Summary of Contents for Sony Vaio PCG-F340
- Page 2 Sony and VAIO are trademarks of Sony. Intel logo and Intel CAUTION: Danger of explosion if battery is incorrectly Inside logo are registered trademarks of Intel Corporation.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Section Title Page Section Title Page CHAPTER 1. REMOVAL CHAPTER 2. SELF DIAGNOSTICS 1-1. Flowchart ................. 1-1 2-1. Required Tools and Peripheral Devices ......2-1 1-2. Main Electrical Parts Location Diagram ......1-1 2-2. Tools and Peripheral Device Connection ......2-3 1-3. -
Page 4: Chapter 1. Removal
CHAPTER 1. REMOVAL 1-1. Flowchart BEZEL DISPLAY INVERTER HOUSING HOUSING UNIT ASSY ASSY ASSY P 1-6 P 1-6 P 1-6 P 1-6 (P 1-8) (P 1-8) (P 1-8) (P 1-8) P 1-10 P 1-10 P 1-10 P 1-10 PALM RESET POWER ASSY HOOD KEYBOARD... -
Page 5: Hinge Cover
1-3.Removal 1. Hinge Cover 2Hinge Cover 1Door I/O 2Hinge Cover 2. Keyboard Unit, Palm Rest Housing Assy, Assy Hood Keyboard 1M2X5 Special Head (X2) 2Pull it up sliding it 3M2X4 to the right. Keyboard Unit Assy Hood Keyboard 6M2X4 Special Head (X2) 7Pull it to the front slightly and raise to remove it. -
Page 6: Display Assy, Cd-Rom Drive
3. Display Assy, CD-ROM Drive Display Assy 5+PS 2X6 (X2) 6+PS 2X6 2M2X4 (X3) 1Bolt (M2X2) Spring (X3) 6+PS 2X6 7+B 2.6X5 1Bolt (M2X2) Spring 7+B 2.6X5 CD-ROM Drive 4. DC Fan, SWX-28 Board 3+B 2X16 (X3) IrDA Bracket PW Sheet 1M2X4 (X2) DC Fan SWX-28 Board... -
Page 7: Hdd Assy, Pws-5 (-2) Board, Latch Detector Unit, Swx-30 (-2) Board
5. HDD Assy, PWS-5 (-2) Board, Latch Detector Unit, SWX-30 (-2) Board 7HDD Assy 5M2X4 6Flexible Connector 4PWS-5 (-2) Board 3M2X4 2Latch Detector Unit 1M2X4 2SWX-30 (-2) Board 6. PC Card Connector, IFX-56 Board, CNX-50 Board, MPM-12 Board, MBX-15 (-2) Board MPM-12 Board 1+B M2 !™M2X9 (X2) -
Page 8: Battery, Lithium
7. Battery, Lithium Flash Door 1+P 2X2.5 TYPE3 (X2) 8. Speaker Unit, SWX-29 Board 3M2X4 (X2) SWX-29 Board 2M2X4 (X5) 3M2X4 (X2) Speaker Unit Speaker Unit PCG-F340/F350/F360 (UC) -
Page 9: Lcd Section (F350/F360 Model) (Made By Samsung)
9. LCD Section (F350/F360 Model) (Made by Samsung) 1. Bezel Housing Assy, LCD Unit (14 inch), Display Housing Assy, Inverter Assy 1Upper Screw Cover Bezel Housing Assy 2M2X4 1Lower Screw Cover : claw part 2M2X4 1Upper Screw Cover 2M2X4 1Lower Screw Cover How to release the claw a Bezel Housing Assy... -
Page 10: Hinge Left, Hinge Right, Lcd Cable
2. Hinge Left, Hinge Right, LCD Cable 1M2X4 Special Head (X4) Hinge Left LCD Cable 1M2X4 Special Head (X4) Hinge Right PCG-F340/F350/F360 (UC) -
Page 11: Lcd Section (F350/F360 Model) (Made By Hitachi)
10. LCD Section (F350/F360 Model) (Made by Hitachi) 1. Bezel Housing Assy, LCD Unit (14 inch), Display Housing Assy, Inverter Assy 1Upper Screw Cover Bezel Housing Assy 2M2X4 1Lower Screw Cover : claw part 2M2X4 1Upper Screw Cover 2M2X4 1Lower Screw Cover How to release the claw a Bezel Housing Assy... -
Page 12: Hinge Left, Hinge Right, Lcd Cable
2. Hinge Left, Hinge Right, LCD Cable 1M2X4 Special Head (X2) Hinge Left 1M2X4 Special Head (X2) Hinge Right LCD Cable PCG-F340/F350/F360 (UC) -
Page 13: Lcd Section (F340 Model)
11. LCD Section (F340 Model) 1. Bezel Housing Assy, LCD Unit (13 inch), Display Housing Assy, Inverter Assy 1Upper Screw Cover Bezel Housing Assy 2M2X4 1Lower Screw Cover : claw part 1Upper Screw Cover 2M2X4 2M2X4 1Lower Screw How to release the claw a Cover Bezel Housing Assy 5M2X4... -
Page 14: Hinge Left, Hinge Right, Lcd Cable
2. Hinge Left, Hinge Right, LCD Cable 1+PS 2.6X4 (X2) Hinge Left Hinge Right 1+PS 2.6X4 (X2) LCD Cable 1-11 PCG-F340/F350/F360 (UC) (END) -
Page 15: Chapter 2. Self Diagnostics
CHAPTER 2. SELF DIAGNOSTICS 2-1. Required Tools and Peripheral Devices Tools and Peripheral Devices Test Items Serial Loopback Tool Loopback tool specified by QA and Factory Serial Port (COM) test (Refer to next page.) Parallel Loopback Tool Loopback Tool specified by QA and Factory Parallel Port (printer) test (Refer to next page.) V.34 Modem and Line Simulator... - Page 16 [Reference] On Serial/Parallel Loopback Tool • The serial loopback tool and the parallel loopback tool are necessary for diagnostics of the serial communication line and the parallel communication line. Fabricate the serial loopback tool and the parallel loopback tool locally referring to the connection diagrams shown below.
-
Page 17: Tools And Peripheral Device Connection
2-2. Tools and Peripheral Device Connection System Connection Diagram 4VGA monitor VGA OUT 2Parallel 1Serial loopback tool loopback tool Serial I/F Serial output 7,!¢PCG-505G series Parallel Modem output 3Transmission line simulator IrDA send/ receive PPK Button port-1394 Phone connector jack 6USB tester 5PC card tester CD-ROM... -
Page 18: How To Start The Diagnostics
2-3. How to Start the Diagnostics Precaution: The supplied floppy disk containing the diagnostics program can be damaged because it will be written the Log and used as FDD read-write test. Be sure to make a backup of the diagnostics floppy disk and use a backup disk for diagnostics. -
Page 19: Short Descriptions Of The Test Items
12. Mouse test 13. Parallel loopback test 14. PC Card test 15. Serial loopback test 16. USB test 17. Port Replicator connector test 18. IrDA test 19. Video test 20. IEEE1394 test 21. PPK test 22. Aging (Short time) HDD test 23. - Page 20 2. The ordinary DOS prompt “A:\>” appears. Input “G:[Enter]”. Then remove the FDD and insert the battery 2 instead of the FDD. 3. The prompt “G:\>PRG” appears and the active drive is changed. Input “CD \FD” to change directory. 4. When the prompt “G:\FD>” appears, input the command “BATT2”. 5.
- Page 21 15. Serial loopback test Tests the COM port. The serial loopback jig is necessary. Connect the serial loopback jig to the COM port. 16. USB test Tests the USB port. To perform this test, the USB jig is necessary. Connect the USB jig to the USB port. 17.
-
Page 22: About The Password Bypass
When item “ 3: Return to START MENU ” of the start menu is selected, the following display appears. Password Bypass Program 1999 Sony Corporation All rights reserved. Input last 7 bytes of Serial number (if serial xxxxxxxx-ooooooo , input serial number... -
Page 23: Chapter 3. Block Diagram
CHAPTER 3. BLOCK DIAGRAM PCG-F3 Series LCD(Panel) BLOCK DIAGRAM Rev . 0.9 North Module 15"/14"/13.3"/13" [DIXON-256K/Celeron128K] PenII-256K 333/366/400MHz MPM-12 BOARD TFT / HPA (66MHz FSB & No AGP) Processor Core with 256KB L2 cache XGA 1024x768 48MHz PCGA-PRF1 Ext RGB Celeron-128K 300/333/366MHz 66 MHz Port... -
Page 24: Chapter 4. Frame Harness Diagram
CHAPTER 4. FRAME HARNESS DIAGRAM (Option) PWS-5 (-2) SWX-30 (-2) CNX-64 Side-B Side-A CN 300 DIMM CN201 CN202 CN6002 CN6001 CN5101 B140 DC FAN B139 PALM A140 CN6005 A139 REST CN400 BATTERY FDD BAY CN6003 PACK CN300 CN402 Side-B DRIVE Side-A CN6004 MPM-12... -
Page 25: Chapter 5. Exploded Views And Parts List
CHAPTER 5. EXPLODED VIEWS AND PARTS LIST NOTE: The components identified by mark ! or • The mechanical parts with no reference number in the dotted line with mark ! are critical for safety. exploded views are not supplied. Replace only with part number specified. •... -
Page 26: Main Section
5-1. Main Section Ref.No. Part No. Description Ref.No. Part No. Description X-4622-490-1 ASSY BOTTOM (NHA) 4-643-794-11 COVER BATTERY CONNECTOR (EP) 4-640-837-11 DOOR BATTERY * 64 4-641-188-01 SPACER MODEM A-8056-427-A RO-27 COMPLETE PWB (K3) 4-644-664-01 INSULATOR MODEM A 1-542-331-11 MICROPHONE UNIT 4-644-665-01 INSULATOR MODEM B 4-641-495-02 HOLDER MIC * 67... - Page 27 Ref.No. Part No. Description 7-627-854-08 PRECISION SCREW +P 2X2.5 TYPE3 7-621-772-80 SCREW +B 2X16 7-621-256-00 SCREW +P 2X16 4-639-112-01 SCREW M2X4 4-641-655-02 SCREW (M2X5), + SPECIAL HEAD 4-641-656-02 SCREW (M2.5), 0 PLATE P 7-621-775-20 SCREW +B 2.6X5 4-641-726-11 SCREW (M2), SPECIAL HEAD 4-640-694-41 BOLT (M2), SPRING 7-685-106-19 SCREW +P 2X10 TYPE2 NON-SLIT 4-642-229-01 TAPPING (B 2X)
-
Page 28: Lcd Section (F350/F360 Model)
5-2. LCD Section (F350/F360 Model) Ref.No. Part No. Description Ref.No. Part No. Description 1-418-578-11 INVERTER UNIT 4-641-726-11 SCREW (M2), SPECIAL HEAD 5-2-1. LCD Made by Samsung X-4622-432-1 HINGE LEFT 14 (SA) 7-628-254-00 SCREW +PS 2.6X5 X-4622-431-1 ASSY HOU, BEZEL 14 (SA) 7-628-253-20 SCREW +PS 2X6 4-635-277-11 COVER SCREW LOWER 4-635-276-11 COVER SCREW UPPER... -
Page 29: Lcd Made By Hitachi
5-2-2. LCD Made by Hitachi Ref.No. Part No. Description Ref.No. Part No. Description 1-418-297-22 INVERTER UNIT 4-641-726-11 SCREW (M2), SPECIAL HEAD X-4622-263-1 HINGE LEFT 14T (B) 7-628-254-00 SCREW +PS 2.6X5 X-4622-396-2 ASSY HOU, BEZEL 14 (NH) 7-628-253-20 SCREW +PS 2X6 4-635-277-11 COVER SCREW LOWER 4-635-276-11 COVER SCREW UPPER 4-637-902-31 LATCH... -
Page 30: Lcd Section (F340 Model)
5-3. LCD Section (F340 Model) Ref.No. Part No. Description Ref.No. Part No. Description 1-418-297-12 INVERTER UNIT ACCESSORIES X-4622-261-1 HINGE LEFT 13H ************ X-4622-395-2 ASSY HOU, BEZEL 13H (NH) !303 4-635-277-11 COVER SCREW LOWER 1-782-614-11 CORD, POWER 4-635-276-11 COVER SCREW UPPER A-8046-144-A WEIGHT SAVER ASSY A-8046-136-A ASSY WEIGHT SAVER (NHA) 4-637-902-31 LATCH... - Page 31 (1/1) QUICK MEMO No. FIT- M2001_043K ! J " UC ! E ! I The object of information Date : 2001.6.29 Technical " Parts Other information From : MNC IT Planning & Control Dept. The relation document to the plan of [SNT] T/N "...
- Page 32 Service Manual Update List Date of the Lastest Update 2001.06.29 ADD : ADDITION COR : CORRECTION DEL : DELETION Update Contents Medium Classification Page Section Details Type Date Ver. Main Section Ref.107 A-8045-905-A 1-418-716-11 Quick Memo M2001_043K 2001.06.29 Ver. 2...
