Summary of Contents for Lynx LHPM
- Page 1 MAKE THE MOST OF YOUR LYNX POST MOUNTED HEATER (LHPM) CARE & USE/INSTALLATION...
-
Page 2: If You Smell Gas
2. California law requires businesses to warn customers of potential exposure to such substances. To minimize exposure to the substances, always operate this unit according to the use and care instructions found in this manual. Be certain to provide adequate ventilation. LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 3: Caution And General Safety
• Children should be strictly supervised when in the area of this heating appliance. Playing or running around the structure should be strictly forbidden. • Clothing or other flammable materials should not be hung on or near this heater. LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 4: Pre-Installation Overview
PRE-INSTALLATION OVERVIEW WHAT YOU WILL RECEIVE: TOP REFLECTOR HEATER HEAD ASSEMBLY ELECTRIC SWITCH KIT POLE ASSEMBLY HARDWARE Assembly delivers in 4 boxes LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 5: A Message To Our Customers
This manual includes important safety tips. You should keep it handy for easy reference. Also, at Lynx, we enjoy hearing from our customers. We like to hear about your successes but also about any difficulties you are having. Please feel free to contact us with any questions or problems, or just to share a new recipe. -
Page 6: Mounting Plate Hole Pattern
PRE-INSTALLATION OVERVIEW MOUNTING PLATE HOLE PATTERN (FULL SIZE) LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 7: Lighting Instructions
3. Gas supply line that is installed to the Gas and Electric Supply according to the: National Fuel Gas Code, ANSI Z.223.1 (NFPA 54) in the US and CAN/CGA B149.1 and B149.2 Installation Codes in Canada. 4. Electrical supply rated at 24 Vac with two stage control LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 8: Location Planning
Use natural or newly built wind barriers where possible, such as existing buildings, shrubbery or tree lines and fences. One Lynx Patio heater, at high fire and in windless conditions has a comfort radius of about twelve feet. A series of heaters providing area heat should be placed about 14 feet apart. -
Page 9: Clearance To Combustible Materials
The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of ½ psig (3.5 KPa). LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 10: Installation Instructions
54) and for Canada, CAN/CGA B149.1 and B149.2, National Gas and Propane Installation Code (latest editions). Appliance must be electrically grounded in accordance with local codes or, in their absence; the National Electrical Code, ANSI/NFPA 70 in the USA, CSA CZ21.1 Canadian Electrical Code in Canada. EQUIPMENT DIMENSIONS LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... - Page 11 The pole base could also be mounted on wood decks with 3/8” bolts and lock washers on the underside of the deck. Periodically check for tightness when mounted to a wood deck. STEP 1 LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION...
- Page 12 Firmly tape the pull wire to the power wires. Lower the assembly into place while pulling the wires. Two people may be necessary for this operation. STEP 2 LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION...
- Page 13 ASSEMBLY ...continued Secure burner head to pole with three #8 screws STEP 3 Please note the lights ony activate when in use LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION...
- Page 14 ASSEMBLY ...continued Push the gas connection into the slot buy slightly pushing on the gas line through the electrical box. The gas fitting should be positioned as illustrated below. STEP 4 LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION...
- Page 15 ASSEMBLY ...continued Place gas connection cover onto the fitting and install the nut to fasten the cover assuring the nut is properly seated. See below. STEP 5 LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION...
- Page 16 ASSEMBLY ...continued Install reflector using the four carriage bolts, nuts and washer provided. STEP 6 Connect gas supply and electric power following all local codes. Pressure test all gas connections. LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION...
- Page 17 Mount the transformer in a location protected from the weather. Optional base cover available separately. The diagram on page 18 is the recommended control circuit for operating this appliance. LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION...
-
Page 18: Maintenance And Troubleshooting
Flame lights but will not stay lit: • Ensure there is no overpowering wind. • Ensure sense electrode is not corroded, is not grounded or has a cracked insulator. Electrode position is radially across face of burner. LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 19: Parts List
33290 GAS HOSE ASSEMBLY 33285 GAS VALVE ASSEMBLY 33291 EMITTER 33286 INDICATOR LIGHT 33292 FLAME SENSOR 33287 BURNER ASSEMBLY 33293 SPARK ELECTRODE 33288 POLE PACKAGE 32590 ELECTRONIC CONTROL MODULE 33289 IGNITION WIRE 33294 LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... -
Page 20: Internal Wiring
INTERNAL WIRING LHPM POST MOUNTED HEATER CARE & USE/INSTALLATION... - Page 21 7) No one has the authority to add to or vary Lynx’s warranty, or to create for Lynx any other obligation or liability in connection with the sale or use of its products.
- Page 22 The best outdoor kitchen products come from: Lynx Grills, Inc. 7300 Flores Street Downey, CA 90242 Service: (888)-289-5969 Fax: (562) 299-6789 www.lynxgrills.com 2017...
