Summary of Contents for LG N2210WZ-BF

  • Page 1 OWNER'S MANUAL NETWORK MONITOR Please read the safety information carefully before using the product. Network Monitor Model N2210WZ www.lg.com...

  • Page 2: Table Of Contents

    Table of Contents TABLE OF CONTENTS ASSEMBLING AND PREPARING Unpacking Parts and buttons Setting Up the Monitor set - Attaching the Stand Base - Detaching the stand base - Adjusting the stand height - Adjusting the angle - Mounting on a table - Using the Kensington locking device - Detaching the stand body - Swivel stand - Installing the wall mount plate - Mounting on a wall USING THE MONITOR SET Connecting Input Signal Cable - D-SUB IN connection - PC - D-SUB OUT connection - PCoIP - DVI connection - PCoIP Connecting LAN/Peripherals - LAN connection - PCoIP...

  • Page 3: Assembling And Preparing

    ASSEMBLING AND PREPARING Unpacking Please check whether all the components are included in the box before using the product. If there are missing components, contact the retail store where you purchased the product. Note that the product and components may look different from those shown here. User Manual/Card Stand Base CAUTION Only use an approved LG power adapter. Damage caused by other power adapters is not covered by warranty. NOTE Note that the components may look different from those shown here. Without prior notice, all information and specifications in this manual are subject to change to improve the performance of the product. To purchase optional accessories, visit an electronics store or online shopping site or contact the retail store where you purchased the product. ASSEMBLING AND PREPARING Power Cord 15-pin D-SUB Signal Cable Adaptor...

  • Page 4: Parts And Buttons

    ASSEMBLING AND PREPARING Parts and buttons Input Connectors (See p.14 ) Power Indicator LED On : Power is on LED Off: Power is off (Power Button) Front Side Buttons Input Connectors (See p.11 to 14)
  • Page 5 Button MENU Activates the main menu. OSD Lock/Unlock Functions VOLUME (Only PCoIP mode) Adjust the volume of the Monitor set.(See p.19) AUTO To adjust the monitor settings, press the AUTO button on the MONITOR SETUP OSD menu (only supported for analog signal). For optimal screen display, use the following resolution. Optimal Resolution INPUT Allows selection of the input signal. y If you connect the monitor to a computer using a D-SUB cable, select either the PCoIP or D-SUB input signal. y If only one computer is connected to the monitor, the input signal is detected automati- cally. The initial input signal is PCoIP. EXIT Exits the OSD menu. y D-SUB Input: Power On/Off (Power Button) y PCoIP Input Monitor Off: Press the power button and wait for 5 seconds. PCoIP Off: Press the power button twice. PCoIP On: Press the power button. Remote PC Power Control: Press the power button for at least five seconds to turn the PC on/off. * To use the Remote PC Power Control function, separate settings are required for the PC. Power Indicator ASSEMBLING AND PREPARING Description Locks/unlocks the OSD screen.

  • Page 6: Setting Up The Monitor Set

    ASSEMBLING AND PREPARING Setting Up the Monitor set Attaching the Stand Base Place the monitor's screen face down. CAUTION To protect the screen from scratches, cover the surface with a soft cloth. Check the position (at the front and rear) of the stand body, then mount the stand base on the stand body as shown in the figure. Stand Body Stand Base Using a coin, turn the screw clockwise to se- cure the stand base. Stand Base Detaching the stand base Place the monitor's screen face down.

  • Page 7: Adjusting The Stand Height

    Adjusting the stand height Place the monitor mounted on the stand base in an upright position. Remove the tape attached at the bottom rear of the stand body, then pull out the locking pin. Stand Body Tape Locking Pin The height can be adjusted up to 110 mm. CAUTION Once the pin is removed, it is not necessary to re-insert it to adjust the height. WARNING Do not put your finger be- tween the screen and the base (chassis) when adjust- ing the screen's height. ASSEMBLING AND PREPARING Adjusting the angle Place the monitor mounted on the stand base in an upright position. Adjust the angle of the screen. The angle of the screen can be adjusted up to 15° forwards and 5° backwards for a comfortable viewing experi- ence. Front Side WARNING To avoid injury to the fingers when adjusting 110.0 mm...

  • Page 8: Mounting On A Table

    ASSEMBLING AND PREPARING Mounting on a table Lift the monitor and place it on the table in an upright position. Install at least 10 cm away from the wall to ensure sufficient ventilation. 10 cm 10 cm Connect the adaptor to the monitor, then plug the power cord into the wall outlet. Press the (Power) button on the front of the monitor to turn on the monitor. CAUTION Unplug the power cord prior to moving or installing the monitor. There is risk of electric shock. Using the Kensington locking device The connector for the Kensington lock is located on the rear of the monitor. For more information on installation and usage, refer to the Kensington lock user manual or visit the website at http://www.kensington.com. Connect the monitor to the table with the Kensing- ton lock cable. 10 cm 10 cm NOTE Using the Kensington lock is optional. The...

  • Page 9: Detaching The Stand Body

    Detaching the stand body Place the monitor's screen face down. To protect the screen from scratches, cover the surface with a soft cloth. Using a screwdriver, remove the four screws and detach the stand from the monitor. Swivel stand Image shown may differ from your Monitor set. Swivel 356 degrees and adjust the angle of the Monitor set to suit your view. ASSEMBLING AND PREPARING Installing the wall mount plate This monitor has a VESA compatible mount on the back. Most mounts will require an LG mounting plate. Place the monitor's screen face down. To protect the screen from scratches, cover the surface with a soft cloth. Place the wall mount plate on the monitor and align it with the screw holes on the monitor. Using a screwdriver, tighten the four screws to fix the plate onto the monitor. Wall Mount Plate NOTE The wall mount plate is sold separately. For more information on the installation, refer to the wall mount plate's installation guide.

  • Page 10: Mounting On A Wall

    10 cm 10 cm 10 cm If you intend to mount the Monitor set to a wall, attach Wall mounting interface (optional parts) to the back of the set. When you install the Monitor set using a wall mounting interface (optional parts), attach it carefully so it will not drop. Please, Use the screw and wall mount interface in accordance with VESA Standards. If you use screw longer than standard, the monitor might be damaged internally. If you use improper screw, the product might be damaged and drop from mounted position. In this case, LG Electronics is not responsible for it. VESA compatible. Please use VESA standard as below. 784.8 mm (30.9 inch) and under * Wall Mount Pad Thickness : 2.6 mm * Screw : Φ 4.0 mm x Pitch 0.7 mm x Length 10 mm 787.4 mm (31.0 inch) and above * Please use VESA standard wall mount pad and screws. Model VESA (A x B) Stand Screw Required Screw Wall Mount Plate...

  • Page 11: Using The Monitor Set

    USING THE MONITOR SET Connecting Input Signal Cable This monitor supports the *Plug and Play feature. *Plug and Play: A feature that allows you to add a device to your computer, without having to reconfigure anything or install any manual drivers. D-SUB IN connection - PC D-SUB IN transfers analog video signals from the PC to the monitor. Connect the monitor to the PC using the provided 15-pin D-SUB signal cable as illustrated below. RGB OUT NOTE When using this device simply as a regu- lar monitor through the RGB IN port, set "PCoIP" to OFF in MENU > OTHERS to reduce energy consumption. USING THE MONITOR SET D-SUB OUT connection - PCoIP D-SUB OUT can only mirror the image displayed RGB OUT on the monitor. (it does not support an extended desktop).

  • Page 12: Dvi Connection - Pcoip

    USING THE MONITOR SET DVI connection - PCoIP Transfers digital video signals to another monitor. Connect the monitor using the DVI cable as illus- trated below. This connection is used to support an extended monitor or replicate the image displayed on the monitor. CAUTION Connect the input signal cable and tighten in the direction of the arrow. To prevent disconnection secure the cable tightly. Do not press on the screen for a prolonged time. This may cause image distortion. Do not display a still image on the screen for a prolonged time. This may cause image retention. If possible, use the screen saver. NOTE To connect the monitor to a computer, use the appropriate signal cable (LAN and D- SUB). A converter can be used to convert the DVI-I input signal to D-SUB input signal. DVI-I(D) IN When connecting the power cord to the out- MONITOR let, use a grounded (3-hole) multi-socket or a grounded wall outlet. The monitor may flicker when turned on in an area of low temperature. This is normal. Sometimes red, green or blue spots may ap- pear on the screen. This is normal.

  • Page 13: Connecting Lan/Peripherals

    Connecting LAN/Peripherals LAN connection - PCoIP The LAN connection transmits PCoIP signals to the monitor. Connect the router or switch to the monitor using a LAN cable as illustrated below. Hub/Router USING THE MONITOR SET NOTE The LAN cable is sold separately. The following LAN cable type can be used: Standard: IEEE 802.3 ETHERNET When connecting the Earphone Out or Line Out through the LAN, use the volume icon on the taskbar of your PC to adjust the volume. NOTE Connect the LAN cable and the peripheral devices prior to booting up the PC.

  • Page 14: Peripheral Device Connection

    USING THE MONITOR SET Peripheral device connection Connect peripheral devices to the monitor using USB, headphone, speaker, and microphone ports. Left Bottom NOTE Peripheral devices are sold separately. The USB ports on the left and bottom of the monitor can be used to connect the key- board, mouse, and other USB devices. Cables with angled plugs may have clear- ance issues, use straight plugs when pos- sible. Angle Type Straight Type NOTE Headphones, speakers or microphone may not work normally, depending on the server PC settings. Virtual solutions may affect the functions or speed of the specific USB storage device.

  • Page 15: Self Image Adjustment

    Self Image Adjustment Press the power button on the front to turn on the monitor. When powered on, the "Self Image Adjustment" function will run automatically (only available for analog [D-SUB input] signals). NOTE What is "Self Image Adjustment"? This func- tion runs when the monitor is connected for the first time and performs automatic image adjustment for each signal (only available for analog [D-SUB input] signals) to provide an optimal screen display. USING THE MONITOR SET...

  • Page 16: Customizing Settings

    CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Accessing The Main Menus Press any button on the front of the monitor to display the MONITOR SETUP OSD menu. Press to select the desired menu item. To change the settings of the selected item press the buttons on the front of the monitor. To return to the upper menu or set other menu items, use the up arrow ( Select EXIT to leave the OSD menu. MENU (See p.17) Sets the screen options. VOLUME (See p.19) Sets the volume. NOTE Different menu items are enabled depending on the type of input signal. D-SUB Input: MENU, AUTO, INPUT, EXIT PCoIP Input: MENU, VOLUME, The language of the monitor's OSD menu and that of the OSD menu illustrated in the CD-ROM manual may be different. Front Side Buttons AUTO (See p.21 Optimizes the resolution. / Disconnects from the server. , INPUT, EXIT ) button.

  • Page 17: Menu Settings

    MENU Settings Picture Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. Menu Analog (D-SUB) BRIGHTNESS ● CONTRAST ● SHARPNESS ● Analog: D-SUB (analog signal) input. NOTE If the screen is not displayed properly after adjusting the settings, use the "FACTORY RESET" option to revert back to the factory default settings. If necessary, enable the "WHITE BALANCE" option again. This option is enabled only for analog (D-SUB) signals. PCoIP ● Sets the brightness of the screen. ● Sets the contrast of the screen. ●...

  • Page 18: Color

    CUSTOMIZING SETTINGS Color Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. Menu Analog (D-SUB) COLOR TEMP ● PRESET ● USER ● GAMMA ● Analog: D-SUB (analog signal) input. PCoIP Allows PRESET or USER to be selected. ● sRGB Sets the screen color according to the sRGB color standard.

  • Page 19: Display

    Display Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. Menu Analog (D-SUB) HORIZONTAL ● VERTICAL ● CLOCK ● PHASE ● Analog: D-SUB (analog signal) input. Volume (Only supported in PCoIP) Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the OSD menu.

  • Page 20: Others

    CUSTOMIZING SETTINGS Others Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the MENU button to display the options in the OSD menu. Set the options by pressing the buttons on the front of the monitor. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Each option is explained below. Menu Analog (D-SUB) LANGUAGE ● PCoIP ● ORIGINAL RATIO ● WHITE BALANCE ● FACTORY RESET ● Analog: D-SUB (analog signal) input. PCoIP ● Sets the menu screen to the desired language. Allows the PCoIP to be turned ON or OFF.

  • Page 21: Auto Settings : D-Sub Input

    AUTO Settings : D-SUB Input Press any button on the front of the monitor to dis- play the MONITOR SETUP OSD menu. Press the AUTO button to automatically adjust the screen. Select EXIT to leave the OSD menu. To return to the upper menu or set other menu items, use the up arrow ( ) button. Pressing the AUTO button allows the monitor to automatically optimize the screen to the current display mode. If you are not satisfied with the optimized screen, you can manually adjust the position of the display area, frequency, phase and sharpness in the OSD menu. (Only available for D-SUB [analog] signals. Note that the sharpness setting is only available for digital sig- nals.) NOTE What is "Auto Image Adjustment"? The Auto Image Adjustment option allows you to improve the picture quality if the screen is dimmed, if the text appears blurred or spread, if the screen flickers or if the display area is not centered after adjusting the resolution. (Only available for D-SUB [analog] signals.) - / / - Settings : PCoIP Input Press any button on the front of the monitor to display the MONITOR SETUP OSD menu. Press the button for at least three seconds to disconnect from the server. Select EXIT to leave the OSD menu.

  • Page 22: Troubleshooting

    Troubleshooting TROUBLESHOOTING Nothing is displayed on the screen Is the monitor's power cord plugged in? Is the power indicator on? Is the power indicator displaying as white? Is the power indicator blinking? Is the "OUT OF RANGE" message displayed? Is the "CHECK SIGNAL CABLE" message is displayed? The "OSD LOCKED" message is displayed. Is the "OSD LOCKED" message displayed when the MENU button is pressed? The screen retains an image. Does image sticking occur even when the monitor is turned off? NOTE Vertical Frequency: In order to display an image, the screen must be refreshed dozens of times per second like a fluorescent lamp. The number of times the screen is refreshed per second is called vertical frequency or refresh rate and is represented by Hz. Horizontal Frequency: The time it takes to display one horizontal line is called the horizontal cycle. The number of horizontal lines displayed in one second can be calculated by dividing one by the horizontal cycle. This is called horizontal frequency and is represented by kHz.
  • Page 23 The image is displayed abnormally. Does the display area appear un- Pressing the AUTO button will automatically optimize the screen to the current centered? display mode. If you are not satisfied with the optimized screen, you can manually adjust the POSITION option in the OSD menu. Does the screen exhibit vertical Pressing the AUTO button will automatically optimize the screen to the current lines? display mode. If you are not satisfied with the optimized screen, you can manually adjust the FREQUENCY option in the OSD menu. Does the screen display horizontal Pressing the AUTO button will automatically optimize the screen to the current frequencies, or does the text appear display mode. blurred? If you are not satisfied with the optimized screen, you can manually adjust the PHASE option in the OSD menu. NOTE Check if the video card's resolution or frequency is within the range allowed by the monitor and set to the recommended (optimal) resolution in Control Panel > Display > Settings. Failing to set the video card to the recommended (optimal) resolution may result in blurred text, a dimmed screen, a truncated display area or misalignment of the display. The configuration procedure may differ depending on your computer and/or operating system. Also, some video cards may not support certain resolutions. If this is the case, contact the computer or video card manufacturer for assistance. The AUTO option is only available for D-SUB (analog) signals. The display color is abnormal. y Set the color to 24 bit (true color) or higher. In Windows, go to Control Does the display color appear dis- colored (16 color)?

  • Page 24: Product Specification

    Specifications PRODUCT SPECIFICATION LCD Screen Type Pixel Pitch Resolution Maximum Resolution Recommended Resolution 1680 x 1050 @ 60 Hz Video Signal Horizontal Frequency Vertical Frequency Synchronization Input Connector 15-pin D-SUB (Analog), 10/100/1000Mbps RJ45 (PCoIP) Power 19 V 3.2 A Power Consumption AC/DC Adapter Type PA-1650-68, manufactured by LITE-ON TECHNOLOGY CORPORATION. OUTPUT: 19 V Dimension/ Monitor Size (Width x Height x Depth) Weight With Stand Without Stand Weight (Without 4.2 kg Packaging) Stand Angle Forwards/Backwards: -5° to 15° (Monitor) Adjustment Environment Operating Condition Condition Storing Condition The specifications are subject to change without notice. 558 mm (22 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Diagonal length of the screen: 558 mm 0.282 mm x 0.282 mm...

  • Page 25: Preset Mode

    Preset Mode Display Modes Horizontal (Resolution) Frequency (kHz) 720 x 400 31.468 640 x 480 31.469 800 x 600 37.879 1024 x 768 48.363 1280 x 1024 63.981 1680 x 1050 65.290 Power Indicator Mode LED Color On Mode White Power Saving Flashing White Off Mode Vertical Polarity (H/V) Frequency (Hz) Product Specification Remark Recommended Mode...

  • Page 26: Proper Posture

    Proper Posture PROPER POSTURE Proper posture for using the monitor Adjust the angle so that the screen is slightly lower than your eyes. Using the monitor for a prolonged period of time can cause eye fatigue. Take a 10-minute break every hour. The stand is designed to best support the monitor when the optimal conditions are selected. Adjust the angle of the monitor from -5° to 15° to obtain the best view of the screen. You should be looking slightly down at the screen. Place your hands gently on the keyboard, keeping your arms bent at the elbows and extended horizontally in front of you. Adjust the angle from -5° to 15° so that there is no re- flection or glare from the screen.

  • Page 27: Using Pcoip Solution

    USING PCOIP SOLUTION Connect Screen The Connect screen is shown during start-up, except when the portal has been configured for a managed start-up or auto-reconnect. The logo dis- played above the Connect button can be changed by uploading a replacement image via the admin interface. The network icon on the bottom right of the Connect screen shows the status of the net- work connection. You must wait until the network icon is displayed as shown in Figure 2-3. Selecting one of the options will produce a settings window. Figure 2-1. OSD Connect Screen A red "X" over the network icon indicates that either the network is not properly connected or that the connection is still being initialized (i.e. during portal boot up). Figure 2-2 shows the red "X" over the network icon indicating that the network is not ready. Figure 2-2. Network Not Ready (Detail) Using PCoIP Solution Figure 2-3 shows the network icon when ready. Figure 2-3. Network Ready (Detail) Selecting the Connect button initiates a PCoIP or RDP session depending on the session settings. While the PCoIP connection is pending, the OSD local GUI will display a "Connection Pending" message. When the connection is established, the OSD local GUI will disappear and be replaced by the session image. Figure 2-4. OSD Connect Screen (Connecting) OSD Options Menu Selecting the Options menu will produce a list of selections. The OSD Options menu contains: y Configuration...
  • Page 28 Using PCoIP Solution Selecting one of the options will produce a settings window. Figure 2-5. OSD Options Menu Configuration Window In the Configuration window, the administrator can access the window tabs that contain the settings to configure and manage the portal environment. The Configuration window has the following tabs: y Network y Label y Connection Management y Discovery y Session y RDP y Language y OSD y Reset y Display y VMware View Each tab contains OK, Cancel and Apply buttons to allow the administrator to apply or cancel the modified settings. NOTE Some PCoIP devices have their password protection disabled and can be logged into the management web page or access the...
  • Page 29 y Gateway The Gateway field contains the gateway IP ad- dress of the device. If DHCP is disabled, this field is required. If DHCP is enabled, this field cannot be edited. y Primary DNS Server The Primary DNS Server field contains the primary DNS IP address of the device. This field is option- al. If DHCP is enabled, this field cannot be edited. y Secondary DNS Server The Secondary DNS Server field contains the sec- ondary DNS IP address of the device. This field is optional. If the DHCP is enabled, this field cannot be edited. y Domain Name The Domain Name field contains the domain name used, e.g. "domain local". This field is optional. It speci- fies on which domain the host or portal operates. y FQDN The FQDN field represents the Fully Qualified Do- main Name of the host or portal. The default value is PCoIP-host-MAC or PCoIP-portal-MAC, where MAC is the MAC address of the host or portal. If there is a domain name, it will be added to the FQDN in the format of PCoIP-host-MAC.domain.local NOTE In order to utilize the FQDN feature, a DNS server, configured properly with DHCP option 81, must be used. y Ethernet Mode The Ethernet Mode field specifies the portal's Eth- ernet mode.
  • Page 30 Using PCoIP Solution Connection Management Tab The Connection Management tab allows the user to enable or disable the connection man- agement and specify the connection manager's IP address. In a managed connection, an external Connection Management Server can communicate with a device to remotely control and configure the device. The connection manager can also search for an ap- propriate peer to connect to the device. Connection Management significantly reduces the tasks of the administrator in a large and complicated system. NOTE The Connection Management parameters can also be configured using the Webpage Administration Interface. Figure 2-8. Connection Management Configuration y Enable Connection Management If the Enable Connection Management option is enabled, the device can be controlled and config-...
  • Page 31 Discovery Tab The Discovery tab allows the administrator to eas- ily find a portal in the PCoIP system. NOTE The Discovery parameters can also be con- figured using the Webpage Administration Interface. Figure 2-9. Discovery Configuration y Enable Discovery If the Enable Discovery option is selected, a device will use SLP Discovery to dynamically locate the peer device without requiring any information about the location of the device in the network. This means that the configuration and maintenance work in a complicated system can be significantly reduced. As SLP Discovery requires a multicast-enabled router, the recommended search structure is DNS- SRV Discovery. y Enable Host Discovery The Enable Host Discovery option allows the user to find the host not listed in the PCoIP session from the portal. When this option is enabled, up to 10 available hosts can be listed, in the order of their detection from the portal. Use the Enable Host Discovery option when there are a relatively small number of hosts. Using PCoIP Solution Session Tab The Session tab allows the administrator to set the method to connect the device to a peer device. NOTE The Session parameters can also be con- figured using the Webpage Administration...
  • Page 32 Using PCoIP Solution RDP Tab The RDP tab allows the administrator to configure the remote desktop protocol (RDP) specific set- tings. NOTE The RDP Label parameters can also be con- figured using the Webpage Administration Interface. Figure 2-11. RDP Configuration y Resolution The Resolution field is used to set the RDP screen resolution. The available values are as follows. y Native Resolution y 800x600 y 1024x768 y 1280x768 y 1280x1024 y 1440x900 y 1600x1200 y 1680x1050 y 1920x1080 y 1920x1200 y Bit Depth The Bit Depth field is used to set the color bit depth for the RDP session. The available values are as follows.
  • Page 33 OSD Tab The OSD tab allows the administrator to modify the On Screen Display (OSD) parameters. NOTE The OSD parameters can also be configured using the Webpage Administration Interface. Figure 2-13. OSD Configuration y Screen-Saver Timeout The Screen-Saver Timeout field allows the ad- ministrator to set a time limit for the screen saver. The time limit is defined in seconds. The maximum time is 9999 seconds. If it is set to 0 seconds, the screen saver will be turned off. Using PCoIP Solution Reset Tab The Reset tab allows the administrator to reset all configurable parameters stored in Flash. NOTE The Reset function can also be accessed through the Webpage Administration Inter- face. Figure 2-14 Reset y Reset Parameters Pressing the Reset Parameters button will reset all settings and options to the factory default settings. When this button is pressed, an OSD message is displayed. This is to prompt the administrator and prevent accidental reset.
  • Page 34 Using PCoIP Solution Display Tab The Display tab allows the user to configure the EDID function of the monitor. NOTE The Enable display override function can be used when the EDID function of the monitor is not running. Figure 2-15. Display Configuration VMware View Tab The VMware View tab allows the user to select the device to use the VMware View Connection Server. NOTE The VMware View parameters can also be configured using the Webpage Administra- tion Interface. Figure 2-16. VMware View Configuration y Enable VMware View The Enable VMware View option allows the user to configure the portal to use the VMware View Con- nection Server. NOTE To enable the VMware View function, the Enable Connection Management check box in the Enable Connection Management Tab must be deselected. y Identify Connection Server by The Identify Connection Server by selector allows the administrator to decide whether to identify the connection manager by IP address or by FQDN. If VMware View is disabled, this field is not required...
  • Page 35 Event Log Tab The Event Log tab allows the administrator to view and delete the event log messages from the portal. NOTE The event log (regardless of the quantity) can also be reset using the Webpage Admin- istration Interface. Figure 2-17. Event Log Configuration y View Event Log Message The View Event Log Message field displays the log messages accompanied by the timestamp informa- tion. The following two buttons are available: y Refresh The Refresh button refreshes the displayed event log messages. y Clear The Clear button clears all event log messages. Using PCoIP Solution Session Statistics Tab The Session Statistics tab allows the administrator to view the PCoIP specific statistics of the last ac- tive PCoIP session from the portal. NOTE The session statistics (regardless of the quantity) can also be viewed using the Web- page Administration Interface. Figure 2-18. Session Statistics Configuration y PCoIP Packets Statistics y PCoIP Packets Sent The PCoIP Packets Sent field shows the total number of PCoIP packets sent from the portal...
  • Page 36 Using PCoIP Solution y Bytes Statistics y Bytes Sent The Bytes Sent field shows the total number of bytes sent in the last active session. y Bytes Received The Bytes Received field shows the total number of bytes received in the last active session. y Round Trip Latency The Round Trip Latency field shows the total round-trip PCoIP system (e.g. from the portal to the host, then back to the portal) and the network latency in milliseconds (+/- 1 ms). PCoIP Processor Tab The PCoIP Processor tab allows the administrator to view the portal PCoIP processor's uptime since its last booting. NOTE The PCoIP Processor Uptime can also be viewed using the Webpage Administration Interface. Figure 2-19. PCoIP Processor Configuration Ping Tab The Ping tab allows the administrator to perform a ping test to the device and check if it can reach the overall IP network. This is useful to check whether the device can reach the host. NOTE The Ping tab has no corresponding menu in to the Webpage Administration Interface of...
  • Page 37 Information Window In the Information window, the administrator can access the Version tab that contains the device related information. NOTE The version information can also be viewed using the Webpage Administration Interface. Figure 2-21. Version Configuration y VPD Information The Vital Product Data (VPD) is information that uniquely identifies each portal or host. y MAC Address The portal MAC address y Unique Identifier The portal ID y Serial Number The portal serial number y Firmware Part Number The part number of the PCoIP firmware y Hardware Version The portal hardware version y Firmware Information The Firmware Information shows the details of the current PCoIP firmware. y Firmware Version The current PCoIP firmware version y Firmware Build ID The current PCoIP firmware revision code y Firmware Build Date The current PCoIP firmware build date Using PCoIP Solution...
  • Page 38 Using PCoIP Solution Mouse Tab The Mouse tab allows the user to modify the OSD and RDP session's mouse cursor speed setting. NOTE The OSD mouse cursor speed setting does not affect the mouse cursor settings when a PColP session is active unless the Local Keyboard Host Driver function is being used (see PColP Host Software User Guide for more information). The Mouse tab has no corresponding menu in the Webpage Administration Interface of Section 1. Figure 2-22. Mouse y Mouse Speed The Mouse Speed field allows the user to set the portal's mouse cursor speed. NOTE The Mouse Speed can also be configured via the PCoIP Host Software. For more informa- tion on using the PCoIP Host Software, refer to the PCoIP Host Software User Guide. Keyboard Tab The Keyboard tab allows the user to modify the OSD and RDP session's keyboard repeat setting. NOTE The OSD keyboard setting does not affect the keyboard settings when a PColP session is active unless the Local Keyboard Host Driver function is being used (see PColP Host Software User Guide for more informa- tion). The Keyboard tab has no corresponding menu in the Webpage Administration Inter- face of Section 1.
  • Page 39 Image The Image tab allows a user to change the image settings on the PCoIP system. NOTE The Image parameters can also be con- figured using the Webpage Administration Interface. Figure 2-24. Image y Minimum Image Quality The Minimum Image Quality slider allows the ad- ministrator to make compromises between image quality and frame rate when network bandwidth is limited. Sometimes, lower-quality images at a higher frame rate may be required, while at other times, higher-quality images at a lower frame rate may be preferred. In environments where the network bandwidth is limited, moving the slider towards Reduced en- sures higher frame rates; moving the slider towards Perception-Free ensures higher image quality. When network bandwidth is not limited, the PCoIP system will maintain percep- tion-free quality regardless of the Minimum Image Quality setting. Using PCoIP Solution...
  • Page 40 Make sure to read the Safety Precautions before using the product. Keep the Owner's Manual(CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service. MODEL SERIAL...
