KIT CONTENTS
Seagate ® BlackArmor
PS 110 Drive
INSTALL DRIVER
1. Connect the USB 3.0 cable to the BlackArmor
computer.
Complete steps 2 and 3 if the driver does not automatically install.
2. Navigate to the BlackArmor PS 110 drive location (Computer > BlackArmor Drive >
USB 3.0 PC Card Adapter)
3. Double-click PC Card Adapter Driver.exe to install the USB 3.0 driver.
4. Once the USB 3.0 driver is installed, safely remove (disconnect) the PS 110 drive from
your computer. (Keep the cable connected to the drive.)
CONNECT KIT
Connect the USB power cable's DC plug
1
to the USB 3.0 PC Card Adapter and to
a USB port on your computer. The LED
on the USB 3.0 PC Card Adapter turns
red to indicate that it is not ready for the
PS 110 drive to be connected.
3
1
100599563_PS110_US_QSG.indd 2
USB 3.0
®
PC Card Adapter
® PS 110 drive and to a USB port on your
Insert the USB 3.0 PC Card Adapter
2
into your computer's ExpressCard™
slot. The LED turns green to indicate
that the PC Adapter Card is now ready
and has sufficient power.
Connect the USB 3.0 cable (attached to
3
the PS 110 drive) to the USB 3.0 PC
Adapter Card port.
2
USB 3.0
Cable
INSTALL BACKUP SOFTWARE
After drive is connected, software
installer automatically launches.
If the installation does not begin
automatically, double-click Setup.exe
on your BlackArmor PS 110 drive or visit
http://support.seagate.com/autorun
for additional instructions.
NOTE: The optional BlackArmor Backup
software can be installed at any time.
Print Date:2010-Jan-6 14:29:40 CST Released; Prod Rel; A; 100599563 Seagate Confidential
USB
Power Cable
Follow the on-screen instructions.
RECOMMENDED: Create Recovery CD
Be sure to create a system recovery CD using
BlackArmor Backup Software. Your system and
data can be restored using this CD. See the
BlackArmor Backup User Guide for instructions.
®
When disconnecting the drive, ensure that
you use the safely remove hardware feature.
Right-click the safely remove icon in the
notification area and then follow the instructions.
