Illustrated Parts List; Introduction; Purpose; Ipl Usage Guide - COBHAM ELT/NAV INTERFACE Abbreviated Component Maintenance Manual

TASK 25-69-10-990-801

1. Introduction

SUBTASK 25-69-10-990-001
A.

Purpose

(1) This illustrated parts list (IPL) illustrates and lists the spare parts, with attaching hardware,
applicable to the ELT/NAV Interface.
(2) Parts and components not listed herein, are not field replaceable and repairs requiring parts
outside the scope of this manual must be accomplished by the manufacturer.
SUBTASK 25-69-10-990-002
B.

IPL Usage Guide

(1) If the part number is not known:
(a) Find the part in the IPL Figure illustration.
(b) Note the item number assigned to the part.
(c) Refer to the associated parts list and find the item number in the "Fig # & Item" column.
(2) If the part number is known:
(a) Refer to the parts list and find the part in the "Part #" column.
(b) Note the figure number and item number assigned to the part.
(c) Refer to the illustration in the applicable IPL figure to find attaching hardware and
related assembly parts.
(3) In cases where multiple item numbers are shown on an illustration for the same item, there is
more than one part number option associated with that item.
