Series SA-S Supervised Self-Amplified Speakers and Speaker Strobes
Description:
The Series SA-S Supervised Self-Amplified Speakers and
Speaker Strobes are designed to meet the critical needs
for the life safety industry. These speakers and speaker
strobes are a perfect fit for SCIF (Sensitive Compartmented
Information Facilities) room applications.
Power Input Voltage:
Appliance Input Level:
Appliance Input Impedence:
Sound Level Speaker Amplifier Current Draw:
(Loudest)
Level 6: < 120mA RMS
Level 5: < 97mA RMS
Level 4: < 80mA RMS
Level 3: < 68mA RMS
Level 2: < 60mA RMS
(Lowest)
Level 1: < 54mA RMS
U
L
®
S5391
SA-S70-24MCW-FR
16.0-33.0 VDC, regulated
0.5 V RMS or 25 V RMS
(Switch selectable)
0.5-V Setting:
Greater than 400 Ohms, or equivalent to less
than 1/1000 W (0.001 W or 1 mW) load
25-V Setting:
Greater than 20 kOhms, or equivalent to less
than 1/32 W (.03125 W or 31.25 mW) load
Series
Series
SA-S70-R
Features:
•
Approvals Include: UL Standard 1480 (Speakers) and UL
Standard 1971 and UL Standard 1480 (Speaker Strobes)
•
Accepts audio input levels of 0.5 VRMS or 25 VRMS
•
Power Input Voltage 16.0 to 33.0 VDC
•
Wall or ceiling mount models
•
Speaker strobes utilize Wheelock's synchronizable Multi-
Candela Strobe
•
1 watt high efficiency speaker
•
Frequency range of 400Hz to 4000Hz
•
Mounts onto a 4" square deep backbox with an extension
ring
dB Sound Output
SA-S90R
Sound
SA-S90W
SA-S90-24MCC-FR
Level
SA-S70R
SA-S90-24MCC-FW
SA-S70W
6
84
5
82
4
77
3
75
2
71
1
69
Series
SA-S90-24MCC-FR
SA-S70-24MCC-FR
SA-S70-24MCC-FW
84
82
81
81
77
76
74
74
71
70
68
68
