Figure 13. Electrical Components - COBHAM ELT/NAV INTERFACE Abbreviated Component Maintenance Manual

COBHAM AVIONICS WULFSBERG ELECTRONICS
ABBREVIATED COMPONENT MAINTENANCE MANUAL
ELT/NAV
INTERFACE
(REF.)
FIG # ITEM PART #
13 01 150-6503
02 151-2100
03 183-6503
04 150-6502
05 151-2101
06 183-6502
– 151-2102
– 150-6504
453-6500

Figure 13. Electrical Components

01
02
1234 NOMENCLATURE
Connector, #16 Circular (24-Position)
***
. Contact, Socket #20
Strain Relief, #16
***
Connector, #18 Circular (31-Position)
***
. Contact Pin, #20
Strain Relief, #18
***
. Plug, Sealing #20
***
Protective Cap, 31-Position Connector
***
25-69-10
04
05
06
03
UPA
1
26
1
1
33
1
42
1
Page 58 of 58
APR 06/10
