Page 1
If your appliance needs service, ship the product to your nearest regional service center. Be sure to put your name on the outside of shipping box (no P.O. boxes please). If in warranty, Rowenta will repair or replace product at their discretion. If the product is out of warranty, you will be advised of the cost of repair before any work begins.
Page 3
DZ9080 US 1103898398 10/05/06 11:00 Page 4 11b* 11c* 11a* 11d* DESCRIPTION Spray nozzle Handle Water filling inlet Thermostat control light* Variable steam control Temperature control dial Dry ironing display* Smooth steam Yellow LED High Pressure steam Green LED Self Clean...
- To avoid the risk of electric shock, do not disassemble the appliance. Ship it to the nearest authorized Rowenta approved service center for examination and repair. Incorrect reassembly can cause a risk of electric shock when the appliance is used.
- Adhere to manufacturer recommendations on garment label. WATER RECOMMENDATIONS 1 • Tap water Rowenta irons are designed to be used with REGULAR TAP WATER (up to 12 grains of hardness). If your water is harder than this, Rowenta recommends mixing half tap water with half bottled spring water which reduces the hardness;...
Never use 100 % distilled water. Once you have changed water it will take several uses to correct the problem. Rowenta recommends trying the steam function for the first time on an old towel or cloth that can be discarded to avoid damaging your clothes.
DZ9080 US 1103898398 10/05/06 11:00 Page 5 - Fill with water (containing no additives) to the max mark on the water tank. We recommend using the enclosed filling cup rather than filling under the tap. - If equipped with filling inlet cover, slide cover to close.
DZ9080 US 1103898398 10/05/06 11:00 Page 6 YELLOW The iron is heating up to reach the selected LIGHT temperature. The iron is ready to be used. GREEN The temperature of the soleplate reached the LIGHT selected setting. Do not iron.
DZ9080 US 1103898398 10/05/06 11:00 Page 7 Before ironing for the first time fill iron and allow to heat. The iron should be allowed to emit steam for at least 1 minute to remove any impurities. Press the burst of steam button a few times prior to ironing.
DZ9080 US 1103898398 10/05/06 11:00 Page 8 WARNING ! Never direct steam at persons or animals. 11 • Spray Setting This feature is ideal for stubborn wrinkles or set in creases. Ensure there is water in the tank then press the spray button.
Page 11
DZ9080 US 1103898398 10/05/06 11:00 Page 9 This feature allows loose mineral deposits and other impurities to be flushed from the soleplate. - Fill the iron with tap water to the max mark on the water tank. - Be sure that variable steam lever is set to minimum.
- In normal use a draggy coating may build up on the soleplate (starch, detergent build-up, burnt synthetic fibers). This can be easily removed by using the Rowenta Soleplate Cleaning Kit or a quality hot iron soleplate cleaner available at most stores. The Rowenta kit is also available through our website: www.rowentausa.com...
DZ9080 US 1103898398 10/05/06 11:00 Page 11 20 • Troubleshooting Issues Possible causes Solutions Iron does not heat. The temperature control Set the temperature is set too low. control to a higher temperature. Not properly plugged in. Check that iron is plugged in correctly.
Page 14
DZ9080 US 1103898398 10/05/06 11:00 Page 12 Iron is leaking. Over use of burst button. Allow more time between each burst. Distilled or softened water being used. See section "Water Recommendations”. Overfilled. Switch to spring water or mix tap water with spring water.
Page 15
DZ9080 US 1103898398 10/05/06 11:00 Page 13 In the interest of improving products, Rowenta reserves the right to change specifications without prior notice. LIMITED WARRANTY This Rowenta product is warranted against defects in material and workmanship for one year from the initial purchase date.
