Cooper Wheelock STH-2R24MCCH(X) Installation Instructions

273 Branchport Avenue
Long Branch, N.J. 07740
(800) 631-2148
www.cooperwheelock.com
Use this product according to this instruction manual. Please keep this instruction manual for future reference.

MODELS:

GENERAL:

The Cluster Speaker Strobe Assembly is designed for indoor ceiling mounting or indoor wall mounting, in high ambient noise level environments. The Cluster
Speaker Strobe is a speaker/visual alerting system, equipped with up to 4 UL Listed STH-15SR supervised horn loudspeakers and a UL Listed High Candela Strobe,
mounted to a NEMA galvanized steel enclosure, 10"W X 10" L X 6"D. The Strobe is mounted to a 4" deep backbox, which is then mounted to the steel enclosure.
Speakers and Strobe are pre-wired to the internal terminal block. The speakers can be wired for one or two speaker circuit operation.
The STH-15 loudspeaker provides multiple power requirements with high dBA output at each power tap. STH-15 offers a choice of field selectable taps, 1 to 15
Watts for either 25VRMS or 70VRMS audio systems. The Series STH design incorporates a compression driver, mounted on a double re-entrant horn for maximum
output at minimum power across a UL rated frequency range of 400 to 4,000Hz and an anechoic range of 400 to 14,000Hz. The speaker line inputs are compatible
with standard supervision of circuit wiring by a Voice Control Panel. A capacitor is wired in series with the multi-tap transformer for this purpose. Each loudspeaker
meets or exceeds the UL Standard 1480 (Speakers for Fire Protective Signaling Systems).
The RSS-24MCCH Strobes can provide a non-synchronized strobe signal when connected directly to a Fire Alarm Control Panel (FACP), or provide a synchronized
strobe signal when used in conjunction with a Sync Module (SM) or Dual Sync Module (DSM). The Series RSS Strobe Appliances are UL Listed under Standard
1971 (Emergency Devices for the Hearing Impaired) for Indoor Fire Protection Service. The Series RSS Strobe Appliance with amber, blue, green or red lens is UL
Listed under Standard 1638 (Visual Signaling Appliance) for Private Mode Emergency General Utility Signaling. The strobe uses a Xenon flashtube with solid state
circuitry enclosed in a rugged Lexan® lens to provide maximum visibility and reliability for effective visible signaling. All inputs are polarized for compatibility with
standard reverse polarity supervision of circuit wiring by a FACP.
NOTE: "Lexan" is a registered trademark of General Electric Company.
For additional information, see the Installation Instruction Sheet P82697 for the STH-15, P84442 for the RSS-24MCCH or the P84517 for the RSS-24MCCH with
colored lens.
NOTE: All CAUTIONS and WARNINGS are identified by the symbol
WARNING: PLEASE READ THESE INSTRUCTIONS CAREFULLY.
INSTRUCTIONS, CAUTIONS AND WARNINGS COULD RESULT IN IMPROPER APPLICATION, INSTALLATION AND/OR OPERATION OF
THESE PRODUCTS IN AN EMERGENCY SITUATION, WHICH COULD RESULT IN PROPERTY DAMAGE, SERIOUS INJURY OR DEATH TO
YOU AND/OR OTHERS.
INSTALLATION INSTRUCTIONS:
SPEAKER WATTAGE SELECTOR SWITCH SETTING: (See Installation Sheet P82697)
1. Remove the cable entrance interface adaptor and gasket.
2. Adjust the Speaker Wattage Selector Switch for the desired dB and wattage setting for each speaker.
3. Replace the cable entrance interface adaptor and gasket.

MOUNTING INSTRUCTIONS:

1. Loosen the 4 Phillips screws holding the cover plate and the RSS-24MCCH Strobe to the enclosure box. (See Figure 1)
2. Remove the cover plate.
3. Mount the speaker assembly to the desired location.
4. Punch out desired knockouts and attach conduit and fittings.
5. Connect all field wiring as per wiring information in Figure 3 or 4.
6. Replace cover plate to the enclosure box and tighten the 4 Phillips screws.
7. Adjust the angle for the speakers to point to the desired direction. Be sure that the speakers do not block the strobe view. (See Figure 5)
Copyright 2007 Cooper Wheelock, Inc. All rights reserved.
Thank you for using our products.
INSTALLATION INSTRUCTIONS
CLUSTER SPEAKER STROBE ASSEMBLY
Table 1: Models
Model
STH-2R24MCCH(X)
STH-2G24MCCH(X)
STH-3R24MCCH(X)
STH-3G24MCCH(X)
STH-4R24MCCH(X)
STH-4G24MCCH(X)
STH-90-R24MCCH(X)
* Each Speaker is a STH-15 UL Listed under UL 1480 for Speaker Appliances.
G= Grey, R=Red (X) = Lens color (A=amber, B=blue, G=green, R=red)
Number of Speakers *
2
3
4
2
. All warnings are printed in bold capital letters.
FAILURE TO COMPLY WITH ANY OF THE FOLLOWING
P84327 H
Sheet 1 of 4
