact us.
  • Page 95 5 5 5 5 5 5 5 5 News Group: Your problem probably had been answered by our support engineer or professional users on the news group. http://www.aopen.com/tech/newsgrp/default.htm 6 6 6 6 6 6 6 6 Contact Distributors/Resellers: We sell our products through resellers and integrators. They should know your system configuration very well and should be able to solve your problem efficiently and provide important reference for you if next time you want to buy something else from them.
  • Page 96 Model name and BIOS version can be found on upper left corner of first boot screen (POST screen). For example: AX45 R1.20 Feb.01.2001 AOpen Inc. Award Plug and Play BIOS Extension v1.0A Copyright © 1998, Award Software, Inc. AX45 is model name of motherboard; R1.20 is BIOS version.
  • Page 97: Product Registration

    Be able to join the discussions of web-based news groups. AOpen makes sure that the information you provide is encrypted, so that it cannot be read or intercepted by other people or companies. Further, AOpen will not disclose any of information you submitted under any conditions. Please consult our...
  • Page 98: How To Contact Us

    Please do not hesitate contact us if you have any problem about our products. Any opinion will be appreciated. Pacific Rim Europe America AOpen America Inc. AOpen Inc. AOpen Computer b.v. Tel: 886-2-3789-5888 Tel: 31-73-645-9516 Tel: 1-510-498-8928 Fax: 1-408-922-2935 Fax: 886-2-3789-5899...
