  • Page 1 USER GUIDE JERRY DOUGLAS SIGNATURE SERIES AURA ® IMAGING PEDAL...

  • Page 2: Quick Start

    Quick start Power – Install a 9V alkaline or lithium battery (not included). Set the controls – Volume at minimum, select at #1 and blend at its mid-point. Plug in – Use standard ¼-inch shielded instrument cables. Place any other pedals after the Aura.
  • Page 3 ® A C O U S T I C I M A G I N G...

  • Page 4: About This Pedal

    About this pedal Larry Fishman developed the Signature Series Aura Pedal with a world-class team of professionals, including musician Jerry Douglas, recording studio engi- neer Bil VornDick, and reknowned resonator builder Paul Beard, to bring you the most realistic amplifi ed tone available. Night after night, or any time you record, this pedal lets you reproduce the tone that can only be created by such trade masters.
  • Page 5 A word from Paul Beard “In the world of resophonic guitar amplifi cation, we fi nally have resolution! The Fishman Nashville Series resophonic pickup is the result of new technology and innovative design. Use this pickup when playing with the Aura Imaging Pedal, select a microphone Image and turn it up.
  • Page 6 Images Image Microphone Neumann U67 Neumann U67 RCA 77 RCA 77 Neumann M149 Neumann M149 Crowley Tripp El Diablo Shure SM81 Type Large diaphragm tube condensor Large diaphragm tube condensor Poly-directional ribbon Poly-directional ribbon (Instrument drop tuned to CAFCAF) Large diaphragm tube condensor Large diaphragm tube condensor Figure 8 ribbon Uni-directional small condensor...
  • Page 7 Neumann FET 47 Crowley Tripp Soundstage Neumann KM84 Shure KSM 32 Shure SM-57 Fishman Transducers, Inc. is not affi liated with any of the forementioned companies, Type Figure 8 Ribbon (Instrument drop tuned to CAFCAF) Lg. diaphragm cardioid tube condensor 12”...

  • Page 8: Using Effects

    Using effects When using your Aura Imaging Pedal with other effects devices, place the Aura Imaging Pedal fi rst in the chain after your guitar. ® A C O U S T I C I M A G I N G...
  • Page 9 If you have a pedal tuner, place it before the Aura Imaging Pedal. ® A C O U S T I C I M A G I N G...

  • Page 10: Left Side Panel

    Left side panel Output Use a standard ¼-inch instrument cable to connect the output to your amplifi er, mixer or effects devices. You can also connect this output to an unbalanced input on a recording system. 9vdc See Power section.

  • Page 11: Right Side Panel

    Right side panel Input Plug in your guitar here with a standard ¼-inch instrument cable. If you have a passive undersaddle pickup (no battery onboard), always plug into the Aura Imaging Pedal fi rst, even if you use a pedal tuner. T rim Raise or lower the trim to optimize the input level for your pickup.

  • Page 12: Control Set

    Control set Phase switch Use the phase switch to improve bass response at low volume or to control feedback at high volume. Play your guitar and toggle the phase switch back and forth until you achieve the desired result. Volume For the cleanest signal, set the volume as high as possible without clipping the next device in the signal chain.
  • Page 13 Select The 16 Images you can choose with the select knob are hand picked for your type of guitar. Try all 16 and pick the ones that compliment your playing style and sound good in the room. For example, dark/deep sounding Images may add impact to a solo performance.
  • Page 14 Blend (continued) Suggestions • To fi nd a good mix of Image and pickup, turn the blend knob to about 8 o’clock, then step on the footswitch. Compare the Image/ pickup mix to the dry pickup signal. Slowly move blend clockwise and then switch between the two until you are happy with the Image/pickup blend.
  • Page 15 Footswitch Step on the footswitch to bypass the Aura effect. When you stomp, you’ll hear the dramatic difference between the Image blend and the dry pickup. When the light above the footswitch is on, the Image is active. Note when the effect is bypassed, your guitar signal remains buffered.
  • Page 16 Imaging Pedal powers up. To conserve the battery, remove the plug from the input when not in use. For AC power, use the Fishman 910-R ( for 110V ) or other suitable 9V adapter. The adapter must be fi ltered, regulated and rated for at least 200mA. It should also accept AC power appropriate for your country.

  • Page 17: Battery Replacement

    Battery replacement The clip/batt indicator will light steadily when it is time to change the battery. Open the battery door underneath the pedal and install a fresh 9V alkaline or lithium battery. When the clip/batt LED comes on you have approximately one hour of remaining battery life.

  • Page 18: Specifications

    All specifi cations subject to change without notice. 24-bit 32-bit 9V alkaline battery or 9VDC adapter 18mA 27 hours Fishman 910-R ( for 110V ) or suitable fi ltered and regulated, 200mA type, tip = negative 10M Ohm 3.5k Ohm -10dB to +2dB...
