Troubleshooting

If you don't hear sound, or if the system does not operate as you expect, please check the following points first.
If you are still unable to resolve the problem, contact your retailer, the nearest Roland Service Center, or an authorized Roland
distributor, as listed on the "Information" page.
Problem
No sound
USB flash drive is not recognized
Songs saved on the USB flash drive will
not play back correctly
Can't play back MP3/WAV files
Can't save the TD's data to a USB flash
drive
Can't correctly set the A-B repeat times
Computer does not recognize the TD
48
Items to check
Is the connection cable correctly con-
nected to the TRIGGER INPUT connector?
Are the cables correctly connected to each
pad and pedal?
Are the cables correctly connected to the
TD's OUTPUT jacks or the PHONES jack?
Are the cables correctly connected to the
input jacks of your amp or audio system?
Could there be a problem with the
connection cables?
Could the [VOLUME] knob be turned all
the way to the left?
Have you made the correct input selection
setting on your amp or audio system?
Are the volume settings of your amp or
audio system appropriate?
Check the type of USB flash drive.
Check the format of the USB flash drive.
Does the TD support the sampling
frequency and bit rate of the MP3 file, or
the sampling frequency and bit depth of
the WAV file?
Playback may be unable to keep up if you raise the playback speed or change the pitch
of a high bit-rate MP3.
Is there sufficient free space on the USB
flash drive?
It's not possible to set the "A" and "B" times
any closer than one second.
When using an MP3 file, it might not be possible to play back the A-B repeat region
correctly.
Is the TD correctly connected to your
computer?
Is the USB driver installed?
Make sure that the USB cable connecting
the TD to your computer's USB port is
compatible with USB 2.0 Hi-Speed.
Action
Check the connections.
Try using other cables.
Try raising the volume of the TD.
If you're using the TD-15, check the side
panel [VOLUME] knob as well.
Check your amp or audio system.
Try raising the volume of your amp or
audio system.
Use a USB flash drive sold by Roland. We
cannot guarantee correct operation if any
other product is used.
The TD can use USB flash drives that are
formatted in FAT format.
Reformat the USB flash drive using the TD.
Use MP3/WAV files that the TD supports.
Delete unneeded files from the USB flash
drive, or use a higher-capacity USB flash
drive.
Make sure that there is at least one second
between the two times.
Check the connection to your computer.
You must first install the USB driver in your
computer.
Use a computer and cable that support
USB 2.0 Hi-Speed.
Page
—
p. 8
—
p. 7
—
—
—
p. 40
p. 26
—
p. 39
p. 29
p. 47
