Following installation, please forward this manual
Ice and Beverage Dispensers
Installation, Operation and Service Manual
to the appropriate operations person.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
VU155 Series
Service numbers above B50000
00119636R08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VU155 Seris and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Follett VU155 Seris

  • Page 1 VU155 Series Ice and Beverage Dispensers Installation, Operation and Service Manual Order parts online www.follettice.com Service numbers above B50000 Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00119636R08 www.follettice.com...
  • Page 2: Table Of Contents

    Table of contents Welcome to Follett Corporation Important cautions Specifications Installation Installing dispenser in counter Field wiring diagrams Installing optional ice machine Connecting beverage lines Operation How the dispenser works Cleaning Service Dispense chute cover removal Auger motor assembly removal...
  • Page 3: Welcome To Follett Corporation

    Before you begin After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if necessary.
  • Page 4: Specifications

    Water disconnect within 10 feet (3 m) of dispenser is suggested for automatic load units. Follett recommends use of a Follett water filter system (part# 00130229) on ice machines connected to automatic fill dispensers. Ice machine...
  • Page 5 Dimensions and clearances Required clearances 51" (1295 mm) minimum above counter for installation if dispenser will be dropped into counter 36" (915 mm) minimum above counter for all units after installation for auger cleaning and servicing 12" (305 mm) minimum on side opposite ice chute for service 12"...
  • Page 6: Installation

    Installation Installing dispenser in counter Note: All dispensers must be supported from below with supplied 6" – 9" (153 – 229 mm) adjustable leg accessory, or equivalent. Do not hang dispenser on flange. All dispensers must be installed level in both directions to ensure proper operation. Check that dispenser location meets all requirements in this manual and cut counter as shown.
  • Page 7: Field Wiring Diagrams

    1. Follow detailed cleaning instructions in service manual before operating dispenser. 2. On units with Follett integral ice water bath beverage cooling (“B” models) only, slowly pour water into ice water bath area to fill empty bath and submerge coils. Coils are submerged when water starts to flow out overflow drain.
  • Page 8: Connecting Beverage Lines

    In automatic load units, ice is manufactured in either one or two Follett RIDE model ice machines. These ice machines may be located up to 20 ft (6 m) away from the dispenser. Extruded ice is transported through a tube and pushed to the storage compartment of the dispenser.
  • Page 9: Cleaning

    Cleaning Using solutions below, clean and sanitize storage area and beverage lines before starting unit and on a routine basis as noted below. Note: Always disconnect power before cleaning dispenser. Do not run plastic parts through a dishwasher. Solution A: Combine 1 oz (30 ml) bleach with 2 gal (8 L) hot water.
  • Page 10 Recommended daily dispenser cleaning 1. Remove all debris from drain pan. 2. Pour 1 gallon (4 L) hot water into drain pan to keep drain lines clear. Recommended weekly dispenser cleaning 1. Remove drain pan and grille and wash with Solution A. Rinse thoroughly. 2.
  • Page 11: Service

    Service Front View Fig. 1 right hand (RH), 8-valve unit Dispense chute cover removal top cover 1. Remove top cover. chute valves cover 2. Push chute cover up vertically to slip off holding tab. 3. After clearing tab, pull chute cover forward to remove.
  • Page 12: Wiring Diagrams

    Wiring diagram FOR RIGHT HAND MACHINE FOR LEFT HAND MACHINE AUGER MOTOR AUGER MOTOR COUNTERCLOCKWISE ROTATION CLOCKWISE ROTATION DISPENSE PL2-1 PL2-2 PL2-1 PL2-2 PL1-1 PL1-2 BLACK YLW WHT BLACK GRAY BLACK ORANGE PURPLE YLW WHT POWER TOP LID DRAIN REAR PL2-3 SWITCH SWITCH...
  • Page 13: Troubleshooting

    (page 14). 4. Check that all drains are clear. Note: For units equipped with Follett compressed nugget ice machine, see Ice machine Operation and Service Manual for service and troubleshooting information.
  • Page 14 Operational Status The chart below shows the operational status of various parts when certain switches are turned off or accessories are removed. Condition Pump Solenoids Auger Wheel Beverage valves Top lid off Rear lid off Drain pan off On/off switch in off position Beverage switch in OFF...
  • Page 15: Replacement Parts

    Front – 8 Valve Unit with Right Hand (RH) Tower Top – 8 Valve Unit with Right Hand (RH) Tower (push-button dispensing) Reference # Description Part # Lid, 8 valve unit (includes “Follett” label) 502436 Lid, 10 valve unit (includes “Follett” label) 502437 Label, “Follett” 502438...
  • Page 16 Order parts online Dispense assembly www.follettice.com Side View (RH unit with bath shown) Top View Reference # Description Part Gate, dispense 502455 Linkage pin, gate/solenoid 502456 Pin, quick release, 3" (77 mm), bath gate and lever 501949 Pin, quick release, 5.53" (141 mm), dispense gate 502102 Solenoid (includes linkage pin) 00126607...
  • Page 17 Order parts online Water bath www.follettice.com Side View Top View Reference # Description Part # Pump, water bath (includes mounting plate and elbow) 00111476 Elbow, overflow drain, 1" (26 mm) x 3/4 MPT 502465 Not shown Elbow, clean-out drain, 3/8" (10 mm) x 3/8 MPT 502466 Coil, syrup 00125864...
  • Page 18 Hopper Order parts online www.follettice.com Side View Reference # Description Part # Auger, LH unit (black, stamped with “1”) 502491 Not shown Auger, RH unit (gray, stamped with “2”) 502492 Tube, auger, LH unit with beverage bath 502486 Not shown Tube, auger, RH unit with beverage bath 502485 Not shown...
  • Page 19 Order parts online Auger motor www.follettice.com Top View Side View Reference # Description Part # Auger motor/drive assembly, vertical (includes all items below) 502493 Motor, vertical auger (includes gearbox and capacitor) 502476 Chain, auger drive #35, 42 link 00931790 Sprocket #35, 22T 5/8 bore 502478 Sprocket #35, 12T 5/8 bore 502479...
  • Page 20 Not shown Relay 01020734 RIDE and QuickCARB are trademarks of Follett LLC. Chewblet is a registered trademark of Follett LLC, registered in the US. 801 Church Lane • Easton, PA 18040, USA Toll free (877) 612-5086 • +1 (610) 252-7301 00119636R08 www.follettice.com...
