Wheelock AHWP Series Specification

FIRE ALARM SYSTEMS
Description:
Wheelock's Weatherproof Strobe, Audible Strobe, Multitone
Strobe and Audible appliances all have an extended
temperature range of -35
satisfy virtually all outdoor and severe environment
applications. All strobes are Indoor/Outdoor UL Listed and rated
for 75 candela @ -35
Series RSSWP Strobes, Series ASWP Audible Strobes Series
AHWP Audibles and Series MTWP Strobe may be
synchronized when used in conjunction with the Wheelock
SM and DSM Sync Module(s).
Weatherproof Strobes - Series RSSWP
ULC Listed under Standard CAN/ULC-S526-02 for
Indoor/Outdoor use. The strobes use a Xenon flashtube with
solid state circuitry enclosed in a rugged Lexan® lens to provide
maximum visibility and reliability for effective visual signaling.
The Series RSSWP has a 75 cd intensity on axis at -35°C and
Low Current Draw (180 cd @ 25°C). For outdoor application
the RSSWP must be wall mounted to a Weatherproof backbox
(WPSBB).
Weatherproof Audible Strobes and Audibles- Series ASWP
and AHWP
ULC Listed under Standard CAN/ULC-S526-02 for Visual
Signaling Appliances and Standard CAN/ULC-S525-99 for
Audible Signaling Appliances. Indoor/Outdoor use and offer a
field selectable choice of continuous horn or temporal pattern
(Code 3) when constant voltage from the Fire Alarm Control
Panel (FACP) is applied. Additionally, the audible has three (3)
selectable dBA settings of 99, 95, and 90 dBA in both tones
and, when used with Wheelock sync modules, SM or DM the
audible may be silenced while maintaining strobe activation
on the Series ASWP. For outdoor applications the ASWP
must be Wall Mounted to the Weatherproof Backbox (WPBB).
Weatherproof Multitone Strobe and Multitone Horn -
Series MTWP and MT-12/24
Is ULC Listed for indoor and outdoor applications under
Standard CAN/ULC-S526-02 for Visual Signaling and under
Standard CAN/ULC-S5255-99 for Audible Signal Devices for Fire
Alarm Systems. The Multitone Strobe Appliances use a Xenon
flash tube with solid state circuitry enclosed in a rugged Lexan®
lens to provide maximum visibility and reliability for effective
visible signaling. The Multitone electronic appliance offers a
choice of eight (8) internationally recognized alerting sounds:
Horn, Bell, March Time Horn, Code 3 Tone, Code 3 Horn, Slow
Whoop, Siren or Hi/Lo Tone. Additionally, the audible has two
installer selectable sound output levels; Standard and High
covering a range (depending on selected signal) or 85-100 dBA
anechoic. The series MTWP is a true 4-wire appliance. The
strobe portion can by synchronized and non synchronized. The
Multitone (audible) portion can be synchronized, but it can be
connected to a coded fire alarm system. The series MTWP
and the MT-12/24 mount to a series IOB out door backbox.
Copyright 2005 Wheelock, Inc. All rights reserved.
° C to 66 ° C (-31 ° F to 150
° C (-31°F).
Helping People Take Action
SERIES RSSWP, ASWP, AHWP, and MTWP
WEATHERPROOF STROBE
° F) and will
WEATHERPROOF AUDIBLE STROBE
WEATHERPROOF AUDIBLE HORN
SERIES ASWP
Mounted to WPBB
SERIES MTWP
Mounted to IOB
FEATURES
• Approvals include: ULC, UL 1638, UL 464
• Meets OSHA 29 Part 1910.165.
• ULC Listed with an extended temperature range
of -35°C to 66°C (-31°F to 150°F).
• 24 VDC with wide UCL Listed Voltage
Range using filtered (DC) or unfiltered VRMS
voltage.
• Synchronize with Wheelock Series SM or DSM,
Sync Module(s).
I N C .
SM
SERIES RSSWP
Mounted to WPSBB
SERIES AHWP
36
