TASK 25-69-10-870-804

4. Specifications

SUBTASK 25-69-10-870-001
A.

Physical and Environmental

(1) Table 3 lists the ELT/NAV Interface physical and environmental specifications.
PARAMETER
Temperature (Storage)
Temperature (Operating)
Crashworthiness
Spurious Emissions
Flammability
Dimensions
COBHAM AVIONICS WULFSBERG ELECTRONICS
ABBREVIATED COMPONENT MAINTENANCE MANUAL
453-6500

Table 3. Physical and Environmental Specifications

Altitude
Vibration
Shock
Humidity
Impact
Crush
Weight
CHARACTERISTIC
-55° C to +85° C
-20° C to +55° C
55,000 ft (16,764 m)
g
10 from 5 Hz to 2,000 Hz
g
500 for 4 ms
g
100 for 23 ms
95% for 50 hrs
55 lbs from 6 in. (24.9 kg from 152 mm)
1,000 lbs (453.6 kg)
Per RTCA/DO-204
Self-Extinguishing
2.8 lbs (1.27 kg)
9.3 x 5.0 x 1.9 in. (236 x 127 x 48 mm)
25-69-10
Page 28 of 58
APR 06/10
