The CertiFiber Pro Optical Loss Test Set (OLTS) modules attach to
Versiv
main and remote units to make rugged, hand-held
™
testers that let you certify, troubleshoot, and document fiber
optic network cabling.
Accessing the Product Manuals
This guide provides basic information to help you get started
using the tester. For more detailed information, see the latest
versions of the CertiFiber Pro Users Manual and the Versiv
Technical Reference Handbook provided on the Product
Manuals DVD and on the Fluke Networks website.

Safety Information

Warning or Caution: Risk of damage or destruction to
equipment or software. See explanations in the manuals.
Warning: Risk of fire, electric shock, or personal injury.
Warning: Class 1 or Class 2 lasers. Risk of eye damage
from hazardous radiation.
This key turns the Product on and off.
To prevent possible fire, electric shock, or personal injury:
•
Read all safety information before you use the
Product.
•
Carefully read all instructions.
•
Do not open the case. You cannot repair or replace
parts in the case.
•
Do not modify the Product.
