OWNER'S MANUAL
Titan 6500 Industrial Generator
The Emission Control System for this generator is warranted for standards set by the Environment Protection Agency.
IMPORTANT!
It is extremely important to read and understand the entire contents of
this Owner's Manual for the Titan Model TG 6500 before attempting to
operate the generator. This is a gas engine powered, industrial strength
generating unit of electrical power. The gas engine and the generator
are both potentially extremely hazardous and could cause physical injury
or even death if improperly used.
WARNING!
Do Not Operate Equipment until reading & understanding Owner's Manual!
Disconnect all loads before starting or stopping generator.
Allow to run for a few minutes with no load before stopping.
Revision # 030321A
TG8500 Manual Copy
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Titan 6500
Summary of Contents for Titan 6500
- Page 1 IMPORTANT! It is extremely important to read and understand the entire contents of this Owner’s Manual for the Titan Model TG 6500 before attempting to operate the generator. This is a gas engine powered, industrial strength generating unit of electrical power. The gas engine and the generator are both potentially extremely hazardous and could cause physical injury or even death if improperly used.
-
Page 2: Industrial Generator
Titan shall not be responsible for any consequences resulting from improper use of this equipment. The operator is required to read the entire contents of this manual before attempting to operate the unit. -
Page 3: Connecting Loads
CONNECTING LOADS Add up the Watts of all devices you connect to the Titan Generator at one time. Do not exceed 6000 Watts on Titan Generator Model TG 6500RC (see wattage refer- ence guide). P.O. Box 791 The rated Watts of most electrical devices can be found Travelers Rest, S.C. - Page 4 SAFETY This generator was designed for specific applications. DO NOT attempt to modify the unit in any way or use it for any application that it was not designed to do. Ask the dealer or contact the factory if you have any questions concerning the generator’s application.
-
Page 5: Operation Of The Generator
OPERATION OF THE GENERATOR Starting the engine Stopping the engine 1. Check oil and fuel levels Turn off all electrical devices connected to the generator. 2. Turn fuel valve to the “ON” position WARNING: 3. Put choke lever in the “ON” position DO NOT start or stop generator with electrical devices plugged in. - Page 7 240 Volt. L14-30 120 Volt. Recep- Breaker On\Off Switch Receptacle tacle P.O.Box 791, Travelers Rest, S.C. 29690 Phone 864-834-7212 Service/Replacement Parts 800-845-4141...
- Page 8 Wattage Reference Guide Device Running Watts Device Running Watts Impact Wrench *Air Conditioner (12,000 BTU) 1700 *Jet Pump Battery Charger (20 Amp) Belt Sander (3”) 1000 Lawn Mower 1200 Light Bulb Chain Saw 1200 Microwave Oven Circular Saw (6-1/2”) 800 to 1000 Coffee Maker 1000 *Milk Cooler...
- Page 10 26-28oz.
- Page 11 Storage...
-
Page 14: Troubleshooting
TROUBLESHOOTING Problem Cause Solution 1. Reset the circuit breaker. Engine is running but no power 1. Circuit breaker is open. 2. Check & repair. output is available. 2. Poor connection or defective 3. Connect another device cord set. that is in good condition. 3. -
Page 15: Parts Catalog
Parts Catalog P.O. Box 791 • Travelers Rest, SC 29690 • Phone: (864) 834-7212 • Fax: (864) 834-5127 Service/Replacement Parts: (800) 845-4141... -
Page 16: Engine Block Assembly
1. Engine Block Assembly Part Name Titan Part # Titan Part # Part Name 125- Rings TI 12-14 163-Oil Drain Plug Washer TI 12-24 126- Piston Pin Clip TI 12-14 165-Main Seal TI 12-27 127- Piston TI 12-14 166-Governor Arm... -
Page 17: Governor Assembly
2. Governor Assembly Part Name Titan Part # 147- Main Bearing TI 12-33 149- Governor Gear Assembly TI 12-09 150- Balancer Shaft Bearing TI 12-32 151- Crank Case Gasket TI 12-08 152- Guide Pins Some Parts Sold As Assemblies... -
Page 18: Starter Assembly
3. Starter Assembly Part Name Titan Part # TI 12-21 170- Ground Wire 171- Bolt TI 12-21 172- Ignition Coil TI 12-34 183- Fly Wheel TI 12-34 184- Fly Wheel Fan TI 12-27 185- Recoil Cup TI 12-34A 186- Nut... - Page 19 4. Carburator Part Name Titan Part # TI 12-02B 131- Gasket TI 12-35 132- Vaccum Spacer TI 12-02B 133- Gasket 134- Vaccum Line Clamp 135- Vaccum Line TI 12-02B 140- Gasket TI 12-02 209- Carburator Assembly Some Parts Sold As Assembly...
-
Page 20: Choke Assembly
5. Choke Assembly Part Name Titan Part # 134- Vaccum Line Clamp 137- Vaccum Line 138- Vaccum Line Holder 139- Check Valve TI 12-02A 140- Gasket TI 12-02B 210- Choke Assembly TI 12-02A Some Parts Sold As Assemblies... -
Page 21: Head Assembly And Parts
6. Head Assembly Titan Part # Part Name Part Name Titan Part # 97- Valve Cover Bolt 112- Rocker Adjustment TI 12-13 TI 12-12A 98- Washer 113- Rocker Arm TI 12-13A TI 12-12A 99- Valve Cover 114-Rocker Arm Stud TI 12-13A... - Page 22 7. Governor Arm Assembly Part Name Titan Part # 177- Governor Spring TI 12-10 178- Governor Rod TI 12-10 179- Throttle Return Spring TI 12-10 180- Nut 181- Bolt 182- Governor Arm TI 12-10 Some Parts Sold As Assemblies...
-
Page 23: Specifications
Circuit Breaker Protection Single Phase 60Hz. 74 Decibel’s @ 10’ Low Oil Shut Down Manual Start Oil Capacity 26-28oz. 12hp Titan Gasoline Engine Size: L-27” W-20” H-22” Steel Sleeve Cylinder Net. Weight 175LBS. 5 Gallon Fuel Tank One Year Warranty Approx. - Page 24 MODEL TG 6500 Generator MODEL TG 6500 P.O. Box 791 • Travelers Rest, SC 29690 • Phone: (864) 834-7212 • Fax: (864) 834-5127 Service/Replacement Parts: (800) 845-4141...
