Integral cold carbonation ice and beverage dispensers

Advertisement

Quick Links

VU300K Series Integral Cold Carbonation
Order parts online
www.follettice.com
Following installation, please forward this manual
Ice and Beverage Dispensers
Installation, Operation and Service Manual
to the appropriate operations person.
801 Church Lane • PO Box D, Easton, PA 18044, USA
Toll free (800) 523-9361 • (610) 252-7301
Fax (610) 250-0696 • www.follettice.com
Service numbers above 50000
U L
U L
®
C
®
00119628R01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 00119628R01 and is the answer not in the manual?

Questions and answers

Summary of Contents for Follett 00119628R01

  • Page 1 801 Church Lane • PO Box D, Easton, PA 18044, USA Toll free (800) 523-9361 • (610) 252-7301 Fax (610) 250-0696 • www.follettice.com Ice and Beverage Dispensers Installation, Operation and Service Manual Service numbers above 50000 ® ® 00119628R01...
  • Page 3: Table Of Contents

    Follett receives the equipment at the factory in Easton, PA within 30 days of the issue of the return authorization number. The equipment must be returned in Follett packaging. If the packaging has been damaged or discarded, Follett will forward, at the customer’s expense, new packaging.
  • Page 4: Welcome To Follett

    Before you begin After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if necessary.
  • Page 5: Specifications

    Drains should be hard piped and insulated. Maintain at least 1/4" per foot (6mm per 304mm run) slope on drain line run. Water disconnect within 10 feet (3m) of dispenser is suggested for automatic load units. Follett recommends use of a Follett model AFSYSTMFL4S water filter on icemakers connected to automatic fill dispensers. Icemaker...
  • Page 6 Dimensions and clearances VU300 series Required clearances 60" (1524mm) minimum above counter for installation if dispenser will be dropped into counter 49" (1245mm) minimum above counter for auger removal 12" (305mm) minimum on ice chute side for service 12" (305mm) minimum on side opposite ice chute if ice transport tube enters this side 12"...
  • Page 7: Installation

    Installation Installing dispenser in counter Note: All dispensers must be supported from below with supplied 4" – 6" (102 – 153mm) adjustable leg accessory, or equivalent. Do not hang dispenser on flange. All dispensers must be installed level in both directions to ensure proper operation. 1.
  • Page 8: Field Wiring Diagrams

    Field wiring diagrams Note: Field wiring diagrams are intended to aid electricians or technicians in understanding how equipment works. All field wiring must be installed in accordance with all local and NEC codes. If attaching optional icemaker accessory DISPENSER LEFT JUNCTION BOX RIGHT JUNCTION BOX Electric Power...
  • Page 9: Installing Optional Icemaker

    3. For manual load units, remove front drain pan or rear lid and fill storage area with approved ice. Note: Follett manual load dispensers can accommodate most cube/cubelet ices up to 1" (26mm) square, or Follett compressed nugget ice. Crushed, flake, bagged, nugget or congealed ice cannot be used. Use of these ices can jam dispenser and void warranty.
  • Page 10: Operation

    How the dispenser works Follett’s dispensers may be fed by Follett remote icemakers or manually loaded (using ice from another source). In all models, ice is stored below the counter in the dispenser storage area. When the dispense lever or button is pushed, the dispense motors are activated.
  • Page 11: Cleaning

    Cleaning Using solutions below, clean and sanitize storage area and beverage lines before starting unit and on a routine basis as noted below. Note: Always disconnect power before cleaning dispenser. Do not run plastic parts through a dishwasher. Solution A: Combine 1 oz (250ml) bleach with 2 gal (8L) hot water or use Ecolab Mikro-chlor Cleaner per manufacturers instructions.
  • Page 12 Recommended daily dispenser cleaning 1. Remove all debris from drain pan. 2. Pour 1 gallon (4L) hot water into drain pan to keep drain lines clear. Recommended weekly dispenser cleaning 1. Remove drain pan and grille and wash with Solution A. Rinse thoroughly. 2.
  • Page 13: Service

    Service Dispense chute cover removal 1. Remove top cover. 2. Remove two screws from top cover and pull cover forward and down to remove. 3. On push button units, disconnect plug on harness. Auger motor assembly removal 1. Remove drain pan. 2.
  • Page 14: Wiring Diagrams

    Wiring diagram VU300K series PL1-1 BLACK BLACK GRAY ORANGE POWER TOP LID DRAIN SWITCH SWITCH SWITCH GRAY GRAY 115 VOLTS 24 VOLTS DISPENSE SWITCH PL6-1 PL6-3 BROWN BATH CONTROL BOARD 24VAC RED BATH SOL STATUS LIGHTS TEMP GREEN - COLD SENSOR RED - WARM DISPENSE...
  • Page 15: Dispenser Troubleshooting Guide

    3. Check that drain pan and top are on securely. If ajar, dispenser will not operate. When the top is off, auger does not operate, even though the solenoids do (page 18). 4. Check that all drains are clear. Note: For units equipped with Follett Chewblet auto-fill icemaker kit(s), see Icemaker Operation and Service Manual for service and troubleshooting information. Symptom Ice does not dispense.
  • Page 16: Troubleshooting

    Carbonation system is not carbonating. Carbonation system is producing excessively carbonated beverages. If problems persist after following this basic troubleshooting guide, call Follett’s technical service department at (800) 523-9361 or (610) 252-7301. Possible cause 1. Loose connection. 2. Electrode connections on carbonator tank are satisfied.
  • Page 17 Operational Status The chart below shows the operational status of various parts when certain switches are turned off or accessories are removed. Condition Pump Top lid off Drain pan off On/off switch in OFF position Beverage switch in OFF position Waterbath circuit board operation The temperature sensor is hard wired directly to the circuit board.
  • Page 18: Replacement Parts

    Replacement parts Single-sided Dispenser Reference # Description Lid, with graphics, single-sided Graphics, “Follett” Access panel, tower, single-sided Not shown Cover, ice opening (below drain pan) Not shown Drain pan assembly and grille Drain pan, plastic Not shown Switch, drain pan safety...
  • Page 19 Reference # Description Motor, auger (includes capacitor) Bracket, auger motor hold-down Not shown Bracket, auger motor stabilizer Not shown Seal, shaft, auger motor Auger Auger tube (includes insulation) Insulation, auger tube Ring, auger tube, upper Ring, auger tube, lower Motor, wheel, Brother (includes capacitor) Bracket, wheel motor Not shown Capacitor, wheel motor, Brother...
  • Page 20 VU300 dispense assembly Side View Reference # Description Gate, dispense Linkage pin, gate/solenoid Pin, quick release, 3" (77mm), gate and lever Chute, ice Solenoid Not shown Boot, solenoid Dispense mechanism assembly Spring, dispense mechanism (1 per side) Not shown Chute, focus Not shown Lever, dispense VU300 dispense assembly...
  • Page 21 Reference # Description Pump, waterbath (includes mounting plate and elbow) Elbow, overflow 1" (26mm) x 3/4 MPT Not shown Elbow, clean out, drain, 3/8" (10mm) x 3/8 MPT Syrup coil QuickCARB foam pack assembly Foam pack assembly, 10 valve Not shown Foam pack assembly, 8 valve Coil, carbonated water, 8 valve and 10 valve Coil, carbonated, outer...
  • Page 22 Top View Front View Side View Reference # Description Transformer, 24V Relay, dispense Strips, terminal Switches (power and icemaker) Board, circuit and probe (one unit) Bracket, probe Switch, safety Not shown Switch, safety, drain pan assembly, LH unit Not shown Switch, safety, drain pan assembly, RH unit Not shown Switch, dispense, lever...
  • Page 24 801 Church Lane • PO Box D, Easton, PA 18044, USA Toll free (800) 523-9361 • (610) 252-7301 00119628R01 Fax (610) 250-0696 • www.follettice.com ® ® 02/06...
