English Table of Contents Usage Notice Precautions ..................2 Introduction About the Product ................. 3 Package Overview ................4 Installation Product Overview ................. 5 Start Your Installation ................7 Powering On/Off the Projection Display..........9 Adjusting the Image Size ..............10 User Controls User Control Overview ................. -
Page 2: Usage Notice
English Usage Notice Do not look into the lens. The bright light may hurt your eyes. Warning- To reduce the risk of fire or electric shock, do not expose this Warning- product to rain or moisture. Please do not open or disassemble the product as this may cause Warning- electric shock. -
Page 3: Introduction
English Introduction About the Product This video projection display, designed with a high-powered metal halide lamp, has its outstanding features as follows: 10.34lbs (4.7 kg) lightweight compact design 330-watt user replaceable metal-halide lamp Single panel 6.4” TFT LCD projection system 800 x 600 addressable pixels 16.7M (24-bit) displayable colors NTSC/ NTSC 4.43/ PAL/ SECAM composite video &... -
Page 4: Package Overview
English Package Overview This projection display comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. Power Cord LCD Projection Display Composite Video Cable S-Video Cable Audio-in Cable User’s Manual Warranty Card Carrying Case... -
Page 5: Installation
English Installation Product Overview Main Unit Lens Panel Control Buttons Keystone Correction Lens Latch Lamp Door Carrying Handle Elevator Foot Lamp Latch Rear Connection Ports Power Switch Audio Outputs Audio Inputs Power S-Video Connector Connector Composite Video Composite Video Connector Connector Fuse Audio Inputs... -
Page 6: Remote Control
English Remote Control Reset All Power on/Standby Freeze POWER ON FREEZE STANDBY RESET All Sharpness Color COLOR SHARPNESS TINT Tint Brightness CONTRAST BRIGHTNESS SOURCE Source selection Contrast VOLUME Volume MUTE Directional select keys MENU ENTER Enter On-Screen menus * For more detailed information, please refer to “Function Descriptions” on page 13. -
Page 7: Start Your Installation
English Start Your Installation Connecting the Projection Display Refer to the installation figure shown below. Power Cord Audio Cable S-Video Cable Composite Video Cable Audio Cable... -
Page 8: Powering On/Off The Projection Display
English Powering On/Off the Projection Display Powering On the Projection Display. Switch on the power; then turn on the lamp by pressing “STANDBY” button. Press the “ I ” side of the power switch to turn on the projection display. After a few seconds, press the “Power on/Standby”... -
Page 9: Adjusting The Image Size
English Adjusting the Image Size Positioning the projection display Projection 5 ft. 6.5 ft. 9.5 ft. 13 ft. 20 ft. Distance (1.5 m) (2 m) (3 m) (4 m) (6 m) 160" 40" 60" 80" 110" Image Size (4.06m) (1.01m) (1.52m) (2.03m) (2.79m) -
Page 10: User Controls
English User Controls User Control Overview There are two ways for you to control the functions: panel control and remote control. Panel Control POWER ON RESET STANDBY MENU ENTER 4 Directional Keys Remote Control Reset All Freeze Power on/Standby POWER ON RESET ALL FREEZE STANDBY... -
Page 11: Osd Menus
English OSD Menus The OSD (On-Screen Display) menus will allow you to easily adjust the display functions. Refer to the following table to find out the location of your adjusting items. Main Menu Sub Menu Language English French German Spanish Italian Source Video 1, Video 2, S-Video... - Page 12 English The way to open the OSD menus will be as follows: Main Menu: Press “MENU” button to pop up the OSD Main Menu. There will be six sub- menus of “Language”, “Source”, “Picture”, “Audio”, “Lamp” and “Reset All” you to easily adjust the screen images. Main Menu Language Source...
-
Page 13: Function Descriptions
English Function Descriptions Basic Functions: Press the “Power On/Standby” button to turn on the Power On/Standby projection lamp. Menu Press “Menu” button to pop up the OSD menu. Enter “Enter” is used for confirming your selection. Four Directional button to select items. Use to make adjustments for your selection. - Page 14 English Contrast To adjust the contrast of the image, select “Contrast” from OSD menus or the remote control. Color To adjust the color of the image, select “Color” from OSD menus or the remote control. Tint To adjust the tint of the image, select “Tint” from OSD menus or the remote control.
- Page 15 English Treble Use this function to control the treble level. Bass Use this function to control the bass level. Mode There are four modes for your choices: Spatial Stereo, Pseudo Stereo, Linear Stereo, and Forced Mono. Lamp Functions Lamp Warning Choose this function to show or hide the warning message.
-
Page 16: Appendices
English Appendices Troubleshooting If you are experiencing trouble with the projection display, refer to the follows. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Press “Power on/Standby” button. Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”... -
Page 17: Maintenance
English Maintenance w Changing the Lamp The projection display will detect the lamp life itself. It will show you a warning message when the lamp is used over working hours. When you see this message, change the lamp as soon as possible. Make sure the projection display has cooled for at least 30 minutes before change the lamp. - Page 18 English 3. Unscrew the two screws on the bottom of the lamp module. Then release the head screw of the lamp module. Bottom Screws Head Screw 4. Take out the used lamp from the usage position. Take out the head of the lamp first and then the bottom.
- Page 19 English w Changing the Fuse Fuse Holder the Blown Fuse Fuse Changing Procedure: 1. Switch off the power and unplug the power cord. 2. Pull out the fuse holder. 3. Remove the blown fuse and then insert a new fuse. 4.
-
Page 20: Specifications
English Specifications LCD Panel - active matrix TFT color LCD - 6.4” panel x 1 - tr=30ms, tf=50ms response time - 200:1 contrast ratio Lamp - 330-watt metal halide Display Resolution - 800 pixels(H) x 600 lines(V) Displayable Color - 16.7M colors Image Size - 40”...
