Adjusting the image

If necessary, adjust the height of the projector by pressing the elevator foot release button to
extend the foot.
If necessary, rotate the leveling feet located at the rear of the projector.
Position the projector the desired distance from the screen at a 90 degree angle to the
screen.
See page 6 for a table listing screen sizes and distances.
Adjust the zoom or focus.
If the image is not square, first make sure that the projector is perpendicular to the screen. If
the image is larger or smaller on the top or bottom edge of the screen, press the top
Keystone
button to reduce the upper part of the image, and press the bottom
button to reduce the lower part.
If the left or right side of the screen is larger or smaller the other, you can turn the projector
to the left or to the right a few degrees to square the image.
Adjust the Contrast or Brightness in the Basic Menu. See page 25 for help with these menu
adjustments.
adjust height
elevator foot release button
adjust distance
adjust zoom and focus
adjust keystone
Keystone
adjust Basic Menu
9
leveling feet
( )
Basic Menu
MDL: IN3124
FW: 1.02
Aspect Ratio ◄ Auto ►
Auto Image Execute
Brightness 50
Contrast 50
Auto Keystone Off
Keystone 0
Presets Presentation
Sharpness 16
Volume 15
Microphone Volume 8
Ceiling Mount Off
Advanced Menu
