Specifications; Axp-Dtc; Overview - AMX Camrobotics Instruction Manual

Figure 10

AXP-DTC

Figure 11
AXP-DTC specifications
Camrobotics

Specifications

Overview

Figure 10 shows the AXP-DTC and Figure 11 lists its specifications. Figure 12 shows
the CAM-1000 and Figure 13 lists its specifications. Figure 14 shows the mounting
pattern for the CAM-1000. Refer to the AXB-EM232 and AXB-CAM instruction
manuals for those specifications.
AXP-DTC
Specifications
Dimensions (HWD) 1.8" (front) x 4.5" (rear) x 15.0" x 9.0"
(46 mm [front] x 114 mm [rear] x 381 mm x 229 mm)
Weight 11 lb (5.0 kg)
Enclosure Type Metal with white and gray matte finish
Power US-style three-conductor line cord 120 VAC 50/60 Hz
Connector 15-pin female D (AXlink)
Specifications 19
