  • Page 1 Owner's Manual netwOrk MOnitOr Please read the safety information carefully before using the product. network Monitor Model n2311aZ www.lg.com...

  • Page 2: Table Of Contents

    Table of Contents TablE of ConTEnTs assEMblInG anD TRoUblEsHooTInG PREPaRInG Unpacking PRoDUCT sPECIfICaTIon Parts and buttons Preset Mode Lifting and moving the Monitor Power Indicator Setting Up the Monitor set - Attaching the Stand Base PRoPER PosTURE - Mounting on a table - Adjusting the angle Proper posture for using the monitor - Adjusting the stand height...

  • Page 3: Assembling And Preparing

    15-pin D-sUb signal Cable stand base CaUTIon Only use an approved LG power adapter. Damage caused by other power adapters is not covered by warranty. noTE Note that the components may look different from those shown here. Without prior notice, all information and specifications in this manual are subject to change to improve the performance of the product.

  • Page 4: Parts And Buttons

    assEMblInG anD PREPaRInG Parts and buttons Input Connectors (See p.16 ) Power Indicator LED On : Power is on LED Off: Power is off (Power Button) Front Side Buttons Input Connectors (See p.13 to 16)
  • Page 5 assEMblInG anD PREPaRInG button Description MENU Activates the main menu. osD lock/Unlock Locks/unlocks the OSD screen. functions y To lock the OSD screen, press and hold the MENU button for several seconds. The "OSD LOCKED" message will be displayed and the screen will be locked. y To unlock the OSD screen, press and hold the MENU button again for several seconds.

  • Page 6: Lifting And Moving The Monitor

    assEMblInG anD PREPaRInG lifting and moving the setting Up the Monitor set Monitor attaching the stand base Please heed the following information when moving the monitor. Place the monitor's screen face down. CaUTIon CaUTIon To protect the screen from scratches, cover Avoid touching the screen at all times, as this the surface with a soft cloth.

  • Page 7: Mounting On A Table

    ASSEMBLING AND PREPARING Mounting on a table Adjusting the angle Lift the monitor and place it on the table in an Place the monitor mounted on the stand base upright position. in an upright position. Install at least 10 cm away from the wall to ensure sufficient ventilation.

  • Page 8: Adjusting The Stand Height

    assEMblInG anD PREPaRInG adjusting the stand height Using the Kensington locking device Place the monitor mounted on the stand base The connector for the Kensington lock is located in an upright position. on the rear of the monitor. For more information on installation and usage, Remove the tape attached at the bottom rear refer to the Kensington lock user manual or visit of the stand body, then pull out the locking...

  • Page 9: Detaching The Stand Base

    assEMblInG anD PREPaRInG Detaching the stand base Detaching the stand body Place the monitor's screen face down. Place the monitor's screen face down. To protect the screen from scratches, cover the To protect the screen from scratches, cover the surface with a soft cloth. surface with a soft cloth.

  • Page 10: Swivel Stand

    ASSEMBLING AND PREPARING Swivel stand Be careful with the cables when rotating the screen. Image shown may differ from your Monitor set. Swivel 356 degrees and adjust the angle of the Monitor set to suit your view. Using the Pivot function The pivot function allows you to rotate the screen 90 degrees clockwise.

  • Page 11: Installing The Wall Mount Plate

    Mounting on a wall This monitor has a VESA compatible mount on the Install the monitor at least 10 cm away from the back. Most mounts will require an LG mounting wall and leave about 10 cm of space at each side plate.
  • Page 12 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Please use a LG wall mounting bracket when using a VESA mount. For more information, contact your local retail store or a qualified installer.

  • Page 13: Using The Monitor Set

    UsInG THE MonIToR sET UsInG THE MonIToR sET Connecting Input signal Cable D-sUb oUT connection - PCoIP This monitor supports the *Plug and Play feature. D-SUB OUT can only mirror the image displayed *Plug and Play: A feature that allows you to RGB OUT on the monitor.

  • Page 14: Dvi Connection - Pcoip

    UsInG THE MonIToR sET DVI connection - PCoIP CaUTIon Transfers video signals to another monitor. Con- Connect the input signal nect the monitor using the DVI cable as illustrated cable and tighten in the below. direction of the arrow. To It is used for the expansion or replication of PCoIP prevent disconnection mode screen.

  • Page 15: Connecting Lan/Peripherals

    UsInG THE MonIToR sET Connecting lan/Peripherals noTE lan connection - PCoIP The LAN cable is sold separately. The following LAN cable type can be used: The LAN connection transmits PCoIP signals to Standard: IEEE 802.3 ETHERNET the monitor. Connect the router or switch to the If a device is connected into the earphone monitor using a LAN cable as illustrated below.

  • Page 16: Peripheral Device Connection

    UsInG THE MonIToR sET Peripheral device connection noTE Connect peripheral devices to the monitor using Peripheral devices are sold separately. USB, microphone and headphone ports. The USB ports on the left and bottom of the monitor can be used to connect the key- board, mouse, and other USB devices.

  • Page 17: Self Image Adjustment

    UsInG THE MonIToR sET self Image adjustment Press the power button on the front to turn on the monitor. When powered on, the "self Image adjustment" function will run automatically (only available for analog [D-SUB input] signals). noTE What is "Self Image Adjustment"? This func- tion runs when the monitor is connected for the first time and performs automatic image adjustment for each signal (only available for...

  • Page 18: Customizing Settings

    CUsToMIZInG sETTInGs CUsToMIZInG sETTInGs accessing The Main Menus Press any button on the front of the monitor to display the MONITOR SETUP OSD menu. Press to select the desired menu item. To change the settings of the selected item press the buttons on the front of the monitor. To return to the upper menu or set other menu items, use the up arrow ( ) button.

  • Page 19: Menu Settings

    CUsToMIZInG sETTInGs MEnU settings Picture Press any button on the front of the monitor to dis- play the MonIToR sETUP OSD menu. Press the MEnU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor.

  • Page 20: Color

    CUsToMIZInG sETTInGs Color Press any button on the front of the monitor to dis- play the MonIToR sETUP OSD menu. Press the MEnU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor.

  • Page 21: Display

    CUsToMIZInG sETTInGs Display Press any button on the front of the monitor to dis- play the MonIToR sETUP OSD menu. Press the MEnU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor.

  • Page 22: Others

    CUsToMIZInG sETTInGs others Press any button on the front of the monitor to dis- play the MonIToR sETUP OSD menu. Press the MEnU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor.

  • Page 23: Auto Settings : D-Sub Input

    CUsToMIZInG sETTInGs aUTo settings : D-sUb Input Press any button on the front of the monitor to dis- play the MonIToR sETUP OSD menu. PRoCEssInG aUTo IMaGE aDJUsTMEnT Press the aUTo button to automatically adjust the foR oPTIMal DIsPlaY screen. CHanGE REsolUTIon To 1920 x 1080 Select EXIT to leave the OSD menu.

  • Page 24: Troubleshooting

    Troubleshooting TRoUblEsHooTInG nothing is displayed on the screen Is the monitor's power cord plugged in? y Check if the power cord is correctly plugged in to the outlet. Is the power indicator on? y Check the power indicator. y Adjust the brightness and the contrast. Is the power indicator displaying as red? y If the monitor is in power saving mode, move the mouse or press any...
  • Page 25 Troubleshooting The image is displayed abnormally. Does the display area appear un- Pressing the AUTO button will automatically optimize the screen to the current centered? display mode. Does the screen exhibit vertical Pressing the AUTO button will automatically optimize the screen to the current lines? display mode.

  • Page 26: Product Specification

    Specifications Product SPEcification LCD Screen Type 58.42 cm (23 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Diagonal length of the screen: 58.42 cm Pixel Pitch 0.2652 mm x 0.2652 mm Resolution Maximum Resolution 1920 x 1080 @ 60 Hz Recommended Resolution 1920 x 1080 @ 60 Hz Video Signal Horizontal Frequency...

  • Page 27: Preset Mode

    Product Specification Preset Mode Display Modes Horizontal Vertical Polarity (H/V) Remark (Resolution) frequency (kHz) frequency (Hz) 720 x 400 31.468 70.08 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1280 x 1024 63.981 60.02 1680 x 1050 65.290 59.954...

  • Page 28: Proper Posture

    Proper Posture PRoPER PosTURE Proper posture for using the monitor Adjust the angle so that the screen is slightly lower than your eyes. Using the monitor for a prolonged period of time can cause eye fatigue. Take a 10-minute break every hour.

  • Page 29: Using Pcoip Solution

    Using PCoIP Solution USIng PCoIP SolUtIon notE Menus and functions in PCoIP mode may be Figure 2-2. Network Not Ready (Detail) slightly different depending on the firmware version.The manual for each version can be downloaded from the Teradici website: http:// www.teradici.com.
  • Page 30 Using PCoIP solution Selecting one of the options will produce a settings network Tab window. The Network tab allows the administrator to config- ure the portal network parameters. noTE The network parameters can also be con- figured using the Webpage Administration Interface.
  • Page 31 Using PCoIP solution y Gateway label Tab The Gateway field contains the gateway IP ad- The Label tab allows the administrator or host to dress of the device. If DHCP is disabled, this field add customized information to the portal. is required.
  • Page 32 Using PCoIP solution Connection Management Tab Table 2-1 shows the configuration parameters that The Connection Management tab allows the can be used with one of the two methods. If an user to enable or disable the connection man- incorrect IP address or DNS name is provided, an agement and specify the connection manager's OSD message is displayed prompting the adminis- IP address.
  • Page 33 Using PCoIP solution Discovery Tab session Tab The Discovery tab allows the administrator to eas- The Session tab allows the administrator to set the ily find a portal in the PCoIP system. method to connect the device to a peer device. noTE noTE The Discovery parameters can also be con-...
  • Page 34 Using PCoIP solution RDP Tab y audio Mode The RDP tab allows the administrator to configure The Audio Mode field is used to set the audio play- the remote desktop protocol (RDP) specific set- back location of the RDP session. The available tings.
  • Page 35 Using PCoIP solution osD Tab Reset Tab The OSD tab allows the administrator to modify the The Reset tab allows the administrator to reset all On Screen Display (OSD) parameters. configurable parameters stored in Flash. noTE noTE The OSD parameters can also be configured The Reset function can also be accessed using the Webpage Administration Interface.
  • Page 36 Using PCoIP solution Display Tab y Enable VMware View The Display tab allows the user to configure the The Enable VMware View option allows the user to EDID function of the monitor. configure the portal to use the VMware View Con- nection Server.
  • Page 37 Using PCoIP solution Event log Tab session statistics Tab The Event Log tab allows the administrator to view The Session Statistics tab allows the administrator and delete the event log messages from the portal. to view the PCoIP specific statistics of the last ac- tive PCoIP session from the portal.
  • Page 38 Using PCoIP solution y bytes statistics Ping Tab y Bytes Sent The Ping tab allows the administrator to perform a The Bytes Sent field shows the total number ping test to the device and check if it can reach the of bytes sent in the last active session.
  • Page 39 Using PCoIP solution Information Window PCoIP Processor Revision In the Information window, the administrator can This shows the PCoIP processor's revision code. access the Version tab that contains the device TERA1x00 Revision A silicone is denoted by 0.0 related information. and TERA1x00 Revision B silicone is denoted by 1.0.
  • Page 40 Using PCoIP solution Mouse Tab Keyboard Tab The Mouse tab allows the user to modify the OSD The Keyboard tab allows the user to modify the and RDP session's mouse cursor speed setting. OSD and RDP session's keyboard repeat setting. noTE noTE The OSD keyboard setting does not affect...
  • Page 41 Using PCoIP solution Image The Image tab allows a user to change the image settings on the PCoIP system. noTE The Image parameters can also be con- figured using the Webpage Administration Interface. Figure 2-24. Image y Minimum Image Quality The Minimum Image Quality slider allows the ad- ministrator to make compromises between image quality and frame rate when network bandwidth...
  • Page 42 Make sure to read the safety Precautions before using the product. keep the Owner’s Manual (CD) in an accessible enerGY star is a set of power-saving place for future reference. guidelines issued by the u.s.environmental the model and serial number of the set is Protection agency(ePa).
