- Page 1 Install guide 8050C ENGLISH Customer Support: 888-515-2585 or Visit our website www.ritetemp-thermostats.com 1-405-061 Made in China...
- Page 2 Install guide 8050C To avoid electrical shock and to prevent damage to the furnace, air conditioner, Caution and thermostat, disconnect the power supply before beginning work. This can be done at the circuit breaker, or at the appliance. You will need #1 Phillips screwdriver (small) and Tools Drill with 3/16-in.
- Page 3 Remove the old thermostat from the wall. Fill wall opening with fiber glass insulation to prevent drafts. 4 Mount the 8050C Separate front from back of unit. Press up on the catch on the bottom of the thermostat and swing the body away from the base, lift up to remove the body from the base.
- Page 4 The batteries will last well over 1 year. If the batteries are not replaced the thermostat will stop working. 2) The 8050C can run on the C wire if available. (24 VAC ONLY) As shown in the wiring diagrams, The C wire is the other side of the 24VAC heating transformer.
- Page 5 Y or B Turn Valve off Turn Valve on Note: On a heat pump, if O and B are both present, connect O to O and tape off B. For wiring support call 1-888-515-2585 or visit our website at www.ritetemp-thermostats.com...
- Page 6 Go To Page 17 Go To Page 16 If you do not find the wiring information for your system try our website: www.ritetemp-thermostats.com for more information or call our customer service at 888-515-2585. 9 Wire Connections cont When you have finished connecting the wires attach control unit to wall unit.
- Page 7 2 WIRE a c e F r o m F u r n Thermostat jumper NOTE: Wires marked with wire the dotted line are optional. HEAT HEAT Power FURNACE STEP 1 - Connect the R (or RH) wire to the RH terminal on the thermostat.
- Page 8 a c e F ro m F u rn a n d A C u n 4 WIRE STEP 1 - Connect the Y wire NON-HEAT PUMP to the Y terminal on the Thermostat thermostat. This connects to the Cooler compressor. jumper wire STEP 2 - Connect the RH or R wire to the RH...
-
Page 9: Heat Pump
NORMAL 2 Stage F ro m N o rm Heat System y s te m tw o s ta g e s STEP 1 - Connect the G wire to jumper wire the G terminal on the thermostat. This connects the Fan. Thermostat STEP 2 - Connect the W wire to the W terminal. - Page 10 Your HVAC system is now connected to the thermostat. 8050C Features The 8050C can be used with most 24-volt gas, oil or electric heating and air conditioning systems, all heat pumps, and gas millivolt heating systems. It cannot be used with 120 volt heating systems. Ask The Home Depot for other thermostats to control line voltage systems.
