M
M
Infrared Outdoor Patio Heater
Manual for Installation, Operation & Maintenance
If you smell gas:
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. If odor continues, immediately call your
WARNING: Improper installation, adjustment, alteration,
service or maintenance can cause injury or property damage.
Read the installation, operating and maintenance instructions
thoroughly before installing or servicing this equipment.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
*FOR OUTDOOR USE ONLY
*
The Lynx Patio heater has been approved for indoor use in
applications (See page 8 for details)
Please retain these instructions for future reference.
IMPORTANT: The installer must leave these instructions with
the owner. Only those who are certified to do so should
perform service on these heaters.
o
d
e
l
N
o
.
o
d
e
l
N
o
.
FOR YOUR SAFETY
gas supplier.
L
H
P
M
L
H
P
M
non-residential
LT087
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Lynx LHPM
Summary of Contents for Lynx LHPM
- Page 1 *FOR OUTDOOR USE ONLY non-residential The Lynx Patio heater has been approved for indoor use in applications (See page 8 for details) Please retain these instructions for future reference. IMPORTANT: The installer must leave these instructions with the owner.
-
Page 3: Table Of Contents
Equipment dimensions................10 Power/Gas Specification................11 7) Assembly .......................12 8) Wiring ......................18 8) Lighting and Shutdown Instructions ...............19 9) Maintenance and Trouble Shooting .............. 20 10) Parts List ......................21 11) Internal Wiring Diagram ................22 12) Warranty ......................23 Lynx Page 3 Rev. 3/06/08... -
Page 4: Caution And General Safety
Children should be strictly supervised when in the area of this heating • appliance. Playing or running around the structure should be strictly forbidden. Clothing or other flammable materials should not be hung on or near this • heater. Lynx Page 4 Rev. 3/06/08... -
Page 5: Pre-Installation Overview
Pre-installation Overview What you will receive: Top Reflector Heater head Assembly Pole Assembly Hardware Lynx Page 5 Rev. 3/06/08... - Page 6 Pre-installation Overview Mounting Plate hole Pattern (Full size) 4.42" 6.25" Ø0.40" Lynx Page 6 Rev. 3/06/08...
-
Page 7: What You Need To Supply
3. Gas supply line that is installed to the Gas and Electric Supply according to the: National Fuel Gas Code, ANSI Z.223.1 (NFPA 54) in the US and CAN/CGA B149.1 and B149.2 Installation Codes in Canada. 4. Electrical supply rated at 24 Vac with two stage control Lynx Page 7 Rev. 3/06/08... -
Page 8: Location Planning
Use natural or newly built wind barriers where possible, such as existing buildings, shrubbery or tree lines and fences One Lynx Patio heater, at high fire and in windless conditions has a comfort radius of about twelve feet (24 ft. circle). -
Page 9: Clearance To Combustible Materials
CLEARANCE TO COMBUSTIBLES SIDE MODEL NO. SIDES BELOW BELOW LHPM 18" 22" 33" NOTE: Some materials deteriorate or soften at sustained temperatures below 160°F. Consult material manufacturer for recommendations Lynx Page 9 Rev. -
Page 10: Installation Instructions
Appliance must be electrically grounded in accordance with local codes or, in their absence; the National Electrical Code, ANSI/NFPA 70 in the USA, CSA CZ21.1 Canadian Electrical Code in Canada. Equipment Dimensions Floor mount model # LHPM 39.5" 89.7" 67.0"... -
Page 11: Power/Gas Specification
The appliance must be isolated from the gas supply piping system by closing its individual manual shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than ½ psig (3.5 KPa) Lynx Page 11 Rev. 3/06/08... -
Page 12: Assembly
The pole base could also be mounted on wood decks with 3/8” bolts and lock washers on the underside of the deck. Periodically check for tightness when mounted to a wood deck. Lynx Page 12 Rev. 3/06/08... - Page 13 Firmly tape the pull wire to the power wires. Lower the assembly into place while pulling the wires. Two people may be necessary for this operation. Lynx Page 13 Rev. 3/06/08...
- Page 14 Assembly Secure burner head to pole with three #8 screws provided. Lynx Page 14 Rev. 3/06/08...
- Page 15 Assembly Push the gas connection into the slot buy slightly pushing on the gas line through the electrical box. The gas fitting should be positioned as illustrated below. Lynx Page 15 Rev. 3/06/08...
- Page 16 Assembly e. Place gas connection cover onto the fitting and install the nut to fasten the cover assuring the nut is properly seated. See below. Lynx Page 16 Rev. 3/06/08...
- Page 17 Assembly f. Install reflector using the four carriage bolts, nuts and washer provided. g. Connect gas supply and electric power following all local codes. Pressure test all gas connections. Lynx Page 17 Rev. 3/06/08...
-
Page 18: Wiring
This appliance requires a 24 volt AC supply with a minimum 20 VA capacity. Below is a suggested control circuit for operating this appliance. The switching mechanisms may also be Timers Blue To Patio Heater Green 20VA 120V Ensure a good ground source Lynx Page 18 Rev. 3/06/08... -
Page 19: Lighting And Shutdown Instructions
Electronic control of heater can be re-set by de-energizing and re-energizing electric power. 2. Shut Down a. Turn off power to electronic control. b. For longer periods of shut down, also close manual gas supply valve. Lynx Page 19 Rev. 3/06/08... -
Page 20: Maintenance And Trouble Shooting
3. Flame lights but will not stay lit: • Ensure there is no overpowering wind. • Ensure sense electrode is not corroded, is not grounded or has a cracked insulator. Electrode position is radially across face of burner. Lynx Page 20 Rev. 3/06/08... -
Page 21: Parts List
Orifice Nat Gas EG002 Gas Hose Assembly EG014 Gas Valve Assembly EG007 Emitter ES011 Indicator Light EE010 Flame Sensor EE002 Burner assembly EG008 Spark Electrode EE001 Pole Package ES066 Electronic Control Module EE009 Ignition wire EE005 Lynx Page 21 Rev. 3/06/08... -
Page 22: Internal Wiring Diagram
électrique fait de la température évaluation with wiring material having a temperature rating d'au moins 105°C. of at least 105°C. EL013 01/08 Lynx Page 22 Rev. 3/06/08... -
Page 23: Warranty
Warranty MODEL No. LHMP LYNX PATIO HEATER WARRANTY The Manufacturer warrants to the original owner that the product will be free of defects in material and workmanship for a period of 5 years from the date of purchase, for everything except the electronic control module, spark electrode, and sense electrodes which have a replacement warranty period of 3 years.
