Wheelock SERIES SM Installation Instructions Manual

273 Branchport Ave.
Long Branch, N.J. 07740
(800) 631-2148
(800) 397-5777
www.wheelockinc.com
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

GENERAL:

Wheelock's Sync Modules (Series SM) are uniquely designed to accept two independent strobe and audible inputs and convert to a
single output that connects to Wheelock's Series AS and NS appliances. When interfaced with the sync module, the audible strobes
produce the synchronized code 3 horn and synchronized strobe upon actuation. The audible portion of the AS and NS can be
controlled independently from the strobe, using only a 2-wire alarm circuit. They are the ideal choice for alarm systems where an
audible silencing feature is required during an alarm condition. The SM is UL Listed under Standard 1971 (Emergency Appliances
for the Hearing Impaired) for indoor use Fire Protective Service and ULC Listed under CAN/ULC-S525-99 for Audible Signaling
Appliances for Fire Alarm Systems. All inputs are polarized for compatibility with standard reverse polarity supervision of circuit
wiring by a Fire Alarm Control Panel (FACP).
The table below shows the additional Wheelock products that can be used with the SM Sync Modules.
Series AH/AH-WP, NH, HS
Series MT with Strobe
Series E70/90 with Strobe
Series ET70/90/1080/1081 with Strobe
Series RSS/RSSP Strobes
Series CH70 Strobes
Series AS, NS, HS4
: All and
NOTE CAUTIONS
WARNING: THE SM APPLIANCE IS A "FIRE ALARM DEVICE - DO NOT PAINT."
: All Canadian Installations should be in accordance with the Canadian Standard for the Installation of Fire Alarm Systems -
NOTE
CAN/ULC-S524-01 and Canadian Electrical Code, Part 1. Final acceptance is subject to Authorities Having Jurisdiction.
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY.
FOLLOWING INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION, INSTALLATION
AND/OR OPERATION OF THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY
DAMAGE AND SERIOUS INJURY OR DEATH TO YOU AND/OR OTHERS.

SPECIFICATIONS:

Model
SM-12/24
SMX-12/24 *
WARNING: FOR UL APPLICATIONS THESE APPLIANCES WERE TESTED TO THE OPERATING VOLTAGE LIMITS OF 8.0-
33.0 VOLTS USING FILTERED (DC) OR UNFILTERED FULL-WAVE RECTIFIED (FWR). DO NOT APPLY 80% AND 110% OF
THESE VOLTAGE VALUES FOR SYSTEM OPERATION.
WARNING: FOR ULC APPLICATIONS THESE APPLIANCES WERE TESTED TO THE OPERATING VOLTAGE OF 10.5-31.0
VOLTS FOR 24V MODELS USING FILTERED (DC) OR UNFILTERED FULL-WAVE-RECTIFIED (FWR). APPLY 80% AND 110%
OF THESE VOLTAGE VALUES FOR SYSTEM OPERATIONS.
Copyright 2004 Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
SERIES SM AND SMX SYNCHRONIZATION (SYNC) MODULE
Table 1: Products Available for Use with SM Sync Module
are identified by the symbol
WARNINGS
Table 2: Ratings Per UL and ULC
Regulated
Voltage
(VDC/VRMS)
12/24
12/24
* SMX is a UL recognized component; SMX is a ULC Listed model.
The SMX version does not have a mounting plate.
Audible Horn
Multitone Horn with Sync Strobes
E Speakers with Sync Strobe
ET Speakers with Sync Strobe
Remote Sync Strobes
Chimes with Strobes
Audible Horn with Sync Strobes
. All warnings are printed in bold capital letters.
FAILURE TO COMPLY WITH ANY OF THE
Voltage Range Limit
Per UL 1971 CAN/ULC-S525-99
(VDC/VRMS)
8.0-33.0
8.0-33.0
Voltage Range Per Mounting
(VDC/VRMS)
10.5-31.0
10.5-31.0
Option
A
----
P83123 T
Sheet 1 of 6
