Intellectual Property All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers relating to the SAMSUNG Phone, including but not limited to, accessories, parts, or software relating there to (the “Phone System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions.
GH68-18518A Printed in China Licensed by Qualcomm Incorporated under one or more of the following patents: U.S.Patent No. 4, 901, 307; 5, 056, 109; 5, 099, 204; 5, 101, 501; 5, 103, 459; 5, 107, 225; 5, 109, 390. Disclaimer of Warranties; Exclusion of Liability EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR ITS FITNESS FOR ANY...
Section 1: Getting Started This section describes the first steps to operating your phone. SIM Card Information When you subscribe for 3G cellular network services, you receive a plug-in SIM (Subscriber Identity Module) card loaded with your subscription details, such as your PIN, and available optional services.
Installing and Removing the SIM Card Important!: The plug-in SIM card and its contacts can be easily damaged by scratches or bending. Use caution when inserting or removing the card, and keep all SIM cards out of reach of children. Remove the back cover and battery.
To remove the card, push it backward until it clears the brackets in the slot, then lift and remove it (refer to illustration). Replacing the Battery To reinstall the battery, with the battery cover open, align the battery tabs with the slots at the bottom of the phone. Press the battery down until it clicks into place.
Charging the Battery Your phone is powered by a rechargeable Li-ion battery. Use the travel adapter to charge the battery, and use only Samsung approved batteries and chargers. Note: You must fully charge the battery before using your phone for the first time.
Important!: The battery charging function may stop if you are on a call or viewing a streaming-video while charging your battery. Note: During charging, you must unplug the adapter before removing the battery from the phone to avoid damage. Low Battery Indicator When the battery is weak and only a few minutes of talk time remain, a warning tone sounds, the “Battery Low”...
Setting Up Your Voice Mail Note: If your service provider did not pre-configure your voicemail server number, store the voicemail server number before accessing the server. Your service provider can give you the number. information, refer to “Changing the Voice Mail Name and Number”...
Section 2: U nderstanding Your Phone This section outlines some key features of your phone. It also displays the screen and the icons that are displayed when the phone is in use. Features of Your Phone Your phone is lightweight, easy-to-use and offers many significant features.
Open View of Your Phone The following illustrations show the main elements of your phone: Keys The following list correlates to the open and front view illustrations. Main Display: This screen displays useful information needed to operate your phone. Navigation keys: This key allows you to scroll through phone menu options and provides a shortcut to phone functions from standby mode.
Special Function keys: Asterisk/Shift key-enters the [ character for calling features. In text mode, press to change the character input type. Pound/Space key-enters the pound [ # ] character for calling features. In text entry mode, press to enter a space between characters. Press and hold to activate/deactivate the Silent profile.
Closed View of Your Phone Keys The following list correlates to the side view illustrations. PTT key: Press to display the PTT Contacts. Press and hold to display the Recent calls list. Volume keys/Menu Navigation: Allows you to adjust the ringer volume in standby mode or adjust the voice volume during a call.
Main Display Layout The display has 3 areas: Icons Text and graphic area Options Menu Soft key indicator Icons Shows the received signal strength. The greater the number of bars, the stronger the signal. Displays the level of your battery. The more bars you see, the more power you have remaining.
Displays when the phone is set to Mute. Displays when your incoming phone calls are being forwarded to another number. Displays when you receive new voice mail message. Displays when you receive an email message. Displays when a new text message is received. Displays when a new multimedia message is received.
Displays when the phone’s profile is set to Driving. In this case, the speaker is active and launches the currently selected ringtone or melody when the associated notification is activated. This icon is accompanied on screen by the Audio icon. Displays when the phone’s profile is set to Outdoor.
When you access a list of options, your phone highlights the currently active option. If, however, there are only two options, such as On/Off or Enable/Disable, your phone highlights the option that is not currently active, so that you can select it directly.
Left Soft Key Some functions of the left soft key are as follows. In the Idle screen, press the Options (left) soft key • Menu screen. See ‘Selecting Functions and Options” on page 17. When in a menu mode, the left soft key function is Select.
Navigation Key Use the directional keys on the Navigation key to browse menus, sub menus, and lists. Press the Up or Down Navigation keys when jumping to highlighted links on the web. Each key also acts as a shortcut to launch applications from the Idle screen.
Section 3: Call Functions This section describes how to make or answer a call. It also includes the features and functionality associated with making or answering a call. Making a Call When the Idle screen displays, enter the area code and phone number, and press the key.
Dialing a Number From the Recent Calls Menu All incoming, outgoing and missed calls are listed in the Recent Calls Menu. If the caller is listed in your Address Book, the name associated displays. To access the Recent Calls menu: In Idle mode, press the key.
Video Share The Video Share features allows you to place a call and share live or recorded video while on the call. You can initiate or receive video by using the following steps. Initiating and Receiving a Video Share Session To initiate and receive a Video Share session: Dial the number and press the Once the call is answered, if you're both capable of Video...
Brightness:Select this option to adjust the brightness for the video. Landscape: Select this option to rotate the picture from Portrait to Landscape mode. Press any key to revert to Portrait. Mute: Select this icon to turn the audio off/on. Spkr Off/On : press this key to the speaker off/on. Tip: To stop the video share call press the Options soft key and press the Select the “Video Share End”...
Recent Calls All incoming, outgoing and missed calls are listed in the Recent Calls Menu. If a number is associated with a name in your Address Book, the associated name displays. To access the Recent Calls menu: In Idle mode, press the key.
Viewing the Details of a Missed Calls To view the details of a selected missed call, use the following steps: Press the View soft key. The most recently missed call displays. Scroll through the list of missed calls. With the missed call selected, press the Options soft key. Highlight Details and press the Saving a Missed Call to your Address Book To save the missed call entry to your address book, use the...
Deleting a Missed Call To delete a missed call entry: Immediately after missing a call, press the View soft key. Press the Options soft key. Use the Navigation keys to select Delete and press the Select soft key or the key.
Options During a Call Your phone provides a number of control functions that you can use during a call. Adjusting the Call Volume During a call, if you want to adjust the ear piece volume, use the Volume keys on the left side of the phone. up Volume Press the key to increase the volume level and the...
• The current call (caller #2) is placed on hold and the previous call on hold (caller #1) is reactivated so you can continue conversing with that person. Press the key to end the currently active call. To end a specific call: Press the Options soft key.
Using the Speakerphone During an Active Call While in an active call, it is possible to enable the speakerphone feature. Dial the number and press the Press the key to activate the speakerphone when the call is answered. Use the volume keys (located on the left side of your phone) to adjust the volume.
Searching for a Number in Address Book You can search for a number from the Address Book during a call. Press the Options soft key. Use the Navigation keys to highlight Address Book and press the Select soft key or key.
3-Way Calling (Multi-Party Calling) The 3-Way or Multi-Party feature allows you to answer a series of incoming calls and place them on hold. If this service is supported by the network, all calls can be joined together. You are notified of an incoming call by a call waiting tone. Note: The Join option combines all of the established calls (both active and on hold).
Section 4: Menu Navigation This section explains the menu navigation for your phone. It also includes an outline of all the available menus associated with your phone. Some menu options are controlled by the SIM provided by your service provider. Menu Navigation Menus and sub-menus can be accessed by scrolling through them using the Navigation keys or by using the shortcut keys.
In Idle mode, press the Menu. Press the key for Settings. Press the key for Phone Press the key for Language. Press the key to display the list of available languages. My Menu The My Menu option is another way to access applications from the idle mode without navigating through the main menu icons and sub menus.
Section 5: Entering Text This section outlines how to select the desired text input mode when entering characters into your phone. This section also describes how to use the T9 predictive text entry system to reduce the amount of key strokes associated with entering text. Using the Text Input Methods The Input Method option switches the key entry functions from ABC (Alphabetic), T9 Alphabetic (predictive text mode), Numeric...
Changing the Text Input Mode When you are in a field that holds characters (such as in a text message), the text input mode indicator displays. Use the following steps to change the text input mode: To change the text input mode, press the - Or - Press the Options soft key and select Input Method.
When the word displays correctly, go to step 5. If the word doesn’t display correctly, press the display alternative word choices. Example: Both “Of” and “Me” use the displays the most commonly used choice first. Insert a space by pressing the the next word.
Section 6: Understanding Your Address Book This section allows you to manage your daily contacts by storing their name and number in your Address Book. Address Book entries can be sorted by name, entry, or group. Note: When storing an Address Book entry into your SIM card, note that only the Name, Address, Group, and slot location are initially offered as fields.
Address Book Entry Options While in the Address Book with any of the default entries highlighted, press the Options soft key to use access the following options: View provides you with details about that contact entry. Press the • Back soft key to return to the Address Book listing. Video Share: allows you to share either a live video recording or •...
Note: The Save New Contacts to setting must be set to Phone to automatically store numbers in the phone’s memory. Select the type of entry, either a New contact or Update to an existing contact. On the Select Type screen, choose the type of phone number being entered: •...
does not support additional fields on the SIM card, this additional information may not be available. In Idle mode, enter the phone number. Press the Options soft key and select the Save to Address Book option. Select the number entry type New or Update. Note: The Save New Contacts to setting must be set to SIM Memory to automatically store numbers on the SIM card.
Press the Up or Down Navigation key to find other numbers on the list. Press the Call soft key, the key, or the when you select the number to call. Group Settings Editing a Caller Group ➔ In Idle mode, press Menu Address Book press the Select soft key or the Scroll through the list of groups, highlight the target group...
Scroll to the contact to assign to this speed dial number and press the Select soft key or the Note: Memory location 1 is reserved for your Voice mail server number. Changing a Contact or Number Assigned to a Key ➔...
Press the Right Navigation key, select one of the following options and press the Select soft key or the • Number: allows you to enter a number to add to the Reject List. • Address Book: allows you to select a contact from the Address Book to the Reject List.
Address Book Settings Using the Address Book you can create a business card, determine where to save new contacts, view all the contacts, find your phone number, use the FDN list to restrict phone access, and view the space used and available. My Business Card My Business Card is an electronic business card which contains your name, phone number, and other profile information and is...
You can assign a name to each of your own phone numbers registered on your SIM card. You can also edit the names and numbers. Any changes made here do not in any way affect the actual subscriber numbers on your SIM card. ➔...
Used Space is listed for the following units: • Phone: tells you how many Address Book entries (out of a possible 1000) are in use. • SIM Card: tells you how many entries are in use on your SIM card (out of a possible 250, depending on your SIM card).
Copying Contacts from the SIM Card to the Phone ➔ In Idle mode, press Menu Address Book ➔ Management Copy Contacts from SIM, and press the Select soft key or the key. Note: Only the contacts currently stored on the SIM card display. Highlight the entry that you want to copy from the SIM card to the phone and press the key to place a check mark...
Section 7: Push to Talk This section describes the Push to Talk (PTT) feature which allows you to contact your family, friends, and co-workers (also using PTT) instantly. Initializing Push to Talk Service From the Idle screen, press the Push to Talk (PTT) key. - Or - ➔...
Unavailable: This becomes your availability state if you power-off your phone, turn PTT off, or if the system detects you have moved out of coverage. Do Not Disturb: This becomes your availability state if you change My Availability to Do Not Disturb. In this state you may place PTT calls but cannot receive a PTT call.
Invitation in Progress: This icon lets the User know the invitation to this person for addition to the PTT Contact List is in progress. A call can not be placed to the person until the invite completes and the icon changes to available. Groups Group Available: This icon only displays next to a group and lets the User know that at least one person in the...
The handset sends an invitation to the new contact and the Invitation In Progress icon displays. An invite response pop-up displays informing you that an invitation was sent to the new contact. Viewing Push To Talk Contacts ➔ In Idle mode, press Menu Push to Talk (PTT) Contacts.
PTT Group Options Press the PTT key. The PTT Contacts list displays on the screen. -Or- ➔ Idle mode, press Menu Push to Talk (PTT) Group and press the Select soft key or the Highlight a PTT Group, press the Options soft key, and select from the following options: •...
Note: When the call completes, “Quick Group Call” displays in your PTT Call Log. Although this call is logged with your other PTT calls a call can not be placed to this entry. Press the key to return to Idle mode. Dynamic Call The Dynamic Call option allows you to make a call with only select members of your group.
Enter a name for the group in the Enter Name field and press the OK soft key or the key. The following options display: • Select in Contacts: allows you to choose from current contacts in your PTT Contacts phonebook. Tip: Press the key to place a check mark displays beside each contact to be added to the new group.
Deleting a Member from a Group Note: When deleting a member from a group, the deleted member receives a PTT Message that they were deleted. Press the PTT key. The PTT Contacts list displays on the screen. Highlight the desired group and press the Highlight the member you wish to delete and press the key.
Alternatively, select the individual or group you want to call. Make sure an available icon is displayed beside the individual or group. Press and hold the PTT key to initiate the call and begin speaking after the tone. Release the PTT key when you are done speaking.
PTT Settings ➔ In Idle mode, press Menu PTT and press the Select soft key or the key. Select PTT Settings and press the Select soft key or the key. Choose from the following options: • My Availability : this option allows you to change your Availability status.
Pending Invitations This menu displays the unanswered contact list invitation. You can accept or reject the pending invitation later. If you accept or reject a pending invitation, the invitation is removed from the Pending invitation list. If you defer the invitation, the invitation saves in the Pending invitation folder.
Section 8: Messaging This section describes how to send or receive different types of messages. It also includes the features and functionality associated with messaging. Types of Messages Your phone provides the following message types: Text Messages • • Multimedia Messages IM Messages •...
– Record Audio: allows you to temporarily exit the message, record an audio clip using the phone’s microphone, and then add the new audio clip to your message. – Record Video: allows you to temporarily exit the message, record a video clip using the phone’s camera, and then add the new video clip to your message.
• Back: prompts you to save your message to the Drafts folder, closes your message, and returns you to the previous menu or to Idle mode. Press the Send To soft key. The Recipients screen displays. Note: A multimedia message should only be sent to a phone that can support the receipt and display of this message type.
➔ In Idle mode, press Menu Messaging Message and press the Select soft key or the In the text field, begin creating your text message. Press the Options soft key, select Add Items, then press the Right Navigation key. Select an Image, Sound or Video and press the Note: A multimedia message should only be sent to a phone which can support the receipt and display of this message type.
The following icons indicate the message type. indicates a new Voicemail message. • indicates a new Text or Multimedia message was • received. Press the View soft key (in the case of Voicemail, the soft key displays Dial, and dials your Voicemail) or the key.
Press the Options soft key, highlight Properties, and press the Select soft key or the key to view brief information about the message, such as the sender’s number, the message size, and the subject. If you want to view the message later in the Inbox, press the Back soft key.
Note: When storing an Address Book entry into the SIM card, only the Name, Number, Group, and Slot location display initially. To save additional information for a particular contact, such as other phone numbers, or e-mail, it is important to add new fields to that Contact information. If you move the SIM card to another phone that does not support additional fields on the SIM card, the additional information is not available.
Signing into Your IM Account Although each account type differs, the initial sign in procedure is common to all supported types. Before beginning the sign in procedure, you must complete the previous procedures for selecting your default IM Community. ➔ In Idle mode, press Menu Messaging the Select soft key or the...
Drafts This message box stores unsent messages that you want to edit or send later. ➔ In Idle mode, press Menu Messaging press the Select soft key or the My Folder My Folder allows you to organize and save messages. You can create custom folders and save your messages to these folders for access at a later time.
• Outbox: allows you select the your Outbox folder and mark its files for deletion. • Drafts: allows you select the your Drafts folder and mark its files for deletion. • My Folder: allows you select the your My Folder and mark its files for deletion.
Request Delivery Report : when this option is enabled, the network – informs you whether or not your message was delivered. Request Read Report : when this option is enabled, your phone sends a – request for a reply along with your message to the recipient. Keep a Copy : you specify whether you want to keep a copy of the sent –...
Voice Mail The following options are available: Voicemail: you can specify the default phone number used for access • of phone’s remote voicemail. Important!: Changing the Voicemail number can affect your ability to access your voicemail. Check with your provider’s Customer Service before changing.
• Text Message - displays memory used for: – Inbox – Sent – Outbox – Drafts – My folder • Push Message - displays memory used for: – Inbox – My Folder • Configuration Message – Inbox – My Folder...
Section 9: MEdia Net and WAP Your phone is equipped with a WAP (Wireless Application Protocol) browser which allows you to access the Internet. This section explains how to access the WAP services of your service provider and navigate the WAP browser. Accessing the MEdia Net Homepage In Idle mode, press the key to launch the WAP...
– Edit Categories: allows you to edit those category entries which appear on the MEdia Net homepage. Although the first four entries (WHAT’S HOT, Tones, Games, Pics, and Cellular Video) cannot be removed, the remaining entries can be toggled on or off. Highlight a category entry and press the key to toggle it on (appear on the page) or off (remove it from the homepage).
Entering Text in the WAP Browser When you are prompted to enter text, the currently active text input mode is indicated on the screen. The following modes are available: • Upper-Case Alphabet Mode (A): allows you to enter upper-case characters. Lower-Case Alphabet Mode (a): allows you to enter lower-case •...
Enter URL: allows you to manually enter the URL address of a WAP • site. After entering an address, press the Go to soft key to go there directly. • Copy URL to Message: send the URL of the current page to another party as a message.
Storing a URL Address as a Favorite ➔ In Idle mode, press Menu MEdia Net and press the Select soft key or the key. Select Enter URL and press the Select soft key or the key. Enter the URL address and press the Down Navigation key. Tip: Use can use the key to cycle through that available symbols and choose the...
Select Delete and press the Right Navigation key. Highlight Selected or All and press the Select soft key or key. Press the Yes soft key or the key to confirm the deletion. Press the key to return to Idle mode. Saved Pages The Saved Pages option allows you to view the pages from URLs that you saved.
Emptying the Cookies A cookie is a small file which is placed on your phone by a web site during navigation. In addition to containing some site-specific information, it can also contain some personal information (such as a username and password) which can pose a security risk if not properly managed.
Use the Up or Down Navigation key to highlight one of these options: • MEdia Net • AT&T MMS • AT&T IMS Press the Options soft key. Important!: The WAPs are pre-configured and cannot be altered on this screen. The MMS connection option can be edited, renamed, or deleted.
– Server 1/Server 2: enter the Domain Name Server (DNS) addresses. – Traffic Class: select the traffic class. Note: The WAP settings may vary depending on the service provider. Downloading Multimedia Files You can buy a variety of multimedia files, such as ringtones, graphics, applications, Multimedia contents, and so on from the WAP browser and download them to your phone’s memory.
Section 10: MEdia Mall The MEdia Mall topics covered in this section are shopping for Tones, Games, Graphics, Multimedia, Applications, and Videos as well as accessing the MEdia Home site. Shop Tones The Shop Tones menu option allows you to shop for audio tones using the built-in browser.
Shop Graphics The Shop Graphics menu option allows you to shop for graphic images using the built-in browser. You can download new images to your Graphics folder. To access this menu option, use the following steps: ➔ In Idle mode, press Menu MEdia Mall and press the Select soft key or the key.
Shop Applications The Shop Applications menu option allows you to shop for application files using the built-in browser. You can download the new applications to your Games and Apps folder. To access this menu option, use the following steps: ➔ In Idle mode, press Menu MEdia Mall and press the Select soft key or the...
Accessing the MEdia Net Home The MEdia Net menu option allows you to quickly access your MEdia Net homepage using the built-in browser. This page gives you quick access to information such as local weather, sports scores, horoscope information and quick links to the previously mentioned shopping sites.
Section 11: My Stuff This section includes information on both on-board applications (such as camera, camcorder, calendar, and alarms) as well as applications that are purchased via the MEdia Mall. In the My Stuff menu option, you access AT&T Music and Cellular video, Audio, Games and Apps, Graphics, Videos, Tools, and Other Files submenus.
Games and Apps The Games and Apps menu option allows you to shop games using the WAP browser. You can download new, and save to the My Games and Apps folder. To access the Games and Apps menu option, use the following steps: ➔...
Selecting and Using the Graphics Folder If you enter the Graphics folder through menu options, and press the Options soft key before selecting an existing graphic, the following options list: Download: allows you to download a graphic from MEdia Mall. •...
in the Graphics folder found within the My Stuff (Phone) location. These images can be used as wallpapers or included into multimedia messages. Select an image entry and press the When you are ready to purchase the image, press the Buy Now button to complete the transaction.
Before taking the photo, use the Menu soft key and the navigation keys to access camera option icons. Press the Gallery soft key to return to the picture viewer. You can use the keypad to quickly change the camera options using the camera shortcut keys. Press the key to take the photo.
Photo size: allows you to set the size of the resulting photo. 1280 Options are: 1280x960 (results in a 1.3M size) • 640x480 • 320x240 • White Balance: allows you to set the white balance for the camera. Choose Auto, Daylight, Incandescent, Fluorescent, or Cloudy.
Camera Options after Taking a Photo After you have taken a photo, you can use various options by pressing the Options soft key. Highlight an option and press the key. The following options are available: • Take photo: allows you to go back to the camera and take another photo.
Editing a Photo Once you have selected and loaded a photo, the following options are available for editing and management of the photo. Zoom: allows you to zoom in on the image or zoom out. • Send: allows you to attach the graphic to a message, send it to a •...
Using the Camcorder Shooting Video Tip: When shooting video in direct sunlight or in bright conditions, it is recommended that you provide your subject with sufficient light by having the light source behind you. In Idle mode, press the Options soft key to open the My Menu screen.
White Balance: allows you to set the white balance for the camcorder. Choose Auto, Daylight, Incandescent, Fluorescent, or Cloudy. Effects: allows you to choose a custom color tone for your video clip. Choose from the following: No Effects: automatically adjust the video for the best •...
Camcorder Options after a Video is Taken After you have shot a video, press the Options soft key to select various options. Highlight an option and press the following options are available: : allows you to record another video clip. •...
Once the video completes playing, or you select the Stop option, the following options are available: • Play: allows you to replay the video clip. Send via: allows you to send the video clip via a multimedia message • or a Bluetooth device. Properties: allows you to view the properties for this video file.
• Set as: allows you to set the audio file as a call ringtone, a ringtone for a specific caller, or an alarm tone. • Delete: allows you to delete the memo. • More: – Rename: allows you to change the memo’s name. –...
• Alarm 4: fourth alarm setting. • Auto Power-up: the alarm rings even when the phone is turned off. Select an alarm type and press Options key. The options available are: Select and Create. Select the alarm, and press the Set the following options: •...
Highlight On and press the Select soft key or the to activate the Autopower feature. Note: If the menu option is set to Off, and the phone is switched off at the specified time, the alarm does not ring. Press the key to return to Idle mode.
• Missed Alarm Event: this option displays any missed events. • Used Space: this option displays a list of the different Calendar event categories along with the memory allocation for each. Appointment ➔ In Idle mode, press Menu My Stuff Highlight Tools and press the Select soft key or the key.
Anniversary ➔ In Idle mode, press Menu My Stuff. Highlight Tools and press the Select soft key or the key. Select Calendar and press the Select soft key or the key. Press the Options soft key. Highlight Create, select Anniversary, and press the Select soft key or the key to use the following options: •...
The calendar displays with today’s date highlighted. If there is an alarm or alarms set, the the icon line above the Calendar. Select the date of the event (s) you want to view and press key or use the Navigation keys to move to the date with an assigned event.
• Missed Alarm Event: this option displays any missed events. • Used Space: this option displays a list of the different Calendar event categories along with the memory allocation for each. Press the key to return to Idle mode. Recent Calls The phone stores the numbers of the calls you’ve dialed, received, or missed in the Recent Calls menu.
Notes This option allows you to create notes to add to your events. ➔ In Idle mode, press Menu My Stuff. Highlight Tools and press the Select soft key or the key. Highlight Notes and press the Select soft key or the key.
Enter the values into the appropriate fields by using the numeric keys: • Bill • Tip(%) • # paying Note: To include a decimal point by pressing the The remaining fields indicate: • Tip($): the amount of the tip based on the figures entered. •...
Highlight World Time and press the Select soft key or the key. Use the Left or Right Navigation keys to browse cities and times. Press the key or the Set DST soft key to indicate that the selected time zone has Daylight Savings Time (DST). The displayed time shifts to reflect the time zone and usage of DST.
Highlight Other Files and press the Select soft key or the key. Used Space This option lets you view the memory usage on your phone and on an optional Memory Card, if installed. This option also lets you view the files stored in each folder and lets you delete unwanted files.
Section 12: Entertainment The Entertainment menu offers both AT&T Music and CV (Cellular Video). AT&T Music is a music service which provides you access to Music Videos, Shop Music, Community, Music applications, XM Radio, The Buzz and a unique Music ID application. CV (Cellular Video) is a media service which allows you to stream video content directly to your phone.
Using the Music Player The Music Player is an application that can play music files. The music player supports files with extensions AAC, AAC+, eAAC+, MP3, WMA, 3GP, MPEG, MP4, and M4A. Launching the Music Player allows you to navigate within your Music folders and select playback material.
• Equalizer: allows you to select from one of the preset equalizer settings. Select from Normal, Rock, Pop, Dance, Classic, or Jazz. • Download Status: allows you to view the status of the downloaded music files. • Properties: displays properties related to the selected song such as: Title, Size, Format, Duration, Artist, Album, Genre, Forwarding, Created Date &...
Playing Music while Using the Phone The Music Player allows you to play music in the background while performing other tasks on your phone. The music pauses when an incoming call is accepted, and the music resumes when the call ends. Music continues to play when you receive a Text Message, Multimedia Message, or an Instant Message.
Using Playlists Playlists are used to assign songs to a list of preferred media which can then be grouped into a list for later playback. These Playlists can be created via either the handset’s Music Player options menu or from within a 3rd party music application (such as Windows Media Player) and then downloaded to the handset.
Removing songs from a Playlist ➔ In Idle mode, press Menu My Stuff AT&T Music and press the Select soft key or the Highlight Music Player and press the Select soft key or key. Highlight Playlists and press the Right Navigation key. Highlight the previously created playlist and press the Right Navigation key.
Under Library, select Songs. The downloaded songs list displays. Highlight a song from the list, right click and select Add to ➔ A837-Phone. Note: If there are no items present in the playlist, click the Edit Playlist button and begin adding the music files from among the various media categories.
Press the key to return to the AT&T Music screen. Transferring Music from the Digital Music Stores In order to download music from the computer to your handset, a microSD™ card and USB data cable are required. These items are sold separately; go to www.wireless.att.com/cell-phone- service/accessories/.
Transferring Music using a Media Application A USB cable, microSD™ card, and a current version of a media application (such as Windows Media Player) are required for this procedure. Open Windows Media Player on your computer (version 10.0 or higher). Use the USB adapter cable to connect the handset to the target PC.
Using ID song! ➔ In Idle mode, press Menu My Stuff AT&T Music and press the Select soft key or the Highlight MusicID and press the Select soft key or the key. Highlight ID song! and press the Place the handset’s microphone up to the source of the song, which can be from either a radio, stereo, or headset.
• ID Picks and More!: describes the process following the successful identification of a song. You can choose to purchase the song and wallpaper (if available) or send the musicID as a link to another phone number. • Subscription: provides details about the general usability and monthly term information.
Highlight Music Videos and press the Select soft key or key. You are then taken to your CV Music homepage. Highlight the desired media clip or select from one of the available categories and press the Music Video Options The options for the Music Video page are identical to those options provided for within the CV homepage.
Enter an area code, phone number (without dashes), and Zip code into the appropriate fields on the Customize screen. Use the Up or Down Navigation key to switch between fields. Press the Done soft key to accept and save your information.
Music Applications The Music Applications option accesses the internet to provide Music tools for your handset. Services provided on this site may include, Music ID, MobiRadio, Billboard Mobile Channel, MobiTV, Live TV, and MobiTV en Español. ➔ In Idle mode, press Menu My Stuff AT&T Music and press the Select soft key or the Highlight AT&T Music and press the Select soft key or the...
Section 13: Cellular Video CV (Cellular Video) is a media service which allows you to stream video content directly to your phone. Your phone is equipped with a WAP (Wireless Application Protocol) browser which allows you to access the Internet and begin streaming.
• Page Size ange the page size of the displayed web page using : ch the Right and Left Navigation keys to step the size up or down (there are 20 increments) • Go to Homepage: takes you back at any time to the homepage of the Wireless Web service provider.
Jump to Track Time This feature pauses the current media content and displays a “Jump to track time” pop-up which allows you to enter an Hour, Minute, and Second value which corresponds to the media’s timeline. For example, if the content is three minutes long, entering a value of: 00:01:30, causes the Media Player to replay the content from the half-way point.
After the stream is buffered into memory, you can choose to either Pause or play the content. Pressing the toggles the Play and Pause functionality. Customizing Cellular Video Updating the Favorites List The list of media providers which appear in the Favorites section of the CV homepage can be edited and changed by the user.
Press the Options soft key. Highlight Add to Favorites and press the Select soft key or the My Purchases The CV homepage can be used to shop for streaming multimedia content. The My Purchases section can help keep track of your purchase history and view any new resale products.
From the Parental Control Setup screen, use your keypad to enter information into the following fields: PIN, Re-enter PIN, contact email address. Use you Navigation keys to highlight the Save button and press the key. Allow a few minutes for MEdia Net to receive and accept the information, then use this information to activate the parental filters.
Section 14: AT&T GPS AT&T GPS is an audible and visual, JAVA based driving aid that uses GPS navigation. The program is a separately licensed product that requires you to download the feature to your handset, and accept the license agreement before using.
• Tools & Extras: allows you to search, refresh and view Favorites, displays Preferences, and provides detailed information about the phone. – My Favorites: allows you to search your saved favorites, create a new favorite, refresh favorites, or view the received address. –...
Section 15: Changing Your Settings This section includes quick tips on how to use some of use some of your phone’s features, as well as how to change and customize the display settings, call handling, security settings, and other settings associated with your phone. Quick Tips Quick Tips is a new service for AT&T customers, where you can get answers to Frequently Asked Questions (FAQ) and tips for...
History: allows you to review the history of the last web pages • you viewed. • Advanced: allows you to change the following settings for the browser. – Clear Cache: deletes the information stored in the cache. The cache stores the most recently accessed pages. –...
Call Tab Call Alert Type : allows you to select the way in which the selected – ringtone is played when a call comes in on the phone. • Melody: the phone sounds the selected melody. • Increasing Melody: the phone sounds the selected melody, which increases in volume until the call is answered, rejected, or goes to voice mail.
• Vibration: the phone vibrates. • Vibration & Melody: the phone vibrates and also plays the melody. • Mute: the phone neither vibrates nor plays a ringtone. The only indication of a message is an alert on the display. – Phone Sound Volume: allows you to set the volume of the phone from power on.
Note: To save any changes made to a profile, highlight the desired Profile, press the key. The phone displays a verification of profile change. Press the Save soft key to verify change. Display Settings In this menu, you can change various settings for the display or backlight.
Front Display Wallpaper: allows you to select from Clock, Picture, or Screen Slogan. • – To set the Clock style, select the Clock option, then press the Edit soft key. Use the Left or Right Navigation keys to access the options of Digital Clock, Analog Clock 1, and Analog Clock 2.
• Time Zone Updating: allows you to select whether the time zone information is updated: Automatic (which greys-out some of the other options), Prompt First, or Manual Only. • Time Zone: allows you to assign your current time zone based on Greenwich Mean Time.
• Français: the selected phone language is changed to French. • Español: the selected phone language is changed to Spanish. Select Press the soft key or the selection. Save Press the soft key to save your new selection. Input T9 The Input T9 option sets the language used when entering text into the phone.
The following options are available. Lock Phone When the Lock Phone feature is enabled, the phone is locked and you must enter the 4- to 8-digit phone password each time the phone is powered on. To change the phone password, see Setting Phone Password on page 141.
Set FDN Mode FDN (Fixed Dial Number) mode, if supported by your SIM card, allows you to restrict the outgoing calls to a limited set of phone numbers. The following options are available: – Off: you can call any number. –...
Airplane Mode The Airplane mode allows you to turn On or Off the Airplane mode. This mode allows you to use many of your phone’s features, such as Games, Music, Notepad, Voice Memos, etc., but you cannot send or receive any calls or access online information.
Press the Select soft key to confirm your selection. Options include: • Send Key: allows you to answer an incoming call by pressing either the Accept soft key or the key. • Open Flip: allows you to answer an incoming call by just opening the phone.
• Unreachable: allows you to forward Voice Calls to a designated number instead of your voicemail number when you are not in an area covered by your service provider or when your phone is switched off. • Cancel All: allows you to cancel all Call Forwarding features. Press the Select soft key to activate this feature.
Auto Redial This feature allows to you automatically redial the last number if the call was either cut off or you were unable to connect. Press the key to make your selection. Options include: • On: causes the phone to automatically redial the last number if the call was disconnected or the call was cut off.
Highlight On or Off and press the Select soft key or the key. Discoverable The Discoverable option allows your phone to wirelessly transmit its phone name and status, when activated. This can be useful if you are attempting to connect additional Bluetooth devices. Allowing your phone to promote its visibility can pose a security risk and incite unauthorized connection.
My Bluetooth Info The My Bluetooth Info feature allows your phone to identify itself using the name, the Device Address and Hardware and Software Version, entered into the fields when your phone’s Bluetooth visibility is turned On. The information is altered by selecting the pre-existing text and replacing it with a new string.
➔ In Idle mode, press Menu Settings ➔ Select USB Mode and press the Select soft key or the key. Use the Up or Down Navigation key to highlight one of these options: • Ask on Connection: requires the phone to present a “Select USB Mode”...
Select the parameter you want to edit: • Set Name: enter a profile name. • Access Name: edit the access point name. • Auth Type: select the type of authentication used for this WAP connection: None, Normal, or Secure. • User ID: enter the User ID required to connect to the network. •...
Applications Settings The Applications Settings feature allows you to configure the functional parameters for most of the onboard applications. These applications are described in more detail within other sections of this manual. ➔ In Idle mode, press Menu Settings Settings and press the Select soft key or the Select the type of application to change and press the Select soft key or the key.
Scroll to and set options one of the following options: • All • Sound Profile Settings • Display Settings • Phone Settings • Alarms Press the Check soft key to make your selection and press the OK soft key. Enter your phone password, if prompted. At the “Reset Settings?”...
Enter your password (if applicable) and at the Clear memory? prompt, press the Yes soft key to confirm or the No soft key to cancel. Depending on your phone’s security settings, you may be asked to enter your password a second time.
Phone Information This option allows you to see the phone number of the phone, the manufacturer, and the model number. This information may be necessary if talking to Customer Service in the event of a problem. ➔ ➔ In Idle mode, press Menu Settings and press the Select soft key or the The phone information including: My Number, Manufacturer,...
Section 16: Accessibility TTY Settings* TTY (also known as a TDD or Text Telephone) is a telecommunications device that allows people who are deaf or hard of hearing, or who have speech or language disabilities, to communicate via a telephone. This phone comes TTY-ready and only requires the insertion of the TTY device to enable this feature.
Section 17: Health and Safety Information This section outlines the safety precautions associated with using your phone. These safety precautions should be followed to safely use your phone. Health and Safety Information Exposure to Radio Frequency (RF) Signals Certification Information (SAR) Your wireless phone is a radio transmitter and receiver.
contains no metal and that positions the handset a minimum of 1.5 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. The FCC has granted an Equipment Authorization for this mobile phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY FOLLOW THESE INSTRUCTIONS. FOR CONNECTION TO A SUPPLY NOT IN NORTH AMERICA, USE AN ATTACHMENT PLUG ADAPTOR OF THE PROPER CONFIGURATION FOR THE POWER OUTLET. THIS POWER UNIT IS INTENDED TO BE CORRECTLY ORIENTATED IN A VERTICAL OR HORIZONTAL OR FLOOR MOUNT POSITION.
can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radio frequency energy (RF) at a level that is hazardous to the user. In such a case, FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists.
repeated in other laboratories. A few animal studies, however, have suggested that low levels of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been genetically engineered or treated with cancer-causing chemicals so as to be pre-disposed to develop cancer in absence of RF exposure.
questions about the effects of exposure to radio frequency energy (RF). FDA has been a leading participant in the World Health Organization international Electromagnetic Fields (EMF) Project since its inception in 1996. An influential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world.
Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United Kingdom distributed leaflets containing such a recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill effects.
develop a detailed test method to measure electromagnetic interference (EMI) of implanted cardiac pacemakers and defibrillators from wireless telephones. This test method is now part of a standard sponsored by the Association for the Advancement of Medical instrumentation (AAMI). The final draft, a joint effort by FDA, medical device manufacturers, and many other groups, was completed in late 2000.
speed dial and redial. If available, these features help you to place your call without taking your attention off the road. When available, use a hands-free device. If possible, add an additional layer of convenience and safety to your wireless phone with one of the many hands free accessories available today.
traffic signal, a minor traffic accident where no one appears injured, or a vehicle you know to be stolen, call roadside assistance or other special non-emergency number. "The wireless industry reminds you to use your phone safely when driving." For more information, please call 1-888-901-SAFE, or visit our web-site www.ctia.org.
headphones should allow you to hear the music at lower volumes than when using earbuds. • Limit the amount of time you listen. As the volume increases, less time is required before you hearing could be affected. Avoid using headphones after exposure to extremely loud noises, such •...
As with other mobile radio transmitting equipment, users are advised that for the satisfactory operation of the equipment and for the safety of personnel, it is recommended that the equipment should only be used in the normal operating position (held to your ear with the antenna pointing over your shoulder if you are using an external antenna).
The wireless telephone industry has developed a rating system for wireless phones, to assist hearing device users find phones that may be compatible with their hearing devices. Not all phones have been rated. Phones that are rated have the rating on their box or a label located on the box.
The HAC rating and measurement procedure are described in the American National Standards Institute (ANSI) C63.19 standard. Other Medical Devices If you use any other personal medical devices, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy.
Remember, to make or receive any calls the phone must be switched on and in a service area with adequate signal strength. Emergency calls may not be possible on all wireless phone networks or when certain network services and/or phone features are in use.
Although your phone is quite sturdy, it is a complex piece of equipment and can be broken. Avoid dropping, hitting, bending or sitting on it. Other Important Safety Information Only qualified personnel should service the phone or install the phone •...
Maintaining Your Phone's Peak Performance For the best care of your phone, only authorized personnel should service your phone and accessories. Faulty service may void the warranty. There are several simple guidelines to operating your phone properly and maintaining safe, satisfactory service. To ensure that the Hearing Aid Compatibility rating for your phone is •...
Battery charging time depends on the remaining battery charge and • the type of battery and charger used. The battery can be charged and discharged hundreds of times, but it will gradually wear out. When the operation time (talk time and standby time) is noticeably shorter than normal, it is time to buy a new battery.
Care and Maintenance Your phone is a product of superior design and craftsmanship and should be treated with care. The suggestions below will help you fulfill any warranty obligations and allow you to enjoy this product for many years. Keep the phone and all its parts and accessories out of the reach of •...
Section 18: Warranty Information Standard Limited Warranty What is Covered and For How Long? SAMSUNG TELECOMMUNICATIONS AMERICA, LLC ("SAMSUNG") warrants to the original purchaser ("Purchaser") that SAMSUNG's Phones and accessories ("Products") are free from defects in material and workmanship under normal use and service for the period commencing upon the date of purchase and continuing for the following specified period of time after that date: Phone...
facility in an adequate container for shipping, accompanied by Purchaser's sales receipt or comparable substitute proof of sale showing the date of purchase, the serial number of Product and the sellers' name and address. To obtain assistance on where to deliver the Product, call Samsung Customer Care at 1-888-987- 4357.
OR LOSS OF USE OF THE PRODUCT OR FROM THE BREACH OF THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL, CONSEQUENTIAL OR SIMILAR DAMAGES, OR LOSS OF ANTICIPATED PROFITS OR BENEFITS, OR FOR DAMAGES ARISING FROM ANY TORT (INCLUDING NEGLIGENCE OR GROSS NEGLIGENCE) OR FAULT COMMITTED BY SAMSUNG, ITS AGENTS OR EMPLOYEES, OR FOR ANY BREACH OF CONTRACT OR FOR ANY CLAIM BROUGHT AGAINST PURCHASER BY ANY OTHER...
Precautions for Transfer and Disposal If data stored on this device is deleted or reformatted using the standard methods, the data only appears to be removed on a superficial level, and it may be possible for someone to retrieve and reuse the data by means of special software. To avoid unintended information leaks and other problems of this sort, it is recommended that the device be returned to Samsung’s Customer Care Center for an Extended File System (EFS) Clear...
Index Accessing a Menu Function Accessing AT&T Music Address Book Adding a New Contact Address Book Entry Options Dialing a Number FDN (Fixed Dialing Number) Mode Finding an Address Book Entry Group Settings Own Number Service Dialing Numbers Speed Dial List Used Space Using Contacts List Airplane mode...
My Devices Bluetooth Device Stereo Calendar Anniversary Appointment Holiday Important Private Viewing an Event Call Alert Type Call Forwarding Always Cancel All If Busy If No Reply Unreachable Call Functions 3-Way Calling (Multi-Party Calling) Address Book Adjusting the Call Volume Answering a Call Call Back Call Back Missed Call...
Shooting mode Shortcuts Video clip size White Balance Camera Accessing the Graphics Folder Camera Options Photo Gallery Taking Pictures Camera Options Effects Frame Mosaic Shot Panorama Photo size Settings Shooting mode Shortcuts Timer View Special Effects White Balance Cellular Video Adding a Video Alert Customizing Cellular Video Media Clip Options...
Headset jack/Adapter jack Health and Safety Information International Call Language Input T9 Screen Text Left soft key Light Settings Backlight Time Brightness Low battery indicator Main Display Settings Dialing Display Greeting Message Menu Style Pop Up List Menu Wallpaper Media Clip Options Cellular Video Settings Jump to track time Landscape...
BellSouth Windows Live Mail M-Ratings Multitasking Music File Extensions AAC+ eAAC+ MPEG Music Videos Music Video Options Viewing a Video Clip MusicID Exit Help me out ID song! Manage IDs Mute Navigating with the WAP Browser Entering Text in the WAP Browser Navigation key New Contact Storing in Phone Memory...
PTT Contact Options PTT Group Options Push To Talk Add Contacts Add Group Help Making a PTT Call PTT Icons PTT Settings Push to Talk key Recent Calls Record Audio Audio Folder Right soft key SAR values Security APN Control Change Phone Password Change PIN Code Change PIN2 Code...
Time Time Format Time Zone Time Zone Updating Tools Calculator Converter Notes Stopwatch Timer Tip Calculator World Time T-Ratings Travel adapter TTY Settings UL Certification Understanding Your Phone Closed View of Your Phone Features of Your Phone Open View of Your Phone Using Favorites Accessing a WAP Site Using Favorites...
