Cooper Wheelock DB4 Range Specification

Description:
This range of loudspeakers, intended for use in potentially explosive
gas and dust atmospheres, has a power rating of up to 25 watts and
is suitable for use in all gas groups including hydrogen.
The flamepaths, flare and the body, are manufactured completely
from a UV stable glass reinforced polyester. Stainless steel screws
and sinter are incorporated thus ensuring a corrosion free product.
A tapered flamepath is used to overcome the problems of assembly
of parallel spigot flamepaths.
This product does not include a blocking capacitor. Contact Cooper
Wheelock Technical Support for models with a blocking capacitor*.
*Coming Soon
Architects and Engineers Specifications
Speakers for hazardous locations and harsh environments shall be UL and cUL listed for Class I, Division 2, Groups A,B,C&D, and
Class I, Zones 1, AExd IIC T4 applications. They shall be constructed of lightweight, UV stable glass reinforced polyester, shall be
corrosion resistant, and shall meet NEMA 4x, NEMA 6, IP 66 & IP 67 environmental requirements over a temperature range of
-67°F to +158°F (-55°C to +70°C).
The speakers shall be rated for 70 vrms input with power taps for 1,2,4,6,12.5 or 25 watt operation. Rated sound output shall be up
to 109 dBA at 10 feet and rated frequency response shall be 400Hz to 8kHz. The speakers shall include a stainless steel mounting
bracket with ratchet facility to direct sound output.
Note: Due to continuous development of our products, specifications and offerings are subject to change without notice in accordance
with Cooper Wheelock standard terms and conditions.
ATEX
Speakers - Up to 25 Watts, Hazardous Location, Weatherproof
15W/20W/25W (Long Flare)
Features*:
UL listed for USA and Canada:
★
– Class I, Div 2, Groups A-D.
– Class I, Zones 1, AExd IIC, T4
– Class II, Div 2, Groups F & G
ATEX approved
★
NEMA 4x & 6, IP66 and IP67
★
Certified temperature –67°F to +158°F (-55°C to
★
+70°C)
GRP corrosion-free flamepaths
★
109dBA at 25 watts at 10 feet
★
8, 15 and 25 watt versions
★
Power tappings, via integral transformer
★
Ratcheted swivel bracket
★
Stainless steel sinter
★
Stainless steel mounting bracket
★
Tapered flamepath
★
*Depends on version
DB4 Range
8W (Short Flare)
