Installing And Removing The Sim Card - Samsung Rugby II User Manual

Lift the battery up (1) and away (2) from the phone, as
3.
shown.

Installing and Removing the SIM Card

Important!: The plug-in SIM card and its contacts can be easily damaged by
scratches or bending. Use caution when inserting or removing the
card, and keep all SIM cards out of reach of children.
Remove the back cover and battery.
1.
2
Make sure to orient the SIM card with the gold contacts
2.
facing down and the corner notch positioned as shown
below, then slide the SIM card completely into the socket.
To remove the SIM, gently slide it out of the socket.
3.
Note: The angled corner of the SIM should be inserted as shown in the
previous diagram. Improperly inserting the SIM can cause the phone to
not recognize the SIM.
