Fluke Cable Analyzer DTX-ELT Brochure & Specs page 2

DTX-ELT Specifications
Test Standards
Standard Link Interface Adapters
Shielded and Unshielded Twisted
Pair (STP, FTP, SSTP and UTP) data
cabling:
Speed of Autotest
Supported Tests Parameters
Cable Tone Generator
Display
Input Protection
Case
Dimensions
Weight
Operating Temperature
Storage Temperature
Operating relative humidity
(% RH without condensation)
Vibration
Shock
Safety
Pollution degree
Altitude
EMC
• TIA Category 3 and 5e per TIA/EIA-568-B
• TIA Category 5 (1000BASE-T) per TIA TSB-95
• TIA Category 6 per TIA/EIA-568B.2-1
• ISO/IEC 11801 Class C, D, and E
• EN 50173 Class C, D, E
• ANSI TP-PMD
• IEEE 802.3 10BASE-T, 100BASE-TX, 1000BASE-T
• IEEE 802.5 (STP cabling, IBM Type 1, 150Ω ) Token Ring, 4 Mbps and 16 Mbps
• Channel adapters for: TIA Category 3, 4, 5, 5e and 6: 100Ω
• ISO/IEC Class C and D: 100Ω and 120Ω
• ISO/IEC Class E, 100Ω
• Permanent Link adapter (only with the DTX-ELT PRO): Cat 6/Class E permanent link adapters with
centered Cat 6A test reference plug. This plug is also the test reference for Cat 6 and lower categories.
The life of the plug is rated at 10,000+ insertions. The contact block can be replaced in the field with
the DTX-PLA002PRP replacement parts.
• Full 2-way Autotest of Category 6 Twisted-Pair links in 20 seconds
(The selected test standard determines the test parameters and the frequency range of the tests)
• Wire Map
• Propagation Delay
• DC Loop Resistance
• Return Loss (RL), RL @ Remote
• Attenuation-to-crosstalk Ratio -
Near End (ACR-N), ACR-N @ Remote
• Power Sum ACR-F (PS ACR-F), PS ACR-F @ Remote
• Power Sum ACR-N (PS ACR-N), PSACR-N @ Remote
Generates tones that can be detected by a tone probe such as a Fluke Networks IntelliTone probe. The
tones are generated on all pairs. Frequency range of tones: 440 Hz to 831 Hz
3.7 in (9.4 cm) diagonal, 240 dots wide by 320 dots high, passive color, transmissive LCD with backlight.
Protected against continuous telco voltages and 100 mA over-current. Occasional ISDN over-voltages will
not cause damage.
Soft carrying case with shoulder strap
Main unit and Smart Remote: 8.5 in x 4.4 in x 2.4 in (21.6 cm x 11.2 cm x 6cm), nominal
2.4 lb (1.1 kg), nominal (without adapter or module)
0°C to 40°C (32°F to 104°F)
-20°C to 60°C (-4°F to 140°F)
32°F to 95 °F (0°C to 35°C): 0 % to 90%
95°F to 113°F (35°C to 45°C): 0 % to 70 %
Random, 2 g, 5 Hz -500 Hz
1 m drop test with and without module and adapter attached
CSA C22.2 No. 1010.1: 1992 EN 61010-1 1st Edition Amendments 1, 2
Pollution Degree 2 as defined in IEC 60664 and applied to IEC 60950 "Safety of Information Technology
Equipment, 1999"
Operating: 4000 m; Storage: 12000 m
EN 61326-1
• Length
• Delay Skew
• Insertion Loss (Attenuation)
• NEXT, NEXT @ Remote
• Attenuation-to-Crosstalk Ratio -
Far End (ACR-F) and ACR-F @ Remote
• Power Sum NEXT (PSNEXT), PSNEXT @ Remote
